Survivin Antibody (60.11) - BSA Free

Novus Biologicals | Catalog # NB500-205

Novus Biologicals
Loading...

Key Product Details

Species Reactivity

Validated:

Human, Mouse, Rat

Cited:

Human, Mouse

Applications

Validated:

Immunohistochemistry, Immunohistochemistry-Paraffin, Immunohistochemistry-Frozen, Western Blot, ELISA, Flow Cytometry, Immunocytochemistry/ Immunofluorescence, Immunoprecipitation, Proximity Ligation Assay, Knockdown Validated

Cited:

Immunohistochemistry, Immunohistochemistry-Paraffin, Immunohistochemistry-Frozen, Western Blot, Immunocytochemistry/ Immunofluorescence, Proximity Ligation Assay

Label

Unconjugated

Antibody Source

Monoclonal Mouse IgG2a Kappa Clone # 60.11

Format

BSA Free
Loading...

Product Specifications

Immunogen

This Survivin Antibody (60.11) was developed against full length recombinant human Survivin [UniProt# O15392].

Epitope

The epitope recognized is between amino acids 57-67.

Reactivity Notes

Human reactivity reported in scientific literature (PMID: 30572639)

Localization

Cytoplasmic

Specificity

Survivin Antibody (60.11) [NB500-205] is specific for the cytoplasmic form of survivin.

Clonality

Monoclonal

Host

Mouse

Isotype

IgG2a Kappa

Theoretical MW

16 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.

Scientific Data Images for Survivin Antibody (60.11) - BSA Free

Western Blot: Survivin Antibody (60.11)Unpurified [NB500-205]

Western Blot: Survivin Antibody (60.11)Unpurified [NB500-205]

Western Blot: Survivin Antibody (60.11) - Unpurified [NB500-205] - Survivin detected in rat aorta smooth muscle cell lysate in western blot analysis using [NB500-205]. Theoretical molecular weight: 16 kDa.
Immunocytochemistry/ Immunofluorescence: Survivin Antibody (60.11) - Unpurified [NB500-205]

Immunocytochemistry/ Immunofluorescence: Survivin Antibody (60.11) - Unpurified [NB500-205]

Immunocytochemistry/Immunofluorescence: Survivin Antibody (60.11) - Unpurified [NB500-205] - HeLa cells stained with Survivin Antibody (60.11) - Unpurified [NB500-205] (Green) and detected with DyLight Fluor 488 conjugated anti-mouse IgG secondary antibody. Nuclei are counterstained with Hoechst 33258 (Blue).
Immunohistochemistry-Paraffin: Survivin Antibody (60.11) - Unpurified [NB500-205]

Immunohistochemistry-Paraffin: Survivin Antibody (60.11) - Unpurified [NB500-205]

Immunohistochemistry-Paraffin: Survivin Antibody (60.11) - Unpurified [NB500-205] - Immunohistochemical staining of formalin-fixed paraffin-embedded ovarian cancer tissue using Survivin Antibody (60.11) - Unpurified [NB500-205].
Flow Cytometry: Survivin Antibody (60.11) - Unpurified [NB500-205]

Flow Cytometry: Survivin Antibody (60.11) - Unpurified [NB500-205]

Flow Cytometry: Survivin Antibody (60.11) - Unpurified [NB500-205] - An intracellular stain was performed on A549 cells with Survivin Antibody (60.11) - Unpurified [NB500-205] and a matched isotype control. Cells were fixed with 4% PFA and then permeablized with 0.1% saponin. Cells were incubated in an antibody dilution of 1 ug/mL for 30 minutes at room temperature, followed by mouse F(ab)2 IgG (H+L) APC-conjugated secondary antibody (F0101B, R&D Systems).
Western Blot: Survivin Antibody (60.11)Unpurified [NB500-205]

Western Blot: Survivin Antibody (60.11)Unpurified [NB500-205]

Western Blot: Survivin Antibody (60.11) - Unpurified [NB500-205] - Cells were transfected with the pCMV6-ENTRY control or pCMV6-ENTRY Survivin cDNA for 48 hrs and lysed. Equivalent amounts of cell lysates (5 ug per lane) were separated by SDS-PAGE and immunoblotted with [NB500-205]. Note: theoretical molecular weight for Survivin is 16 kDa.

Applications for Survivin Antibody (60.11) - BSA Free

Application
Recommended Usage

Flow Cytometry

1:200

Immunocytochemistry/ Immunofluorescence

1:100

Immunohistochemistry-Frozen

reported in scientific literature (PMID 22841823)

Immunohistochemistry-Paraffin

reported in scientific literature (PMID 18332262)

Immunoprecipitation

1:10-1:500

Proximity Ligation Assay

reported in scientific literature (PMID 28077791)

Western Blot

reported in scientific literature (PMID 18332262)
Application Notes
This antibody weakly detects Survivin in Western blot; for this application we suggest using NB500-235 instead. The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.

Flow Cytometry Panel Builder

Bio-Techne Knows Flow Cytometry

Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.

Advanced Features

  • Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
  • Spillover Popups - Visualize the spectra of individual fluorochromes
  • Antigen Density Selector - Match fluorochrome brightness with antigen density
Build Your Panel Now

Formulation, Preparation, and Storage

Purification

Unpurified

Formulation

Ascites with PBS

Format

BSA Free

Preservative

0.05% Sodium Azide

Concentration

This product is unpurified. The exact concentration of antibody is not quantifiable.

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Aliquot and store at -20C or -80C. Avoid freeze-thaw cycles.

Background: Survivin

Survivin (BIRC5 or IAP4) is the smallest member of the inhibitor of apoptosis (IAP) proteins, containing only a single baculovirus IAP repeat (BIR) domain and lacking the C-terminal RING domain. Survivin has a theoretical molecular weight of 16.5 kDa (wild-type protein) and exists as ten splice variant forms including the most predominant isoforms, survivin-2B and surviving-DeltaEx3 (1). It also undergoes phosphorylation by PKA, Plk1, Cdk1, CKII and Aurora B at multiple sites (e.g. Serine 20 and Threonine 34, 53 and 117).

Besides being highly abundant in fetal development and expressed in proliferating adult cells such as activated T lymphocytes, erythroblasts, and self-renewing stem cells, survivin is generally absent in adult tissues. However, it is elevated in common cancers such as lung, colon, pancreas, breast and prostate where it drives proliferation, metastasis, poor prognosis, and decreased patient survival (2).

Survivin has been shown to be involved in multiple cellular processes including cell cycle progression, mitotic spindle assembly, kinetochore attachment, angiogenesis, migration, and its anti-apoptotic activity has been linked to both its monomeric and homodimeric forms. Survivin impacts the function of other IAP members, c-IAP1 and c-IAP-2, or modulates the inhibitory activity of XIAP against caspases by forming a stable complex with XIAP and HBXIP. During the intrinsic apoptotic pathway, survivin may prevent the release of mitochondrial APAF1 into the cytoplasm or hinder the association of SMAC with other IAPS, which results in prolonged cell survival (3).

References

1. Sah NK, Seniya C. (2015) Survivin splice variants and their diagnostic significance. Tumour Biol. 36(9):6623-31. PMID: 26245993

2. Lladser A, Sanhueza C, Kiessling R, Quest AF. (2011) Is survivin the potential Achilles' heel of cancer? Adv Cancer Res. 111:1-37. PMID: 21704829

3. Wheatley SP, Altieri DC. (2019) Survivin at a glance. J Cell Sci. 132(7). PMID: 30948431

Alternate Names

API4, BIRC5

Entrez Gene IDs

332 (Human); 11799 (Mouse); 64041 (Rat)

Gene Symbol

BIRC5

UniProt

Additional Survivin Products

Product Documents for Survivin Antibody (60.11) - BSA Free

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Product Specific Notices for Survivin Antibody (60.11) - BSA Free

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.

Citations for Survivin Antibody (60.11) - BSA Free

Customer Reviews for Survivin Antibody (60.11) - BSA Free

There are currently no reviews for this product. Be the first to review Survivin Antibody (60.11) - BSA Free and earn rewards!

Have you used Survivin Antibody (60.11) - BSA Free?

Submit a review and receive an Amazon gift card!

$25/€18/£15/$25CAN/¥2500 Yen for a review with an image

$10/€7/£6/$10CAN/¥1110 Yen for a review without an image

Submit a review
Amazon Gift Card

Protocols

View specific protocols for Survivin Antibody (60.11) - BSA Free (NB500-205):


Western Blot Procedure

1) HeLa whole cell lysates were heated to 70 degrees C for 10 minutes and then microfuged at room temperature.
2) 65 mg of lysate were electrophoresed (200 V) through a 4-12% NuPAGE Bis-Tris gel, for 1 hr.
3) Proteins were transferred (30 V) onto a nitrocellulose membrane for 40 minutes.
4) The membrane was incubated for 1 hr. at ~ 27 degrees C (RT) in blocking buffer [TBST / 5% nonfat milk].
5) Rinsed the membrane twice in TBS.
6) Incubated the membrane with a dilution of (NB500-205) anti-Survivin antibody, diluted in TBS + 1% BSA, overnight at 4degrees C, gently shaking.
7) Washed the membrane in TBST; 1x15 min., 3x5min.
8) Incubated the membrane with a goat anti-mouse secondary antibody, diluted in TBS + 1% BSA, gently shaking for 35 minutes at room temperature.
9) Washed the membrane in TBST; 1x15 min., 3x5min.
10) Visualized membrane by ECL (AlphaInnotech ).
NOTE: HeLa whole cell extracts (NB800-PC1) were used as a positive control for this antibody.

Find general support by application which include: protocols, troubleshooting, illustrated assays, videos and webinars.

FAQs for Survivin Antibody (60.11) - BSA Free

Showing  1 - 1 of 1 FAQ Showing All
  • Q: Can I use this antibody with species other than those listed?

    A: The species we have listed are validated and therefore have a 100% guarantee to work with this antibody. We cannot guarantee that this will work with other species.

Showing  1 - 1 of 1 FAQ Showing All
View all FAQs for Antibodies
Loading...

Associated Pathways

Apoptosis Signaling Pathway Apoptosis Signaling Pathway Thumbnail
