ATG5 Antibody (8L7X6)

Novus Biologicals | Catalog # NBP3-15854

Recombinant Monoclonal Antibody
Novus Biologicals
100% Guarantee

Key Product Details

Validated by

Knockout/Knockdown

Species Reactivity

Human, Mouse, Rat

Applications

Knockout Validated, Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, ELISA, Immunocytochemistry/ Immunofluorescence, Immunoprecipitation

Label

Unconjugated

Antibody Source

Recombinant Monoclonal Rabbit IgG Clone # 8L7X6 expressed in HEK293
View all ATG5 Primary Antibodies »

Product Specifications

Immunogen

A synthetic peptide corresponding to a sequence within amino acids 1-100 of human ATG5 (Q9H1Y0). MTDDKDVLRDVWFGRIPTCFTLYQDEITEREAEPYYLLLPRVSYLTLVTDKVKKHFQKVMRQEDISEIWFEYEGTPLKWHYPIGLLFDLLASSSALPWNI

Clonality

Monoclonal

Host

Rabbit

Isotype

IgG

Theoretical MW

32 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.

Scientific Data Images for ATG5 Antibody (8L7X6)

Western Blot: ATG5 Antibody (8L7X6) [NBP3-15854]

Western Blot: ATG5 Antibody (8L7X6) [NBP3-15854]

Western Blot: ATG5 Antibody (8L7X6) [NBP3-15854] - Western blot analysis of extracts of various cell lines, using ATG5 antibody (NBP3-15854) at 1:1000 dilution. Secondary antibody: HRP Goat Anti-Rabbit IgG (H+L) at 1:10000 dilution. Lysates/proteins: 25ug per lane. Blocking buffer: 3% nonfat dry milk in TBST. Detection: ECL Basic Kit. Exposure time: 1s.
Knockout Validated: ATG5 Antibody (8L7X6) [NBP3-15854]

Western Blot: ATG5 Antibody (8L7X6) [NBP3-15854]

Western Blot: ATG5 Antibody (8L7X6) [NBP3-15854] - Western blot analysis of extracts from normal (control) and ATG5 knockout (KO) 293T cells, using ATG5 antibody (NBP3-15854) at 1:1000 dilution. Secondary antibody: HRP Goat Anti-Rabbit IgG (H+L) at 1:10000 dilution. Lysates/proteins: 25ug per lane. Blocking buffer: 3% nonfat dry milk in TBST. Detection: ECL Basic Kit. Exposure time: 1s.
Immunoprecipitation: ATG5 Antibody (8L7X6) [NBP3-15854]

Immunoprecipitation: ATG5 Antibody (8L7X6) [NBP3-15854]

Immunoprecipitation: ATG5 Antibody (8L7X6) [NBP3-15854] - Immunoprecipitation analysis of 300ug extracts of 293T cells using 3ug ATG5 antibody (NBP3-15854). Western blot was performed from the immunoprecipitate using ATG5 (NBP3-15854) at a dilition of 1:1000.
ATG5 Antibody (8L7X6)

Immunohistochemistry: ATG5 Antibody (8L7X6) [ATG5] -

Immunohistochemistry: ATG5 Antibody (8L7X6) [ATG5] - Immunohistochemistry analysis of paraffin-embedded Human breast cancer tissue using [KO Validated] ATG5 Rabbit mAb at a dilution of 1:200 (40x lens). High pressure antigen retrieval performed with 0.01M Citrate Buffer (pH 6.0) prior to IHC staining.
ATG5 Antibody (8L7X6)

Immunocytochemistry/ Immunofluorescence: ATG5 Antibody (8L7X6) [ATG5] -

Immunocytochemistry/ Immunofluorescence: ATG5 Antibody (8L7X6) [ATG5] - Confocal imaging of paraffin-embedded Mouse colon tissue using [KO Validated] ATG5 Rabbit mAb followed by a further incubation with Cy3 Goat Anti-Rabbit IgG (H+L). DAPI was used for nuclear staining (Blue). High pressure antigen retrieval performed with 0.01M Citrate Buffer (pH 6.0) prior to IF staining. Objective: 40x.
ATG5 Antibody (8L7X6)

Immunohistochemistry: ATG5 Antibody (8L7X6) [ATG5] -

Immunohistochemistry: ATG5 Antibody (8L7X6) [ATG5] - Immunohistochemistry analysis of paraffin-embedded Human colon tissue using [KO Validated] ATG5 Rabbit mAb at a dilution of 1:200 (40x lens). High pressure antigen retrieval performed with 0.01M Citrate Buffer (pH 6.0) prior to IHC staining.
ATG5 Antibody (8L7X6)

Immunohistochemistry: ATG5 Antibody (8L7X6) [ATG5] -

Immunohistochemistry: ATG5 Antibody (8L7X6) [ATG5] - Immunohistochemistry analysis of paraffin-embedded Human kidney tissue using [KO Validated] ATG5 Rabbit mAb at a dilution of 1:200 (40x lens). High pressure antigen retrieval performed with 0.01M Citrate Buffer (pH 6.0) prior to IHC staining.
ATG5 Antibody (8L7X6)

Immunocytochemistry/ Immunofluorescence: ATG5 Antibody (8L7X6) [ATG5] -

Immunocytochemistry/ Immunofluorescence: ATG5 Antibody (8L7X6) [ATG5] - Confocal imaging of paraffin-embedded Rat colon tissue using [KO Validated] ATG5 Rabbit mAb followed by a further incubation with Cy3 Goat Anti-Rabbit IgG (H+L). DAPI was used for nuclear staining (Blue). High pressure antigen retrieval performed with 0.01M Citrate Buffer (pH 6.0) prior to IF staining. Objective: 40x.
ATG5 Antibody (8L7X6)

Immunocytochemistry/ Immunofluorescence: ATG5 Antibody (8L7X6) [ATG5] -

Immunocytochemistry/ Immunofluorescence: ATG5 Antibody (8L7X6) [ATG5] - Confocal imaging of paraffin-embedded Human colon cancer tissue using [KO Validated] ATG5 Rabbit mAb followed by a further incubation with Cy3 Goat Anti-Rabbit IgG (H+L). DAPI was used for nuclear staining (Blue). High pressure antigen retrieval performed with 0.01M Citrate Buffer (pH 6.0) prior to IF staining. Objective: 40x.
ATG5 Antibody (8L7X6)

Immunohistochemistry: ATG5 Antibody (8L7X6) [ATG5] -

Immunohistochemistry: ATG5 Antibody (8L7X6) [ATG5] - Immunohistochemistry analysis of paraffin-embedded Mouse colon tissue using [KO Validated] ATG5 Rabbit mAb at a dilution of 1:200 (40x lens). High pressure antigen retrieval performed with 0.01M Citrate Buffer (pH 6.0) prior to IHC staining.
ATG5 Antibody (8L7X6)

Immunocytochemistry/ Immunofluorescence: ATG5 Antibody (8L7X6) [ATG5] -

Immunocytochemistry/ Immunofluorescence: ATG5 Antibody (8L7X6) [ATG5] - Confocal imaging of paraffin-embedded Human colon tissue using [KO Validated] ATG5 Rabbit mAb followed by a further incubation with Cy3 Goat Anti-Rabbit IgG (H+L). DAPI was used for nuclear staining (Blue). High pressure antigen retrieval performed with 0.01M Citrate Buffer (pH 6.0) prior to IF staining. Objective: 40x.
ATG5 Antibody (8L7X6)

Immunohistochemistry: ATG5 Antibody (8L7X6) [ATG5] -

Immunohistochemistry: ATG5 Antibody (8L7X6) [ATG5] - Immunohistochemistry analysis of paraffin-embedded rat colon tissue using [KO Validated] ATG5 Rabbit mAb at a dilution of 1:200 (40x lens). High pressure antigen retrieval performed with 0.01M Citrate Buffer (pH 6.0) prior to IHC staining.
ATG5 Antibody (8L7X6)

Immunohistochemistry: ATG5 Antibody (8L7X6) [ATG5] -

Immunohistochemistry: ATG5 Antibody (8L7X6) [ATG5] - Immunohistochemistry analysis of paraffin-embedded Human colon carcinoma tissue using [KO Validated] ATG5 Rabbit mAb at a dilution of 1:200 (40x lens). High pressure antigen retrieval performed with 0.01M Citrate Buffer (pH 6.0) prior to IHC staining.

Applications for ATG5 Antibody (8L7X6)

Application
Recommended Usage

ELISA

Recommended starting concentration is 1 ug/mL

Immunocytochemistry/ Immunofluorescence

1:200 - 1:400

Immunohistochemistry

1:200 - 1:2000

Immunohistochemistry-Paraffin

1:200 - 1:2000

Immunoprecipitation

0.5μg-4μg antibody for extracts of whole cells

Western Blot

1:1000 - 1:6000

Formulation, Preparation, and Storage

Purification

Affinity purified

Formulation

PBS (pH 7.3), 50% glycerol, 0.05% BSA

Preservative

0.09% Sodium Azide

Concentration

Please see the vial label for concentration. If unlisted please contact technical services.

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at -20C. Avoid freeze-thaw cycles.

Background: ATG5

Atg5, Autophagy related 5 or autophagy protein 5 (theoretical molecular weight 32 kDa), belongs to a group of core autophagy-related proteins first identified in yeast and later in eukaryotic cells. Atg proteins play essential roles in the process of macroautophagy. Atg5 is considered a core autophagy protein, for its role in the formation of the autophagosome, a double membrane vesicle which engulfs proteins and organelles for delivery to the lysosome and subsequent degradation (1). Atg5 participates in the process of phagophore elongation by interacting with the ubiquitin-like protein Atg12. Formation of the Atg12-Atg5 conjugate is dependent on the activities of Atg7 (E1 ubiquitin-activating like enzyme) and Atg10 (E2 ubiquitin-activating like enzyme). Non-covalent interaction between the Atg12-Atg5 conjugate and Atg16L1, allows for the formation of a large complex which associates with the nascent phagophore. The Atg16L1 complex dissociates from the autophagosome once it is fully formed (1,2).

In the context of its role in autophagy, Atg5 plays diverse physiologically relevant roles. For example, Atg5 together with Atg7 are required for adipogenesis (3). Recently, Atg5 has been implicated in the process of B-cell receptor polarization and antigen presentation (4). In addition to its role in autophagy, Atg5 is implicated in apoptotic cell death. Interaction of Atg5 with FADD (Fas-associated protein with death domain) is involved in cell death induced by IFN-gamma. A truncated form of Atg5, a 24kDa fragment, leads to cell death by interacting with Bcl-xl and inhibiting its anti-apoptotic activity (5). Other Atg5 interacting partners include interleukin-beta (IL-beta) converting enzyme and nucleotide binding oligomerization domain protein 1, which suggest that Atg5 may play other biologically relevant roles (3).

References

1. Yang, Z., & Klionsky, D. J. (2010). Mammalian autophagy: Core molecular machinery and signaling regulation. Current Opinion in Cell Biology. https://doi.org/10.1016/j.ceb.2009.11.014

2. Rubinsztein, D. C., Shpilka, T., & Elazar, Z. (2012). Mechanisms of autophagosome biogenesis. Current Biology. https://doi.org/10.1016/j.cub.2011.11.034

3. Subramani, S., & Malhotra, V. (2013). Non-autophagic roles of autophagy-related proteins. EMBO Reports. https://doi.org/10.1038/embor.2012.220

4. Arbogast, F., Arnold, J., Hammann, P., Kuhn, L., Chicher, J., Murera, D., Gros, F. (2019). ATG5 is required for B cell polarization and presentation of particulate antigens. Autophagy. https://doi.org/10.1080/15548627.2018.1516327

5. Luo, S., & Rubinsztein, D. C. (2007). Atg5 and Bcl-2 provide novel insights into the interplay between apoptosis and autophagy. Cell Death and Differentiation. https://doi.org/10.1038/sj.cdd.4402149

Long Name

ATG5 Autophagy Related 5 Homolog

Alternate Names

APG5, ASP

Gene Symbol

ATG5
