CD40 ligand (CD40L), also known as CD154, TNFSF5, TRAP or gp39, is a 260 amino acid (aa) type II transmembrane glycoprotein belonging to the TNF family. Murine CD40L consists of a 22 aa cytoplasmic domain, a 24 aa transmembrane domain, and 214 aa extracellular domain bearing a single glycosylation site (1, 2). CD40L is expressed predominantly on activated CD4+ T lymphocytes, and also found in other types of cells, including NK cells, mast cells, basophils and eosinophils. Murine CD40L shares 78% amino acid sequence identity with human CD40L. Native bioactive soluble CD40L exists. Soluble human trimeric CD40L secreted by stimulated T cells has been shown to be generated by proteolysis in the microsomes (3). Both membrane bound and soluble CD40L induce similar effects on B cells (3, 4). The receptor of CD40L is CD40, a type I transmembrane glycoprotein belonging to the TNF receptor family. CD40 is expressed on B lymphocytes, monocytes, dendritic cells, and thymic epithelium. Although all monomeric, dimeric and trimeric forms of soluble CD40L can bind to CD40, the soluble trimeric form of CD40L has the most potent biological activity through oligomerization of cell surface CD40, a common feature of TNF receptor family members (2). The genetic defect in the hyper-IgM syndrome is due to point mutations or deletions of the gene encoding the CD40L, which prevent CD40L from interacting with CD40 (5-7). CD40L mediates a range of activities on B cells including induction of activation-associated surface antigen, entry into the cell cycle, isotype switching, Ig secretion, and memory generation (8, 9). CD40-CD40L interaction also plays important roles in monocyte activation and dendritic cell maturation (10).
Mouse CD40 Ligand/TNFSF5 Antibody
R&D Systems | Catalog # AF1163
Key Product Details
Species Reactivity
Validated:
Mouse
Cited:
Human, Mouse
Applications
Validated:
Western Blot, Neutralization, Immunocytochemistry
Cited:
Immunohistochemistry-Paraffin, Western Blot, Neutralization, Immunocytochemistry, ELISA Development
Label
Unconjugated
Antibody Source
Polyclonal Goat IgG
Loading...
Product Specifications
Immunogen
Mouse myeloma cell line NS0-derived recombinant mouse CD40 Ligand/TNFSF5
Glu61-Leu260
Accession # P27548
Glu61-Leu260
Accession # P27548
Specificity
Detects mouse CD40 Ligand/TNFSF5 in Western blots.
Clonality
Polyclonal
Host
Goat
Isotype
IgG
Endotoxin Level
<0.10 EU per 1 μg of the antibody by the LAL method.
Scientific Data Images for Mouse CD40 Ligand/TNFSF5 Antibody
CD40 Ligand/TNFSF5 in Transfected CHO-S (positive) and wild type (negative) cells.
CD40 Ligand/TNFSF5 was detected in immersion fixed transfected CHO-S (positive) and wild type (negative) cells using Goat Anti-Mouse CD40 Ligand/TNFSF5 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF1163) at 5 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Anti-Goat IgG Secondary Antibody (red; Catalog # NL001) and counterstained with DAPI (blue). Specific staining was localized to cytoplasm. View our protocol for Fluorescent ICC Staining of Non-adherent Cells.Proliferation Induced by CD40 Ligand/TNFSF5 and Neutralization by Mouse CD40 Ligand/TNFSF5 Antibody.
Recombinant Mouse CD40 Ligand/TNFSF5 (Catalog # 8230-CL) induces proliferation in mouse splenic B cells in a dose-dependent manner (orange line), as measured by Resazurin (Catalog # AR002). Proliferation elicited by Recombinant Mouse CD40 Ligand/TNFSF5 (0.5 ng/mL) is neutralized (green line) by increasing concentrations of Goat Anti-Mouse CD40 Ligand/TNFSF5 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF1163). The ND50 is typically 0.08-0.4 µg/mL.Applications for Mouse CD40 Ligand/TNFSF5 Antibody
Application
Recommended Usage
Immunocytochemistry
5-15 µg/mL
Sample: Immersion fixed transfected CHO-S (positive) and wild type (negative) cells.
Sample: Immersion fixed transfected CHO-S (positive) and wild type (negative) cells.
Western Blot
0.1 µg/mL
Sample: Recombinant Mouse CD40 Ligand/TNFSF5 (Catalog # 1163-CL)
Sample: Recombinant Mouse CD40 Ligand/TNFSF5 (Catalog # 1163-CL)
Neutralization
Measured by its ability to neutralize CD40 Ligand/TNFSF5-induced proliferation in mouse splenic B cells. The Neutralization Dose (ND50) is typically 0.08-0.4 µg/mL in the presence of 0.5 ng/mL Recombinant Mouse CD40 Ligand/TNFSF5.
Formulation, Preparation, and Storage
Purification
Antigen Affinity-purified
Reconstitution
Reconstitute at 0.2 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.
Loading...
Formulation
Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.
Shipping
Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.
Stability & Storage
Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
- 12 months from date of receipt, -20 to -70 °C as supplied.
- 1 month, 2 to 8 °C under sterile conditions after reconstitution.
- 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Calculators
Background: CD40 Ligand/TNFSF5
References
- Armitage, R.J. et al. (1992) Nature 357:80.
- Hollenbaugh, D. et al. (1992) EMBO J. 11:4313.
- Fabienne, P. et al. (1996) J. Biol. Chem. 271:5965.
- Fabienne, P. et al. (1996) Eur. J. Immunol 26:725.
- Arrufo, A. et al. (1993) Cell 72:291.
- Hill, A. and N. Chapel et al. (1993) Nature 361:494.
- Korthauer, U. et al. (1993) Nature 361:539.
- Spriggs, M.K. et al. (1992) J. Exp. Med. 176:1543.
- Fanslow, W.C. et al. (1994) Seminars in Immunology 6:267.
- Kooten, C.V. and J. Banchereau (2000) J. Leukoc. Biol. 67:2.
Alternate Names
CD154, CD40L, CD40LG, gp39, TNFSF5, TRAP
Gene Symbol
CD40LG
