![Immunohistochemistry-Paraffin: NDUFB5 Antibody [NBP1-85607]](https://resources.rndsystems.com/images/products/NDUFB5-Antibody-Immunohistochemistry-Paraffin-NBP1-85607-img0010.jpg "Immunohistochemistry-Paraffin: NDUFB5 Antibody [NBP1-85607]")
Loading...
Key Product Details
Validated by
Orthogonal Validation
Species Reactivity
Human
Applications
Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Immunocytochemistry/ Immunofluorescence
Label
Unconjugated
Antibody Source
Polyclonal Rabbit IgG
Format
BSA Free
Loading...
Product Specifications
Immunogen
This antibody was developed against Recombinant Protein corresponding to amino acids: EGYVPEHWEYYKHPISRWIARNFYDSPEKIYERTMAVLQIEAEKAELRVKELEVRKLMHVRGDGPWYYYETIDKELIDHSPKATPDN
Reactivity Notes
Reactivity reported in adult mouse brain from a verified customer review.
Clonality
Polyclonal
Host
Rabbit
Isotype
IgG
Scientific Data Images for NDUFB5 Antibody - BSA Free
![Western Blot: NDUFB5 Antibody [NBP1-85607]](https://resources.rndsystems.com/images/products/NDUFB5-Antibody-Western-Blot-NBP1-85607-img0005.jpg "Western Blot: NDUFB5 Antibody [NBP1-85607]")
Western Blot: NDUFB5 Antibody [NBP1-85607]
Western Blot: NDUFB5 Antibody [NBP1-85607] - Lane 1: Marker [kDa] 220, 112, 84, 47, 32, 26, 17. Lane 2: Human cell line RT-4. Lane 3: Human cell line U-251MG sp. Lane 4: Human plasma (IgG/HSA depleted). Lane 5: Human liver tissue. Lane 6: Human tonsil tissue![Immunocytochemistry/ Immunofluorescence: NDUFB5 Antibody [NBP1-85607]](https://resources.rndsystems.com/images/products/NDUFB5-Antibody-Immunocytochemistry-Immunofluorescence-NBP1-85607-img0006.jpg "Immunocytochemistry/ Immunofluorescence: NDUFB5 Antibody [NBP1-85607]")
Immunocytochemistry/ Immunofluorescence: NDUFB5 Antibody [NBP1-85607]
Immunocytochemistry/Immunofluorescence: NDUFB5 Antibody [NBP1-85607] - Immunofluorescent staining of human cell line U-2 OS shows localization to nucleoplasm & mitochondria. Antibody staining is shown in green.![Immunohistochemistry-Frozen: NDUFB5 Antibody [NBP1-85607]](https://resources.rndsystems.com/images/products/NDUFB5-Antibody-Immunohistochemistry-Frozen-NBP1-85607-img0014.jpg "Immunohistochemistry-Frozen: NDUFB5 Antibody [NBP1-85607]")
Immunohistochemistry-Frozen: NDUFB5 Antibody [NBP1-85607]
Immunohistochemistry-Frozen: NDUFB5 Antibody [NBP1-85607] - PFA-fixed cryosections (14 um) of adult mouse brain.100x confocal imaging. Mitochondria are labeled. Antigen retrieval was performed in boiling 10mM citric acid (pH6) for 15 min, followed by block in 5% goat serum (PBS/ 0.3% triton) and incubated in primary ab (1:100) overnight at 4C in goat block. Developed with goat-anti-rabbit Alexa 488. Image from verified customer review.![Immunohistochemistry-Paraffin: NDUFB5 Antibody [NBP1-85607]](https://resources.rndsystems.com/images/products/NDUFB5-Antibody-Immunohistochemistry-Paraffin-NBP1-85607-img0011.jpg "Immunohistochemistry-Paraffin: NDUFB5 Antibody [NBP1-85607]")
Immunohistochemistry-Paraffin: NDUFB5 Antibody [NBP1-85607]
Immunohistochemistry-Paraffin: NDUFB5 Antibody [NBP1-85607] - Staining of human heart muscle shows strong positivity in mitochondria in cardiomyocytes.![Immunohistochemistry-Paraffin: NDUFB5 Antibody [NBP1-85607]](https://resources.rndsystems.com/images/products/NDUFB5-Antibody-Immunohistochemistry-Paraffin-NBP1-85607-img0013.jpg "Immunohistochemistry-Paraffin: NDUFB5 Antibody [NBP1-85607]")
Immunohistochemistry-Paraffin: NDUFB5 Antibody [NBP1-85607]
Immunohistochemistry-Paraffin: NDUFB5 Antibody [NBP1-85607] - Staining of human pancreas shows weak positivity in mitochondria in exocrine glandular cells.![Immunohistochemistry-Paraffin: NDUFB5 Antibody [NBP1-85607]](https://resources.rndsystems.com/images/products/NDUFB5-Antibody-Immunohistochemistry-Paraffin-NBP1-85607-img0012.jpg "Immunohistochemistry-Paraffin: NDUFB5 Antibody [NBP1-85607]")
Immunohistochemistry-Paraffin: NDUFB5 Antibody [NBP1-85607]
Immunohistochemistry-Paraffin: NDUFB5 Antibody [NBP1-85607] - Staining of human kidney shows strong positivity in mitochondria in cells in tubules.Applications for NDUFB5 Antibody - BSA Free
Application
Recommended Usage
Immunocytochemistry/ Immunofluorescence
0.25-2 ug/ml
Immunohistochemistry
1:50 - 1:200
Immunohistochemistry-Paraffin
1:50 - 1:200
Western Blot
0.04-0.4 ug/ml
Application Notes
For IHC-Paraffin, HIER pH 6 retrieval is recommended. ICC/IF,Fixation Permeabilization: Use PFA/Triton X-100. NDUFB5 antibody validated for IHC-FR from a verified customer review.
Reviewed Applications
Read 1 review rated 5 using NBP1-85607 in the following applications:
Formulation, Preparation, and Storage
Purification
Affinity purified
Formulation
PBS (pH 7.2) and 40% Glycerol
Format
BSA Free
Preservative
0.02% Sodium Azide
Concentration
Concentrations vary lot to lot. See vial label for concentration. If unlisted please contact technical services.
Shipping
The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage
Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.
Background: NDUFB5
Alternate Names
5 (16kD, SGDH), CISGDH, CI-SGDH, Complex I-SGDH, DKFZp686N02262, FLJ30597, MGC111204, MGC12314, NADH dehydrogenase (ubiquinone) 1 beta subcomplex, 5, 16kDa, NADH dehydrogenase [ubiquinone] 1 beta subcomplex subunit 5, mitochondrial, SGDH
Gene Symbol
NDUFB5
Additional NDUFB5 Products
Product Documents for NDUFB5 Antibody - BSA Free
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Product Specific Notices for NDUFB5 Antibody - BSA Free
This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
Customer Reviews for NDUFB5 Antibody - BSA Free (1)
5 out of 5
1 Customer Rating
Have you used NDUFB5 Antibody - BSA Free?
Submit a review and receive an Amazon gift card!
$25/€18/£15/$25CAN/¥2500 for a review with an image
$10/€7/£6/$10CAN/¥1110 for a review without an image
Submit a review
Customer Images
Showing
1
-
1 of
1 review
Showing All
Filter By:
-
Application: Immunohistochemistry-FrozenSample Tested: PFA-fixed cryosections of mouse brainSpecies: MouseVerified Customer | Posted 07/10/2018Immunohistochemistry on 14um adult mouse brain sections, 100x confocal imaging. Mitochondria are labeled.This tissue was fixed in 4% PFA, and cryosectioned. Antigen retrieval was performed in boiling 10mM citric acid (pH6) for 15 min, followed by block in 5% goat serum (PBS/ 0.3% triton) and incubated in primary ab (1:100) overnight at 4C in goat block. Developed with goat-anti-rabbit Alexa 488.
