Human/Mouse/Rat PD-ECGF/Thymidine Phosphorylase Antibody

Catalog # Availability Size / Price Qty
Human/Mouse/Rat PD-ECGF/Thymidine Phosphorylase Antibody in Western Blot
2 Images
Product Details
Supplemental Products

Human/Mouse/Rat PD-ECGF/Thymidine Phosphorylase Antibody Summary

Species Reactivity
Human, Mouse, Rat
Detects mouse PD-ECGF/Thymidine Phosphorylase in direct ELISAs. Detects human, mouse, and rat PD-ECGF/Thymidine Phosphorylase in Western blots.
Monoclonal Rat IgG2B Clone # 826722
Protein A or G purified from hybridoma culture supernatant
S. frugiperda insect ovarian cell line Sf 21-derived recombinant mouse PD-ECGF/Thymidine Phosphorylase
Accession # Q99N42
Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied as a 0.2 µm filtered solution in PBS.


Recommended Concentration
Western Blot
2 µg/mL
See below
8-25 µg/mL
See below

Please Note: Optimal dilutions should be determined by each laboratory for each application. General Protocols are available in the Technical Information section on our website.

Data Examples

Western Blot Detection of Human, Mouse, and Rat PD-ECGF/Thymidine Phosphorylase by Western Blot. View Larger

Detection of Human, Mouse, and Rat PD-ECGF/Thymidine Phosphorylase by Western Blot. Western blot shows lysates of A431 human epithelial carcinoma cell line, Hepa 1-6 mouse hepatoma cell line, and H4-II-E-C3 rat hepatoma cell line. PVDF membrane was probed with 2 µg/mL of Rat Anti-Human/Mouse/Rat PD-ECGF/Thymidine Phosphorylase Monoclonal Antibody (Catalog # MAB7568) followed by HRP-conjugated Anti-Rat IgG Secondary Antibody (Catalog # HAF005). A specific band was detected for PD-ECGF/Thymidine Phosphorylase at approximately 49 kDa (as indicated). This experiment was conducted under reducing conditions and using Immunoblot Buffer Group 1.

Immunohistochemistry PD-ECGF/Thymidine Phosphorylase in Mouse Embryo. View Larger

PD-ECGF/Thymidine Phosphorylase in Mouse Embryo. PD-ECGF/Thymidine Phosphorylase was detected in immersion fixed frozen sections of mouse embryo (15 d.p.c.) using Rat Anti-Human/Mouse/Rat PD-ECGF/Thymidine Phosphorylase Monoclonal Antibody (Catalog # MAB7568) at 25 µg/mL overnight at 4 °C. Tissue was stained using the Anti-Rat HRP-DAB Cell & Tissue Staining Kit (brown; Catalog # CTS017) and counterstained with hematoxylin (blue). Specific staining was localized to developing brain. View our protocol for Chromogenic IHC Staining of Frozen Tissue Sections.

Reconstitution Calculator

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.


Preparation and Storage

Reconstitute at 0.5 mg/mL in sterile PBS.
Reconstitution Buffer Available
Reconstitution Buffer 1 (PBS)
Catalog #
Size / Price
The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below. *Small pack size (SP) is shipped with polar packs. Upon receipt, store it immediately at -20 to -70 °C
Stability & Storage
Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.

Background: PD-ECGF/Thymidine Phosphorylase

TYMP (Thymidine phosphorylase/TP; also [PD]-ECGF/platelet-derived endothelial cell growth factor, gliostatin and TdRPase) is a 50-55 kDa member of the pyrimidine-nucleoside phosphorylase family of enzymes. TYMP/TP is both a cytosolic and secreted molecule that is expressed by a variety of cell types, including, macrophages, hepatocytes, endometrial gland epithelium, vascular smooth muscle and endothelial cells. It has also been found in select tumor cell types, and via an angiogenic activity, has been proposed to promote tumor growth. TYMP converts thymidine to thymine and 2-deoxy-ribose-1P, and it is the 2-deoxy-ribose component that is believed to promote endothelial cell migration (but not proliferation). This may be due to the fact that 2-deoxy-ribose induces reactive oxygen species, which drive the production of angiogenic factors, and that 2-deoxy-ribose also activates endothelial cell integrins. Mouse TYMP is 471 amino acids (aa) in length. It contains a phosphorylase domain (aa 96-348), followed by a C-terminal region (aa 374-448). Although TYMP circulates, there is no definitive signal sequence. TYMP is known to form homodimers. Full-length mouse TYMP (aa 1-471) shares 80% and 92% aa sequence identity with human and rat TYMP, respectively.

Long Name
Platelet-derived Endothelial Cell Growth Factor
Entrez Gene IDs
1890 (Human); 72962 (Mouse)
Alternate Names
dThdPase; EC 2.4.2; EC; ECGF; ECGF1; ECGF1TP; endothelial cell growth factor 1 (platelet-derived); Gliostatin; hPD-ECGF; MEDPS1; MNGIE; MTDPS1; PDECGF; PD-ECGF; Platelet-derived endothelial cell growth factor; TdRPase; Thymidine Phosphorylase; TPase; TYMP
