Dendritic cell-specific ICAM-3 grabbing non-integrin (DC-SIGN or CD299) and DC-SIGN related protein (DC-SIGNR, DC-SIGN2, L-SIGN or CD209L) are type II membrane proteins that are mannose-specific calcium-dependent (C-type) lectins. The two proteins share 77% amino acid identity. DC-SIGN mediates interactions between dendritic cells (DCs) and T cells. Both DC-SIGN and DC-SIGNR have been shown to bind HIV, hepatitis C glycoproteins, Ebola virus glycoproteins and the cellular adhesion protein ICAM-3 (1‑4). DC-SIGN and DC-SIGNR appear to selectively recognize and bind viral proteins containing a large portion of high-mannose oligosaccharides (5). Though DC-SIGN and DC-SIGNR are found on the same chromosome, they are not expressed in the same tissue. DC-SIGN is expressed solely on Dendritic cells while DC-SIGNR is found on endothelial cells in the liver and lymph node sinuses and in a significant portion of capillary endothelial cells in term placenta (1, 4).
Human DC-SIGNR/CD299 Antibody (120604)
R&D Systems | Catalog # MAB162
Clone 120604 was used by HLDA to establish CD designation
Scientific images may be resized, cropped, or adjusted for brightness or contrast for presentation purposes. These updates are limited to presentation and do not affect the underlying scientific interpretation of the data. Where available, additional source data may be provided upon request.
Key Product Details
Species Reactivity
Validated:
Human
Cited:
Human, Mouse, Primate - Cercopithecus aethiops (African Green Monkey)
Applications
Validated:
Adhesion Blockade, Flow Cytometry, CyTOF-ready
Cited:
Immunohistochemistry, Immunohistochemistry-Frozen, Neutralization, Flow Cytometry, Immunocytochemistry, ELISA Detection
Label
Unconjugated
Antibody Source
Monoclonal Mouse IgG2B Clone # 120604
Loading...
Product Specifications
Immunogen
NIH-3T3 mouse embryonic fibroblast cell line transfected with human DC‑SIGNR/CD299
Accession # Q9H2X3
Accession # Q9H2X3
Specificity
Detects human DC‑SIGNR/CD299.
Clonality
Monoclonal
Host
Mouse
Isotype
IgG2B
Scientific Data Images for Human DC-SIGNR/CD299 Antibody (120604)
Detection of DC‑SIGNR/CD299 in Human DC‑SIGNR/CD299 Transfected 3T3 Mouse Cell Line by Flow Cytometry.
Human DC-SIGNR/CD299 and DC-SIGN transfected 3T3 mouse embryonic fibroblast cell line were stained with Mouse Anti-Human DC-SIGNR/CD299 Monoclonal Antibody (Catalog # MAB162, filled histograms) or isotype control antibody (Catalog # MAB0041, open histogram), followed by Phycoerythrin-conjugated Anti-Mouse IgG F(ab')2Secondary Antibody (Catalog # F0102B).
Detection of Human DC-SIGNR/CD299/CLEC4M by Immunocytochemistry/Immunofluorescence
In situ localization of Ptx3-LECs and transition between Ptx3-LECs and Marco-LECs in human LNs. (A) Expression of CD36/Cd36 in LN LEC subsets of human and mouse. Dots indicate mean log-normalized transcript count. (B–D) Identification of CD36high Ptx3-LECs in human head and neck LNs by immunostaining. (B,C) Immunofluorescence of PROX-1, MARCO and CD36 (B), or PROX-1, LYVE-1 and CLEC4M (C). Zoomed-in images (inset marked by blue dotted lines) in (B) and (C) demonstrate CD36high LYVE-1+ paracortical sinuses (filled arrowhead). Scale bars = 500 μm (left panels) and 100 μm (right panel inset). (D) CD36high LYVE-1+ Ptx3-LECs (filled arrowhead) can be seen associated with MARCO+ CLEC4M+ Marco-LECs (empty arrowhead) in human LNs. Scale bars = 100 μm. CD36high Ptx3-LECs were detected in four out of seven human LNs. Images are representative of four biological replicates. Image collected and cropped by CiteAb from the following publication (https://pubmed.ncbi.nlm.nih.gov/32426372), licensed under a CC-BY license. Not internally tested by R&D Systems.
Detection of Human DC-SIGNR/CD299/CLEC4M by Immunocytochemistry/Immunofluorescence
In situ localization of Ptx3-LECs and transition between Ptx3-LECs and Marco-LECs in human LNs. (A) Expression of CD36/Cd36 in LN LEC subsets of human and mouse. Dots indicate mean log-normalized transcript count. (B–D) Identification of CD36high Ptx3-LECs in human head and neck LNs by immunostaining. (B,C) Immunofluorescence of PROX-1, MARCO and CD36 (B), or PROX-1, LYVE-1 and CLEC4M (C). Zoomed-in images (inset marked by blue dotted lines) in (B) and (C) demonstrate CD36high LYVE-1+ paracortical sinuses (filled arrowhead). Scale bars = 500 μm (left panels) and 100 μm (right panel inset). (D) CD36high LYVE-1+ Ptx3-LECs (filled arrowhead) can be seen associated with MARCO+ CLEC4M+ Marco-LECs (empty arrowhead) in human LNs. Scale bars = 100 μm. CD36high Ptx3-LECs were detected in four out of seven human LNs. Images are representative of four biological replicates. Image collected and cropped by CiteAb from the following publication (https://pubmed.ncbi.nlm.nih.gov/32426372), licensed under a CC-BY license. Not internally tested by R&D Systems.Applications for Human DC-SIGNR/CD299 Antibody (120604)
Application
Recommended Usage
Adhesion Blockade
The adhesion of NIH-3T3 mouse embryonic fibroblast cells (5 x 104 cells/well) to immobilized Recombinant Human ICAM-3/CD50 Fc Chimera (Catalog # 715-IC, 5 µg/mL, 100 µL/well) was maximally inhibited (80-100%) by 2.5 µg/mL of the antibody.
CyTOF-ready
Ready to be labeled using established conjugation methods. No BSA or other carrier proteins that could interfere with conjugation.
Flow Cytometry
2.5 µg/106 cells
Sample: Human DC‑SIGNR/CD299 transfected 3T3 mouse embryonic fibroblast cell line
Sample: Human DC‑SIGNR/CD299 transfected 3T3 mouse embryonic fibroblast cell line
Flow Cytometry Panel Builder
Bio-Techne Knows Flow Cytometry
Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.
Advanced Features
- Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
- Spillover Popups - Visualize the spectra of individual fluorochromes
- Antigen Density Selector - Match fluorochrome brightness with antigen density
Formulation, Preparation, and Storage
Purification
Protein A or G purified from hybridoma culture supernatant
Reconstitution
Reconstitute at 0.5 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.
Loading...
Formulation
Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.
Shipping
Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.
Stability & Storage
Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
- 12 months from date of receipt, -20 to -70 °C as supplied.
- 1 month, 2 to 8 °C under sterile conditions after reconstitution.
- 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Calculators
Background: DC-SIGNR/CD299
References
- Pohlmann, S. et al. (2001) Proc. Natl. Acad. Sci. USA 98:2670.
- Pohlmann, S. et al. (2003) J. Virol. 77:4070.
- Simmons, L.G. et al. (2003) J. Virol. 77:1337.
- Bahirova, A.A. et al. (2001) J. Exp. Med. 193:671.
- Feinberg, H. et al. (2001) Science 294:2163.
Long Name
Dendritic Cell-specific ICAM-3-grabbing Non-integrin 2
Alternate Names
CD209L, CD299, CLEC4M, DC-SIGN2, DCSIGNR, LSIGN
Entrez Gene IDs
10332 (Human)
Gene Symbol
CLEC4M
