Human PD-L2/B7-DC Antibody MAB1224-100: R&D Systems

Human PD-L2/B7-DC Antibody

(3 citations)
  • Species Reactivity
    Human
  • Specificity
    Detects human PD-L2/B7-DC in direct ELISAs and Western blots. In direct ELISAs, no cross-reactivity with recombinant mouse PD-L2, recombinant human (rh) B7-1, rhB7-2, rhB7-H1, rhB7-H2, or rhB7-H3 is observed.
  • Source
    Monoclonal Mouse IgG2B Clone # 176611
  • Purification
    Protein A or G purified from hybridoma culture supernatant
  • Immunogen
    Mouse myeloma cell line NS0-derived recombinant human PD-L2/B7-DC
    Leu20-Pro219 (predicted)
    Accession # Q9BQ51
  • Formulation
    Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied as a 0.2 µm filtered solution in PBS.
  • Label
    Unconjugated
Applications
  •
    Recommended
    Concentration
    Sample
  • Western Blot
    1 µg/mL
    Recombinant Human PD-L2 Fc Chimera (Catalog # 1224-PL)
  • Flow Cytometry
    2.5 µg/106 cells
    See below
  • Immunohistochemistry
    0.5-25 µg/mL
    See below
  • CyTOF-ready
    Ready to be labeled using established conjugation methods. No BSA or other carrier proteins that could interfere with conjugation.
Please Note: Optimal dilutions should be determined by each laboratory for each application. General Protocols are available in the Technical Information section on our website.
Data Examples
Detection of PD‑L2 in HepG2 Human Cell Line by Flow Cytometry. HepG2 human hepatocellular carcinoma cell line was stained with Human PD‑L2 Monoclonal Antibody (Catalog # MAB1224, filled histogram) or isotype control antibody (Catalog # MAB0041, open histogram), followed by Phycoerythrin-conjugated Anti-Mouse IgG
F(ab')2 Secondary Antibody (Catalog # F0102B).
Immunohistochemistry
PD‑L2/B7‑DC in Human Lung Cancer Tissue. PD‑L2/B7‑DC was detected in immersion fixed paraffin-embedded sections of human lung cancer tissue using Mouse Anti-Human PD‑L2/B7‑DC Monoclonal Antibody (Catalog # MAB1224) at 0.5 µg/mL for 1 hour at room temperature followed by incubation with the Anti-Mouse IgG VisUCyte™ HRP Polymer Antibody (Catalog # VC001). Tissue was stained using DAB (brown) and counterstained with hematoxylin (blue). Specific staining was localized to cytoplasm. View our protocol for IHC Staining with VisUCyte HRP Polymer Detection Reagents.
Preparation and Storage
  • Reconstitution
    Reconstitute at 0.5 mg/mL in sterile PBS.
  • Shipping
    The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below. *Small pack size (SP) is shipped with polar packs. Upon receipt, store it immediately at -20 to -70 °C
  • Stability & Storage
    Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
    • 12 months from date of receipt, -20 to -70 °C as supplied.
    • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
    • 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Background: PD-L2/B7-DC

T cells require a signal induced by the engagement of the T cell receptor and a “co‑stimulatory” signal(s) through distinct T cell surface molecules for optimal T cell activation and tolerance. Members of the B7 superfamily of counter-receptors were identified by their ability to interact with co‑stimulatory molecules found on the surface of T cells. Members of the B7 superfamily include B7-1 (CD80), B7-2 (CD86), B7-H1 (PD-L1), B7-H2 (B7RP-1), B7-H3, and PD-L2 (B7-DC) (1). B7 proteins are immunoglobulin (Ig) superfamily members with extracellular Ig-V-like and Ig-C-like domains and short cytoplasmic domains. Among the family members, they share from 20‑40% amino acid (aa) sequence identity. The cloned human PD-L2 cDNA encodes a 273 aa type I membrane precursor protein with a putative 20 aa signal peptide, a 201 aa extracellular region containing one V-like and one C-like Ig domain, a 24 aa transmembrane region, and a 28 aa cytoplasmic domain. The extracellular domains of mouse and human PD-L2 share approximately 70% aa sequence identity (2). PD-L2 is one of two ligands for programmed death-1 (PD-1), a member of the CD28 family of immuno-receptors. The other identified ligand is PD-L1. Human PD-L1 and PD-L2 share approximately 41% aa sequence identity and have similar functions. PD-L2 is broadly expressed in tissues. Highest expression was detected by Northern blot analysis in heart, placenta, liver, pancreas, spleen, and lymph node. Lower amounts of expression were observed in lung, smooth muscle, and thymus. Expression of PD-L2 on antigen presenting cell has been examined in detail. Resting B cells, monocytes and dendritic cells do not express PD-L2, expression however can be induced by LPS or BCR activation in B cells, INF-gamma treatment in monocytes, or LPS plus IFN-gamma treatment of dendritic cells. PD-L2 expression is also up regulated in a variety of tumor cell lines. On previously activated T cells, PD-L2 interaction with PD-1 inhibits TCR-mediated proliferation and cytokine production, suggesting an inhibitory role in regulating immune responses. In contrast, a co‑stimulatory function for the PD-L2 on resting T cells activated with sub-optimal TCR signals has also been reported (3).



  • References:
    1. Coyle, A.J. and J-C. Gutierrrez-Ramos (2001) Nature Immunol. 2:203.
    2. Latchman Y. et al. (2001) Nature Immun. 2:261.
    3. Carreno, B.M. and M. Collins (2002) Annu. Rev. Immunol. 20:29.

  • Long Name:
    Programmed Death-1 Ligand-2
  • Entrez Gene IDs:
    80380 (Human); 58205 (Mouse); 102146227 (Cynomolgus Monkey)
  • Alternate Names:
    B7-DC; bA574F11.2; Btdc; Butyrophilin B7-DC; Butyrophilin-like Protein; CD273 antigen; CD273; CD273PD-1 ligand 2; MGC142240; PD-1-ligand 2; PDCD1L2MGC142238; PDCD1LG2; PDL2; PD-L2; PDL2B7DC; PD-L2PDCD1 ligand 2; programmed cell death 1 ligand 2; Programmed death ligand 2
Related Research Areas
Citations:

R&D Systems personnel manually curate a database that contains references using R&D Systems products. The data collected includes not only links to publications in PubMed, but also provides information about sample types, species, and experimental conditions.

3 Citations: Showing 1 - 3
Filter your results:

Species
Applications
Sample Type
  1. Clinicopathologic analysis of programmed cell death-1 and programmed cell death-ligand 1 and 2 expressions in pulmonary adenocarcinoma: comparison with histology and driver oncogenic alteration status.
    Authors: Koh J, Go H, Keam B, Kim M, Nam S, Kim T, Lee S, Min H, Kim Y, Kim D, Jeon Y, Chung D
    Mod Pathol, 2015;28(9):1154-66.
    Species: Mouse
    Sample Type: Whole Tissue
    Application: IHC Not Specified
  2. IFN-gamma generates maturation-arrested dendritic cells that induce T cell hyporesponsiveness independent of Foxp3+ T-regulatory cell generation.
    Authors: Rojas D, Krishnan R,
    Immunol. Lett., 2010;132(1):31-7.
    Species: Human
    Sample Type: Whole Cells
    Application: Flow
  3. Expression of B7-H1 on gastric epithelial cells: its potential role in regulating T cells during Helicobacter pylori infection.
    Authors: Das S, Suarez G, Beswick EJ, Sierra JC, Graham DY, Reyes VE
    J. Immunol., 2006;176(5):3000-9.
    Species: Human
    Sample Type: Cell Lysates
    Application: WB
