Mouse NCAM-1/CD56 APC-conjugated Antibody

Catalog # Availability Size / Price Qty

SAVE +FREE SHIPPING with ACADEMIA23 (See Promo Details)

Detection of NCAM‑1/CD56 in Neuro‑2A Mouse Cell Line by Flow Cytometry.
1 Image
Product Details
Citations (7)
Supplemental Products

Mouse NCAM-1/CD56 APC-conjugated Antibody Summary

Species Reactivity
Detects mouse NCAM‑1/CD56 in direct ELISAs.
Monoclonal Rat IgG2A Clone # 809220
Protein A or G purified from hybridoma culture supernatant
Mouse myeloma cell line NS0-derived recombinant mouse NCAM‑1/CD56
Accession # P13595
Supplied in a saline solution containing BSA and Sodium Azide.
Allophycocyanin (Excitation= 620-650 nm, Emission= 660-670 nm)


Recommended Concentration
Flow Cytometry
0.25-1 µg/106 cells
See below

Please Note: Optimal dilutions should be determined by each laboratory for each application. General Protocols are available in the Technical Information section on our website.

Scientific Data

Flow Cytometry Detection of NCAM-1/CD56 antibody in Neuro-2A Mouse Cell Line antibody by Flow Cytometry. View Larger

Detection of NCAM‑1/CD56 in Neuro‑2A Mouse Cell Line by Flow Cytometry. Neuro-2A mouse neuroblastoma cell line was stained with Rat Anti-Mouse NCAM-1/CD56 APC-conjugated Monoclonal Antibody (Catalog # FAB7820A, filled histogram) or isotype control antibody (Catalog # IC006A, open histogram). View our protocol for Staining Membrane-associated Proteins.

Reconstitution Calculator

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.


Preparation and Storage

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage
Protect from light. Do not freeze.
  • 12 months from date of receipt, 2 to 8 °C as supplied.

Background: NCAM-1/CD56

NCAM-1 (Neural adhesion molecule-1; also CD56) is a 120-190 kDa glycoprotein member of the Ig Superfamily. It is expressed on multiple cell types, both in the embryo and adult. Here, it serves as both an adhesion molecule and a receptor for multiple ligands, including as FGFR, PDGF, GDNF and agrin. On the cell surface, it is a cis-oriented homodimer that can form homodimers in-trans with other cis-homodimers. In the embryo, NCAM-1 is polysialylated (PolySia), and shows a MW of 200-220 kDa in SDS-PAGE. This polysialylation reduces the ability of NCAM-1 to dimerize. Mature mouse NCAM-1 is a 1096 amino acid (aa) type I transmembrane (TM) protein (aa 20-1115). It possesses a 692 aa extracellular region (aa 20-711) and a 386 aa cytoplasmic domain. The extracellular region contains five consecutive C2-type Ig-like domains (aa 20-492) followed by two FN type-III domains (aa 497-692). Multiple splice variants exist. There is a 140 kDa TM variant that shows a deletion of aa 810-1076, and a 120 kDa variant that is GPI-linked and shows a 24 aa substitution for aa 702-1115. A third potential variant contains a five aa substitution for aa 601-1115. Over aa 20-711, mouse NCAM-1 shares 99% and 95% aa identity with rat and human NCAM-1, respectively.

Long Name
Neural Cell Adhesion Molecule
Entrez Gene IDs
4684 (Human); 17967 (Mouse); 24586 (Rat)
Alternate Names
CD56 / NCAM-1; CD56 antigen; CD56; MSK39; NCAM1; N-CAM-1; NCAM-1; NCAMantigen recognized by monoclonal 5.1H11; neural cell adhesion molecule 1; neural cell adhesion molecule, NCAM

Product Datasheets

You must select a language.


Citations for Mouse NCAM-1/CD56 APC-conjugated Antibody

R&D Systems personnel manually curate a database that contains references using R&D Systems products. The data collected includes not only links to publications in PubMed, but also provides information about sample types, species, and experimental conditions.

7 Citations: Showing 1 - 7
Filter your results:

Filter by:

  1. In vivo study of the immune response to bioengineered spider silk spheres
    Authors: T Deptuch, K Penderecka, M Kaczmarek, S Molenda, H Dams-Kozlo
    Scientific Reports, 2022-08-05;12(1):13480.
    Species: Mouse
    Sample Types: Whole Cells
    Applications: Flow Cytometry
  2. A conserved YAP/Notch/REST network controls the neuroendocrine cell fate in the lungs
    Authors: YT Shue, AP Drainas, NY Li, SM Pearsall, D Morgan, N Sinnott-Ar, SQ Hipkins, GL Coles, JS Lim, AE Oro, KL Simpson, C Dive, J Sage
    Nature Communications, 2022-05-16;13(1):2690.
    Species: Mouse
    Sample Types: Whole Tissue
    Applications: Flow Cytometry
  3. STRAP regulates alternative splicing fidelity during lineage commitment of mouse embryonic stem cells
    Authors: L Jin, Y Chen, DK Crossman, A Datta, T Vu, JA Mobley, MK Basu, M Scarduzio, H Wang, C Chang, PK Datta
    Nat Commun, 2020-11-23;11(1):5941.
    Species: Mouse
    Sample Types: Whole Cells
    Applications: Flow Cytometry
  4. Oncolytic virotherapy for small-cell lung cancer induces immune infiltration and prolongs survival
    Authors: P Kellish, D Shabashvil, MM Rahman, A Nawab, MV Guijarro, M Zhang, C Cao, N Moussatche, T Boyle, S Antonia, M Reinhard, C Hartzell, M Jantz, HJ Mehta, G McFadden, FJ Kaye, M Zajac-Kaye
    J. Clin. Invest., 2019-04-29;130(0):.
    Species: Mouse
    Sample Types: Whole Cells
    Applications: Flow Cytometry
  5. CNS-derived extracellular vesicles from superoxide dismutase 1 (SOD1)G93A ALS mice originate from astrocytes and neurons and carry misfolded SOD1
    Authors: JM Silverman, D Christy, CC Shyu, KM Moon, S Fernando, Z Gidden, CM Cowan, Y Ban, RG Stacey, LI Grad, L McAlary, IR Mackenzie, LJ Foster, NR Cashman
    J. Biol. Chem., 2019-01-11;0(0):.
    Species: Mouse
    Sample Types: Microvesicles
    Applications: Flow Cytometry
  6. GDF10 is a signal for axonal sprouting and functional recovery after stroke.
    Authors: Li S, Nie E, Yin Y, Benowitz L, Tung S, Vinters H, Bahjat F, Stenzel-Poore M, Kawaguchi R, Coppola G, Carmichael S
    Nat Neurosci, 2015-10-26;18(12):1737-45.
    Species: Mouse
    Sample Types: Tissue Homogenates
    Applications: Flow Cytometry
  7. Neuronal transgene expression in dominant-negative SNARE mice.
    Authors: Fujita T, Chen M, Li B, Smith N, Peng W, Sun W, Toner M, Kress B, Wang L, Benraiss A, Takano T, Wang S, Nedergaard M
    J Neurosci, 2014-12-10;34(50):16594-604.
    Species: Mouse
    Sample Types: Whole Cells
    Applications: Flow Cytometry
