The neuregulin family of structurally related glycoproteins comprises products from four distinct but related genes, Nrg-1, Nrg-2, Nrg-3, and Nrg-4. Through alternative splicing or the use of alternative promoters, Nrg-1 encodes more than 14 soluble or transmembrane proteins. The extracellular domain of the transmembrane NRG1 isoforms can be proteolytically cleaved to release soluble growth factors. The alpha - or beta -splice variants differ in their C-terminal region. All NRG1 isoforms contain an EGF-like domain that is required for their direct binding to the ErbB3 or ErbB4 receptor tyrosine kinases. The ErbB3 or ErbB4 subsequently recruits and heterodimerizes with ErbB2, resulting in tyrosine phosphorylation and NRG1 signaling. NRG1 isoforms can be classified into three major subtypes. Type I (Neu Differentiation Factor, NDF; Heregulin, HRG; Acetylcholine Receptor Inducing Activity, ARIA) and type II (Glial Growth Factor, GGF). NRG1s have an immunoglobulin (Ig)-like domain N‑terminal to the EGF-like domain. Type I NRG1s differ from type II NRG1s by having a glycosylation-rich domain between the Ig-like and the EGF-like domains. Type III NRG1 (Sensory and Motor neuron-Derived Factor) lacks the Ig-like domain but has a cysteine rich domain (CRD) instead. NRG1 isoforms show distinct spatial and temporal expression patterns. These proteins play important roles during development of both the nervous system and the heart. They have been shown to regulate the selective expression of neurotransmitter receptors in neurons and at the neuromuscular junction, and to promote the differentiation and development of Schwann cells from neural crest stem cells. NRG1s have also been shown to be involved in the establishment of the oligodendroglial lineage.
Human NRG1‑ alpha /HRG1‑ alpha EGF Domain Antibody
R&D Systems | Catalog # AF-296-NA
Key Product Details
Species Reactivity
Validated:
Human
Cited:
Human, Mouse, Transgenic Mouse, Xenograft
Applications
Validated:
Immunohistochemistry, Western Blot, Neutralization
Cited:
Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Neutralization
Label
Unconjugated
Antibody Source
Polyclonal Goat IgG
Loading...
Product Specifications
Immunogen
E. coli-derived recombinant human NRG1-alpha /HRG1-alpha
Ser177-Lys241
Accession # Q7RTV8
Ser177-Lys241
Accession # Q7RTV8
Specificity
Detects human NRG1-alpha /HRG1-alpha in direct ELISAs and Western blots.
Clonality
Polyclonal
Host
Goat
Isotype
IgG
Endotoxin Level
<0.10 EU per 1 μg of the antibody by the LAL method.
Scientific Data Images for Human NRG1‑ alpha /HRG1‑ alpha EGF Domain Antibody
NRG1-alpha /HRG1-alpha in Human Breast.
NRG1-a/HRG1-a was detected in paraffin-embedded sections of human breast using Goat Anti-Human NRG1-a/HRG1-a EGF Domain Antigen Affinity-purified Polyclonal Antibody (Catalog # AF-296-NA) at 15 µg/mL overnight at 4 °C. Tissue was stained using the Anti-Goat HRP-AEC Cell & Tissue Staining Kit (red; Catalog # CTS009) and counterstained with hematoxylin (blue). View our protocol for Chromogenic IHC Staining of Paraffin-embedded Tissue Sections.Cell Proliferation Induced by NRG1‑ alpha /HRG1‑ alpha and Neutralization by Human NRG1‑ alpha /HRG1‑ alpha Antibody.
Recombinant Human NRG1-a/HRG1-a EGF Domain (Catalog # 296-HR) stimulates proliferation in the MCF-7 human breast cancer cell line in a dose-dependent manner (orange line). Proliferation elicited by Recombinant Human NRG1-a/HRG1-a EGF Domain (125 ng/mL) is neutralized (green line) by increasing concentrations of Human NRG1-a/HRG1-a EGF Domain Antigen Affinity-purified Polyclonal Antibody (Catalog # AF-296-NA). The ND50 is typically 7-30 µg/mL.Applications for Human NRG1‑ alpha /HRG1‑ alpha EGF Domain Antibody
Application
Recommended Usage
Immunohistochemistry
5-15 µg/mL
Sample: Immersion fixed paraffin-embedded sections of human breast and human breast cancer tissue
Sample: Immersion fixed paraffin-embedded sections of human breast and human breast cancer tissue
Western Blot
0.1 µg/mL
Sample: Recombinant Human NRG1-alpha /HRG1-alpha EGF Domain (Catalog # 296-HR)
Sample: Recombinant Human NRG1-alpha /HRG1-alpha EGF Domain (Catalog # 296-HR)
Neutralization
Measured by its ability to neutralize NRG1‑ alpha /HRG1‑ alpha -induced proliferation in the MCF‑7 human breast cancer cell line. The Neutralization Dose (ND50) is typically 7-30 µg/mL in the presence of 125 ng/mL Recombinant Human NRG1‑ alpha /HRG1‑ alpha EGF Domain.
Formulation, Preparation, and Storage
Purification
Antigen Affinity-purified
Reconstitution
Reconstitute at 0.2 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.
Loading...
Formulation
Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.
Shipping
Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.
Stability & Storage
Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
- 12 months from date of receipt, -20 to -70 °C as supplied.
- 1 month, 2 to 8 °C under sterile conditions after reconstitution.
- 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Calculators
Background: Neuregulin-1 alpha/NRG1 alpha
References
- Lemke, G. (2006) Science STKE 325:pe11.
- Esper, R.M. et al. (2006) Brain Res. Brain Res. Rev. 51:161.
- Tosato, S. et al. (2005) Schizophr. Bull. 31:613.
Alternate Names
Neuregulin1 alpha
Gene Symbol
NRG1
UniProt
Additional Neuregulin-1 alpha/NRG1 alpha Products
Product Documents for Human NRG1‑ alpha /HRG1‑ alpha EGF Domain Antibody
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Note: Certificate of Analysis not available for kit components.
Product Specific Notices for Human NRG1‑ alpha /HRG1‑ alpha EGF Domain Antibody
For research use only
