MAP2 Antibody (5H11) - BSA Free

Novus Biologicals | Catalog # NBP1-92711

Novus Biologicals
100% Guarantee

Key Product Details

Species Reactivity

Validated:

Human, Mouse, Rat, Monkey

Cited:

Human, Rat

Applications

Validated:

Immunohistochemistry, Immunohistochemistry Free-Floating, Western Blot, Immunocytochemistry/ Immunofluorescence

Cited:

Immunohistochemistry-Paraffin, Immunocytochemistry/ Immunofluorescence

Label

Unconjugated

Antibody Source

Monoclonal Mouse IgG2B Clone # 5H11

Format

BSA Free
View all MAP2 Primary Antibodies »

Product Specifications

Immunogen

MAP2 Antibody (5H11) was developed against full length purified bovine protein, epitope mapped to projection domain of human sequence, amino acids 1057-1588 using MAP2 Projection Domain 3.

Reactivity Notes

Monkey reactivity reported in scientific literature (Mortazavi F et al).

Localization

Cytoskeleton

Marker

Neuronal Dendritic Marker

Specificity

Note that since the epitope for this antibody in within the projection domain found only in MAP2A and MAP2B, and so the antibody does not bind to the lower molecular weight MAP2C and MAP2D isoforms which lack this region.

Clonality

Monoclonal

Host

Mouse

Isotype

IgG2B

Theoretical MW

199 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.

Scientific Data Images for MAP2 Antibody (5H11) - BSA Free

Immunohistochemistry Free-Floating: MAP2 Antibody (5H11) [NBP1-92711]

Immunohistochemistry Free-Floating: MAP2 Antibody (5H11) [NBP1-92711]

Immunohistochemistry Free-Floating: MAP2 Antibody (5H11) [NBP1-92711] - Analysis of rat hippocampus section stained with mouse mAb to MAP2, NBP1-92711, dilution 1:5,000 in green, and costained with rabbit pAb to alpha-internexin, dilution 1:2,000 in red. Following transcardial perfusion of rat with 4% paraformaldehyde, brain was post fixed for 24 hours, cut to 45uM, and free-floating sections were stained with above antibodies. The NBP1-92711 antibody labels MAP2 protein in the perikarya and dendrites of the most neurons, and the alpha-internexin antibody selectively stains axons and dendrites of neuronal cells.
Western Blot: MAP2 Antibody (5H11) [NBP1-92711]

Western Blot: MAP2 Antibody (5H11) [NBP1-92711]

Western Blot: MAP2 Antibody (5H11) [NBP1-92711] - Analysis of different tissue lysates using mouse mAb to MAP2A/B (5H11), NBP1-92711, dilution 1:10,000 in green: [1] protein standard (red), [2] adult rat whole brain, [2] embryonic (E20) rat brain, [4] adult rat spinal cord, and [5] adult mouse brain lysate. A band observed at about 280 kDa corresponds to full length MAP2a and MAP2B protein. MAP2A/B is expressed heavily in brain particularly in cortical regions, but is a more minor component of spinal cord. Note that the epitope for this antibody in within the projection domain, and so the antibody does not bind to the lower molecular weight MAP2C and MAP2D isoforms which lack this region.
Immunocytochemistry/ Immunofluorescence: MAP2 Antibody (5H11) [NBP1-92711]

Immunocytochemistry/ Immunofluorescence: MAP2 Antibody (5H11) [NBP1-92711]

Immunocytochemistry/Immunofluorescence: MAP2 Antibody (5H11) [NBP1-92711] - Single cultured astrocytes stained with MAP2 (red) and Myelin (green). Image from a verified customer review.

Applications for MAP2 Antibody (5H11) - BSA Free

Application
Recommended Usage

Immunocytochemistry/ Immunofluorescence

1:1000

Immunohistochemistry

1:1000

Western Blot

1:10000
Application Notes
This MAP2 (5H11) antibody is useful for Immunocytochemistry/Immunofluorescence, Immunohistochemistry, and Western blot, where a band can be seen at approximately 280 kDa. ICC/IF reported in a verified customer review.

Reviewed Applications

Read 1 review rated 5 using NBP1-92711 in the following applications:

Formulation, Preparation, and Storage

Purification

Protein G purified

Formulation

50% PBS, 50% glycerol

Format

BSA Free

Preservative

5mM Sodium Azide

Concentration

1 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: MAP2

Microtubule-associated protein 2 also known as MAP2 (theoretical molecular weight 280 kDa) belongs to the MAP2/Tau family which in addition to the two neuronal forms MAP2 and Tau also includes MAP4 (1). For MAP2, four different isoforms have been identified which are produced through alternative splicing including MAP2a, MAP2b, MAP2c and MAP2d (1). MAP2 isoforms contain multiple microtubule-binding domains located near the carboxy terminal, a variably sized amino-terminal projection domain, and a conserved protein kinase A binding domain. MAP2c and MAP2d isoforms have a shorter amino-terminal projection domain, lower molecular weight and are identifiable at ~70 kDa in SDS-PAGE analysis (2,3). MAP2's carboxy terminal domain supports interactions with microtubules, actin, and intermediate filaments (2).

MAP2 isoforms are developmentally regulated and differentially expressed in neurons and some glia. MAP2c is predominantly expressed in the developing brain while the other isoforms are expressed in the adult brain. The distribution of MAP2 isoforms also varies, with MAP2a and MAP2b predominantly localized to dendrites, while MAP2c is also found in axons. Lastly, the expression of MAP2d is not limited to neurons and may be found in glia, specifically oligodendrocytes (1, 2). MAP2 isoforms associate with microtubules and mediate their interaction with actin filaments thereby playing a critical role in organizing the microtubule-actin network. In neurons, MAP2 isoforms are implicated in different processes including neurite initiation, elongation and stabilization as well as axon and dendrite formation (2). Knockout of MAP expression in animal models results in a variety of functional and structural brain defects according to the isoform affected (e.g., reduced LTP and LTD, reduced myelination, absence of corpus collosum, motor system malfunction, abnormal hippocampal dendritic morphology, abnormal synaptic plasticity) (4).

References

1. Dehmelt, L., & Halpain, S. (2005). The MAP2/Tau family of microtubule-associated proteins. Genome Biology. https://doi.org/10.1186/gb-2004-6-1-204

2. Mohan, R., & John, A. (2015). Microtubule-associated proteins as direct crosslinkers of actin filaments and microtubules. IUBMB Life. https://doi.org/10.1002/iub.1384

3. Shafit-Zagardo, B., & Kalcheva, N. (1998). Making sense of the multiple MAP-2 transcripts and their role in the neuron. Molecular Neurobiology. https://doi.org/10.1007/BF02740642

4. Tortosa, E., Kapitein, L. C., & Hoogenraad, C. C. (2016). Microtubule organization and microtubule-associated proteins (MAPs). In Dendrites: Development and Disease. https://doi.org/10.1007/978-4-431-56050-0_3

Long Name

Microtubule-associated Protein 2

Alternate Names

DKFZp686I2148, MAP-2, MAP2A, MAP2B, MAP2C, Microtubule Associated Protein 2, microtubule-associated protein 2, MTAP2

Entrez Gene IDs

4133 (Human)

Gene Symbol

MAP2

UniProt

P11137

Additional MAP2 Products

Product Documents for MAP2 Antibody (5H11) - BSA Free

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Download SDS

Product Specific Notices for MAP2 Antibody (5H11) - BSA Free

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.

Citations for MAP2 Antibody (5H11) - BSA Free

Customer Reviews for MAP2 Antibody (5H11) - BSA Free (1)

5 out of 5
1 Customer Rating
5 Stars
100%
4 Stars
0%
3 Stars
0%
2 Stars
0%
1 Stars
0%

Have you used MAP2 Antibody (5H11) - BSA Free?

Submit a review and receive an Amazon gift card!

$25/€18/£15/$25CAN/¥2500 Yen for a review with an image

$10/€7/£6/$10CAN/¥1110 Yen for a review without an image

Submit a review
Amazon Gift Card

Customer Images

Showing  1 - 1 of 1 review Showing All
Filter By:
Clear Filters X
  • Name: Anonymous
    Application: Immunofluorescence
    Sample Tested: Rat astrocytes
    Species: Mouse
    Verified Customer | Posted 04/29/2014
    Single cultured astrocytes stained with MAP2(red) and Myelin(green)
    MAP2 Antibody (5H11) - BSA Free NBP1-92711

There are no reviews that match your criteria.

Showing  1 - 1 of 1 review Showing All

Protocols

Find general support by application which include: protocols, troubleshooting, illustrated assays, videos and webinars.

FAQs

No product specific FAQs exist for this product.

View all FAQs for Antibodies
