Calnexin Antibody (1C2.2D11) - BSA Free

Novus Biologicals | Catalog # NBP2-36570

Novus Biologicals
Loading...

Key Product Details

Species Reactivity

Validated:

Human

Cited:

Human

Predicted:

Bovine (91%), Canine (92%), Primate (99%), Rat (90%). Backed by our 100% Guarantee.

Applications

Validated:

Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Flow (Intracellular), Immunocytochemistry/ Immunofluorescence

Cited:

Immunocytochemistry/ Immunofluorescence

Label

Unconjugated

Antibody Source

Monoclonal Mouse IgG2b Kappa Clone # 1C2.2D11

Format

BSA Free
Loading...

Product Specifications

Immunogen

Partial recombinant human Calnexin protein (between amino acids 1-300). [UniProt P27824]

Reactivity Notes

Immunogen's sequence similarity with other species: Mouse (88%), Duck (81%), Xenopus (76%)

Localization

Endoplasmic reticulum membrane, Melanosome

Marker

Endoplasmic Reticulum Membrane Marker

Clonality

Monoclonal

Host

Mouse

Isotype

IgG2b Kappa

Scientific Data Images for Calnexin Antibody (1C2.2D11) - BSA Free

Western Blot: Calnexin Antibody (1C2.2D11)BSA Free [NBP2-36570]

Western Blot: Calnexin Antibody (1C2.2D11)BSA Free [NBP2-36570]

Western Blot: Calnexin Antibody (1C2.2D11) [NBP2-36570] - Analysis of 11 kDa Partial Recombinant Human Calnexin protein with Calnexin antibody (clone 1C2.2D11) at 0.5 ug/mL.
Immunocytochemistry/ Immunofluorescence: Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Immunocytochemistry/ Immunofluorescence: Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Immunocytochemistry/Immunofluorescence: Calnexin Antibody (1C2.2D11) [NBP2-36570] - HeLa cells were fixed for 10 minutes using 10% formalin and then permeabilized for 5 minutes using 1X PBS + 0.05% Triton X-100. The cells were incubated with anti-Calnexin (1C2.2D11) conjugated to FITC [NBP2-36570F] at 10ug/mL for 1 hour at room temperature. Nuclei were counterstained with DAPI (Blue). Cells were imaged using a 40X objective.
Immunohistochemistry-Paraffin: Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Immunohistochemistry-Paraffin: Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Immunohistochemistry-Paraffin: Calnexin Antibody (1C2.2D11) [NBP2-36570] - Analysis of FFPE tissue section of normal human kidney using mouse monoclonal Calnexin antibody (clone 1C2.2D11) at 7 ug/mL concentration. The cells of Glomeruli developed strong cytoplasmic staining.
Flow (Intracellular): Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Flow (Intracellular): Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Flow (Intracellular): Calnexin Antibody (1C2.2D11) [NBP2-36570] - An intracellular stain was performed on HeLa cells with Calnexin [1C2.2D11] Antibody NBP2-36570AF594 (blue) and a matched isotype control (orange). Cells were fixed with 4% PFA and then permeabilized with 0.1% saponin. Cells were incubated in an antibody dilution of 2.5 ug/mL for 30 minutes at room temperature. Both antibodies were conjugated to Alexa Fluor 594.
Immunocytochemistry/ Immunofluorescence: Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Immunocytochemistry/ Immunofluorescence: Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Immunocytochemistry/Immunofluorescence: Calnexin Antibody (1C2.2D11) [NBP2-36570] - Calnexin (1C2.2D11) antibody was tested in HeLa cells with DyLight 488 (green). Nuclei and alpha-tubulin were counterstained with DAPI (blue) and Dylight 550 (red).
Immunohistochemistry-Paraffin: Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Immunohistochemistry-Paraffin: Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Immunohistochemistry-Paraffin: Calnexin Antibody (1C2.2D11) [NBP2-36570] - Analysis of FFPE tissue section of normal human breast using mouse monoclonal Calnexin antibody (clone 1C2.2D11) at 7 ug/mL concentration. The myoepithelial cells around the lobules depicted a very strong cytoplasmic staining.
Immunohistochemistry-Paraffin: Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Immunohistochemistry-Paraffin: Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Immunohistochemistry-Paraffin: Calnexin Antibody (1C2.2D11) [NBP2-36570] - Analysis of FFPE tissue section of malignant stromal tumor of the human small bowel using mouse monoclonal Calnexin antibody (clone 1C2.2D11) at 7 ug/mL concentration. The cancer cells showed a very strong cytoplasmic reactivity for Calnexin.
Immunohistochemistry-Paraffin: Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Immunohistochemistry-Paraffin: Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Immunohistochemistry-Paraffin: Calnexin Antibody (1C2.2D11) [NBP2-36570] - Analysis of FFPE tissue section of human placenta using mouse monoclonal Calnexin antibody (clone 1C2.2D11) at 7 ug/mL concentration.
Immunohistochemistry-Paraffin: Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Immunohistochemistry-Paraffin: Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Immunohistochemistry-Paraffin: Calnexin Antibody (1C2.2D11) [NBP2-36570] - Analysis of FFPE tissue section of human skin using mouse monoclonal Calnexin antibody (clone 1C2.2D11) at 7 ug/mL concentration. The outermost keratinocytes layer of the epidermis showed cytoplasmic positivity for Calnexin protein.
Flow (Intracellular): Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Flow (Intracellular): Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Flow (Intracellular): Calnexin Antibody (1C2.2D11) [NBP2-36570] - Intracellular staining of human Calnexin in Flow cytometry using 5.0 ug of antibody per 1 million cells. Isotype control was mouse IgG2b kappa.
Flow (Intracellular): Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Flow (Intracellular): Calnexin Antibody (1C2.2D11) - BSA Free [NBP2-36570]

Flow (Intracellular): Calnexin Antibody (1C2.2D11) [NBP2-36570] - An intracellular stain was performed on HeLa cells with Calnexin Antibody (1C2.2D11) NBP2-36570F (blue) and a matched isotype control (orange). Cells were fixed with 4% PFA and then permeabilized with 0.1% saponin. Cells were incubated in an antibody dilution of 10 ug/mL for 30 minutes at room temperature. Both antibodies were conjugated to FITC.
Calnexin Antibody (1C2.2D11) - BSA Free

Calnexin (IC2.2D11) in U-2 OS Human Cell Line.

Calnexin (IC2.2D11) was detected in immersion U-2 OS human osteosarcoma cell line using Mouse anti-Calnexin (IC2.2D11) Protein G Purified Monoclonal Antibody conjugated to Alexa Fluor® 647 (Catalog # NBP2-36570AF647) (light blue) at 10 µg/mL overnight at 4C. Cells were counterstained with DAPI (dark blue). Cells were imaged using a 100X objective and digitally deconvolved.
Calnexin Antibody (1C2.2D11) - BSA Free

Calnexin (1C2.2D11) in U-2 OS Human Cell Line.

Calnexin (1C2.2D11) was detected in immersion fixed U-2 OS human osteosarcoma cell line using Mouse anti-Calnexin (1C2.2D11) Protein G Purified Monoclonal Antibody conjugated to FITC (Catalog # NBP2-36570F) (green) at 10 µg/mL overnight at 4C. Cells were counterstained with DAPI (blue). Cells were imaged using a 100X objective and digitally deconvolved.

Applications for Calnexin Antibody (1C2.2D11) - BSA Free

Application
Recommended Usage

Flow (Intracellular)

5 ug/million cells

Immunocytochemistry/ Immunofluorescence

10 ug/ml

Immunohistochemistry

7 ug/ml

Immunohistochemistry-Paraffin

7 ug/ml

Flow Cytometry Panel Builder

Bio-Techne Knows Flow Cytometry

Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.

Advanced Features

  • Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
  • Spillover Popups - Visualize the spectra of individual fluorochromes
  • Antigen Density Selector - Match fluorochrome brightness with antigen density
Build Your Panel Now

Formulation, Preparation, and Storage

Purification

Protein G purified

Formulation

PBS

Format

BSA Free

Preservative

0.05% Sodium Azide

Concentration

1.0 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: Calnexin

Calnexin is a calcium-binding protein which interacts with newly synthesized glycoproteins in ER for facilitating protein assembly and/or the retention within ER of unassembled protein subunits as well as incorrectly folded proteins thereby playing a key role in ER's quality control apparatus. The specificity of calnexin for glycoproteins is defined by a lectin site, which binds an early oligosaccharide intermediate on the folding glycoprotein. When associated with partial T-cell antigen receptor complexes which escape immature thymocytes's ER, calnexin regulates thymocyte maturation process and is also implicated in receptor-mediated endocytosis at synapses. MAPK3/ERK1 phosphorylates calnexin at Ser-565 leading to increased calnexin-ribosomal association and DHHC6 mediated calnexin palmitoylation leads to its preferential localization to perinuclear rough ER. Palmitoylation also facilitate calnexin association with RTC/ribosome-translocon complex that is essential to efficient folding of glycosylated proteins.

Alternate Names

calnexin, CNX, IP90FLJ26570, Major histocompatibility complex class I antigen-binding protein p88, P90

Entrez Gene IDs

821 (Human); 12330 (Mouse); 29144 (Rat)

Gene Symbol

CANX

UniProt

Additional Calnexin Products

Product Documents for Calnexin Antibody (1C2.2D11) - BSA Free

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Product Specific Notices for Calnexin Antibody (1C2.2D11) - BSA Free

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.

Citations for Calnexin Antibody (1C2.2D11) - BSA Free

Customer Reviews for Calnexin Antibody (1C2.2D11) - BSA Free

There are currently no reviews for this product. Be the first to review Calnexin Antibody (1C2.2D11) - BSA Free and earn rewards!

Have you used Calnexin Antibody (1C2.2D11) - BSA Free?

Submit a review and receive an Amazon gift card!

$25/€18/£15/$25CAN/¥2500 Yen for a review with an image

$10/€7/£6/$10CAN/¥1110 Yen for a review without an image

Submit a review
Amazon Gift Card

Protocols

View specific protocols for Calnexin Antibody (1C2.2D11) - BSA Free (NBP2-36570):

Calnexin Antibody (1C2.2D11):
Immunocytochemistry Protocol

Culture cells to appropriate density in 35 mm culture dishes or 6-well plates.

1. Remove culture medium and add 10% formalin to the dish. Fix at room temperature for 30 minutes.
2. Remove the formalin and add ice cold methanol. Incubate for 5-10 minutes.
3. Remove methanol and add washing solution (i.e. PBS). Be sure to not let the specimen dry out. Wash three times for 10 minutes.
4. To block nonspecific antibody binding incubate in 10% normal goat serum from 1 hour to overnight at room temperature.
5. Add primary antibody at appropriate dilution and incubate at room temperature from 2 hours to overnight at room temperature.
6. Remove primary antibody and replace with washing solution. Wash three times for 10 minutes.
7. Add secondary antibody at appropriate dilution. Incubate for 1 hour at room temperature.
8. Remove antibody and replace with wash solution, then wash for 10 minutes. Add Hoechst 33258 to wash solution at 1:25,0000 and incubate for 10 minutes. Wash a third time for 10 minutes.
9. Cells can be viewed directly after washing. The plates can also be stored in PBS containing Azide covered in Parafilm (TM). Cells can also be cover-slipped using Fluoromount, with appropriate sealing.

*The above information is only intended as a guide. The researcher should determine what protocol best meets their needs. Please follow safe laboratory procedures.

Calnexin Antibody (1C2.2D11):
1. Deparaffinize the tissue sections by immersing the slides in Xylene with two changes for 10 min each. Sections should not get dried at any stage from this point.
2. Rehydrate the tissue sections by immersing the slides in decreasing grades of ethanol as follows:
a. Immerse in 100% ethanol with 2 changes for 5 minutes each
b. Immerse in 95% ethanol with 2 changes for 5 minutes each
c. Immerse in 90% ethanol for 5 minutes
d. Immerse in 70% ethanol for 5 minutes
e. Immerse in 50% ethanol for 5 minutes
f. Immerse in distilled water for 5 minutes
3. Antigen Retrieval (Microwave Method):
a. Immerse the slides in a microwave compatible tray containing 10 mM Sodium Citrate buffer (pH 6.0) with 0.05% Tween 20.
b. Boil the slides and maintain the sub-boiling temperature for 5 minutes in the microwave. Thereafter, take out the tray very carefully and cool it at room temperature (RT) for about 30 minutes.
c. Wash the slides 3 times, 3 minutes each by immersing them in TBST (Tris Buffered Saline having 0.05% Tween 20).
4. Quenching of Endogenous Peroxidase:
a. Incubate the slides in 3% hydrogen peroxide prepared in methanol for 15 minutes (at RT, in dark conditions).
b. Wash the slides in TBST 3 times, 3 minutes each.
5. Protein Blocking:
a. Incubate the sections with background sniper solution at RT for 15 minutes (Biocare Medicals, USA).
b. Wash the sections 3 times, 3 min each by immersing the slides in TBST.
6. Primary Antibody:
a. Dilute the primary antibody at 5ug/ml concentration using PBS as a diluent.
b. Incubate the sections with diluted primary antibody for 90 minutes at RT in a humidified chamber.
c. Thereafter, wash the slides 4 times, 5 minutes each with TBST.
7. Probe (Secondary Reagent):
a. Incubate with MACH 1 Mouse probe for 15 minutes at RT.
b. Incubate for 30 min at room temperature with HRP-Polymer (Biocare Medical, USA).
c. Wash the slides with TBST 4 times, 5 minutes each
8. Chromogen:
a. Mix 32ul of DAB Chromogen with 1 ml of DAB substrate buffer (Biocare Medical, USA).
b. Apply 200ul DAB mixture/section and incubate at RT in dark conditions (few seconds - 5 minutes).
c. As soon as an appropriate color develops, rinse the slides with deionized water (2-3 brief rinses).
9. Counter stain:
a. Counter stain with Hematoxylin for 30 seconds (Vector Labs, USA).
b. Wash in deionized water for 1-2 minutes to clear the extra stain.
c. Incubate the slides in bluing solution or Scott's water twice for 2 minutes each time.
10. Dehydrate the sections in increasing grades of alcohols:
a. 50% alcohol for 1 minute
b. 70% for 1 minute
c. 90% for 1 minute
d. 95% for 1 minute
e. 100% for 1 minute
f. Xylene with 2 changes for 2 minutes each
11. Mount with DPX mount and cover-slip glass (Fisher Scientific, USA), carefully not allowing any air bubbles to enter.

NOTE:- This protocol is provided as a reference tool only. Depending upon the type of tissues /tissue processing and reagents employed, the end user will need to optimize the final conditions for achieving an expected staining.

Calnexin Antibody (1C2.2D11):
Western Blot Protocol

1. Perform SDS-PAGE on samples to be analyzed, loading 25 ug of total protein per lane.
2. Transfer proteins to membrane according to the instructions provided by the manufacturer of the membrane and transfer apparatus.
3. Stain according to standard Ponceau S procedure (or similar product) to assess transfer success, and mark molecular weight standards where appropriate.
4. Rinse the blot.
5. Block the membrane using standard blocking buffer for at least 1 hour.
6. Wash the membrane in wash buffer three times for 10 minutes each.
7. Dilute anti-Calnexin primary antibody in blocking buffer and incubate 1 hour at room temperature.
8. Wash the membrane in wash buffer three times for 10 minutes each.
9. Apply the diluted HRP conjugated secondary antibody in blocking buffer (as per manufacturers instructions) and incubate 1 hour at room temperature.
10. Wash the blot in wash buffer three times for 10 minutes each (this step can be repeated as required to reduce background).
11. Apply the detection reagent of choice in accordance with the manufacturers instructions.
Note: Tween-20 can be added to the blocking or antibody dilution buffer at a final concentration of 0.05-0.2%.

Find general support by application which include: protocols, troubleshooting, illustrated assays, videos and webinars.

FAQs

No product specific FAQs exist for this product.
