SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free

Novus Biologicals | Catalog # NBP2-36573

Novus Biologicals
100% Guarantee

Key Product Details

Validated by

Biological Validation

Species Reactivity

Validated:

Human, Mouse

Cited:

Human, Mouse

Predicted:

Porcine (96%), Primate (100%), Rat (96%). Backed by our 100% Guarantee.

Applications

Validated:

Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Immunocytochemistry/ Immunofluorescence

Cited:

Immunohistochemistry-Paraffin, Western Blot

Label

Unconjugated

Antibody Source

Monoclonal Mouse IgG2b Kappa Clone # 5E6.1B4

Format

BSA Free
View all SLC31A1 Primary Antibodies »

Product Specifications

Immunogen

Two synthetic peptides made to internal sequences of human SLC31A1/CTR1 protein (sequences found between amino acids 50-150) [UniProt# O15431]

Reactivity Notes

Use in Mouse reported in scientific literature (PMID:32060280).

Clonality

Monoclonal

Host

Mouse

Isotype

IgG2b Kappa

Scientific Data Images for SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free

Western Blot: SLC31A1/CTR1 Antibody (5E6.1B4)BSA Free [NBP2-36573]

Western Blot: SLC31A1/CTR1 Antibody (5E6.1B4)BSA Free [NBP2-36573]

Western Blot: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573] - Analysis of SLC31A1/CTR1 in MCF7 and HeLa at 2 ug/ml.
Immunocytochemistry/ Immunofluorescence: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573]

Immunocytochemistry/ Immunofluorescence: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573]

Immunocytochemistry/Immunofluorescence: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573] - HepG2 cells were fixed for 10 minutes using 10% formalin and then permeabilized for 5 minutes using 1X TBS + 0.5% Triton X-100. The cells were incubated with anti SLC31A1/CTR1 (5E6.1B4) NBP2-36573 at a 1:50 dilution overnight at 4C and detected with an anti-mouse DyLight 488 (Green) at a 1:500 dilution. Actin was detected with Phalloidin 568 (Red) at a 1:200 dilution. Nuclei were counterstained with DAPI (Blue). Cells were imaged using a 40X objective.
Immunohistochemistry: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573]

Immunohistochemistry: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573]

Western Blot: SLC31A1/CTR1 Antibody (5E6.1B4)BSA Free [NBP2-36573]

Western Blot: SLC31A1/CTR1 Antibody (5E6.1B4)BSA Free [NBP2-36573]

Immunohistochemistry-Paraffin: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573]

Immunohistochemistry-Paraffin: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573]

Immunohistochemistry-Paraffin: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573] - Analysis of a formalin fixed and paraffin embedded tissue section of human urinary bladder transitional cell carcinoma (NBP2-30234) using purified CTR1/SLC31A1 antibody clone 5E6.1B4 at 5 ug/ml concentration.
Immunohistochemistry-Paraffin: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573]

Immunohistochemistry-Paraffin: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573]

Immunohistochemistry-Paraffin: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573] - Analysis of a FFPE tissue section of normal breast tissue from a human breast cancer patient (NBP2-30234) using purified CTR1/SLC31A1 antibody clone 5E6.1B4 at 5 ug/ml concentration. The antibody generated a very strong cytoplasmic staining in the myo-epithelial cells in the tested section.
Immunohistochemistry-Paraffin: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573]

Immunohistochemistry-Paraffin: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573]

Immunohistochemistry-Paraffin: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573] - Analysis of a FFPE tissue section of normal skin from a human breast cancer patient (NBP2-30234) using purified CTR1/SLC31A1 antibody clone 5E6.1B4 at 5 ug/ml concentration. The antibody developed a strong cytoplasmic staining in the outer layer of stratum spinosum and the cells of stratum granulosum/ granular layer of skin epidermis. The endothelial cells in the dermis of the section also showed positivity for SLC31A1/CTR1.
Immunohistochemistry-Paraffin: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573]

Immunohistochemistry-Paraffin: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573]

Immunohistochemistry-Paraffin: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573] - Aanalysis of a FFPE tissue section of human small bowel malignant stromal tumor (NBP2-30234) using purified CTR1/SLC31A1 antibody clone 5E6.1B4 at 5 ug/ml concentration. The cancer cells developed moderate to strong positivity for CTR1/SLC31A1 protein.

Applications for SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free

Application
Recommended Usage

Immunocytochemistry/ Immunofluorescence

1:50

Immunohistochemistry

5 ug/ml

Immunohistochemistry-Paraffin

5 ug/ml

Western Blot

2 ug/ml

Formulation, Preparation, and Storage

Purification

Protein G purified

Formulation

PBS

Format

BSA Free

Preservative

0.05% Sodium Azide

Concentration

1.0 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: SLC31A1

SLC31A1/CTR1 (solute carrier family 31 member 1/copper transporter 1) is a homotrimeric high-affinity, saturable copper importer implicated in dietary copper uptake. Homeostasis of copper is tightly controlled by inter-regulatory circuitry containing copper, Sp1, and CTR1, wherein Sp1 transcription factor acts as a copper sensor in modulating CTR1 expression which in turn controls cellular copper and Sp1 levels in a 3-way mutual regulatory loop. CTR1 mediated copper uptake is time, temperature, and pH dependent and specific for reduced form of Cu (I) and copper reduction has been proposed to be caused by Steap protein family or Dcytb protein (Cybrd1) both of which are reported to possess cupric reductase activity. The intracellular localization of CTR1 is variable in different cell lines: CTR1 is localized at the plasma membrane in HEK293, CaCo-2, and A2780 cells, whereas, in other cells such as HeLa, it is predominantly localized to vesicular compartments, and variability in trafficking rates between vesicular and plasma membrane compartments has been suggested as the cause of this differential localization. Post-translational O-linked glycosylation of CTR1 protects it against proteolytic cleavage of N terminal 17-kD fragment and the biological function of this cleaved variant or protease responsible is largely unknown. Selective knockout of Ctr1 in murine intestinal epithelial cells results in severe systemic copper deficiency, ataxia, and death prior to weaning.

Long Name

Solute Carrier Family 31 Member 1

Alternate Names

COPT1, CTR1, HCTR1

Entrez Gene IDs

1317 (Human)

Gene Symbol

SLC31A1

UniProt

O15431 (Human)
