VEGFR2/KDR/Flk-1 Antibody - BSA Free
Novus Biologicals | Catalog # NB100-529
Key Product Details
Species Reactivity
Validated:
Human, Mouse
Predicted:
Rat (100%). Backed by our 100% Guarantee.
Applications
Western Blot, Immunocytochemistry/ Immunofluorescence
Label
Unconjugated
Antibody Source
Polyclonal Rabbit IgG
Format
BSA Free
Loading...
Product Specifications
Immunogen
A synthetic peptide made to an internal region of the mouse VEGF Receptor 2 protein (between residues 1200-1300). [Swiss-Prot: P35918]
Localization
Type 1 membrane protein
Marker
Endothelial Cell Marker
Clonality
Polyclonal
Host
Rabbit
Isotype
IgG
Theoretical MW
150 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.
Scientific Data Images for VEGFR2/KDR/Flk-1 Antibody - BSA Free
Western Blot: VEGFR2/KDR/Flk-1 Antibody [NB100-529]
Western Blot: VEGF R2/KDR/Flk-1 Antibody [NB100-529] - Detection of VEGF R2/KDR/Flk-1 doublet in VEGFA induced HUVEC cell lysate (50 ug) using NB100-529 (4 ug/mL). ECL detection 2.5 minutes.Immunocytochemistry/ Immunofluorescence: VEGFR2/KDR/Flk-1 Antibody [NB100-529]
Immunocytochemistry/Immunofluorescence: VEGF R2/KDR/Flk-1 Antibody [NB100-529] - The VEGF R2/KDR/Flk-1antibody was tested in V6.5 mouse embryonic stem cells (NBP1-41162) with DyLight 488 (Green). Alpha-tubulin and nuclei were counterstained with DyLight 550 (Red) and DAPI (Blue), respectively.Western Blot: VEGFR2/KDR/Flk-1 Antibody [NB100-529]
Western Blot: VEGF R2/KDR/Flk-1 Antibody [NB100-529] - Detection of VEGF R2/KDR/Flk-1 doublet in CSF-1 receptor/VEGF Receptor 2 chimera transfected lysate (20 ug) using NB100-529 (6 ug/mL). ECL detection 30 seconds.Applications for VEGFR2/KDR/Flk-1 Antibody - BSA Free
Application
Recommended Usage
Immunocytochemistry/ Immunofluorescence
1:50 - 1:500
Western Blot
1:250 - 1:1000
Application Notes
In Western blot, a doublet is seen at ~150 kDa. In ICC/IF, membrane staining can be seen in V6.5 mouse embryonic stem cells (cat# NBP1-41162).
Formulation, Preparation, and Storage
Purification
Immunogen affinity purified
Formulation
Tris-Glycine, 0.15 M NaCl
Format
BSA Free
Preservative
0.05% Sodium Azide
Concentration
1.0 mg/ml
Shipping
The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage
Store at 4C. Do not freeze.
Background: VEGFR2/KDR/Flk-1
Long Name
Vascular Endothelial Growth Factor Receptor 2
Alternate Names
CD309, Flk-1, Flk1, KDR, KRD1, Ly73, VEGF R2
Gene Symbol
KDR
Additional VEGFR2/KDR/Flk-1 Products
Product Documents for VEGFR2/KDR/Flk-1 Antibody - BSA Free
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Product Specific Notices for VEGFR2/KDR/Flk-1 Antibody - BSA Free
This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
Customer Reviews for VEGFR2/KDR/Flk-1 Antibody - BSA Free
There are currently no reviews for this product. Be the first to review VEGFR2/KDR/Flk-1 Antibody - BSA Free and earn rewards!
Have you used VEGFR2/KDR/Flk-1 Antibody - BSA Free?
Submit a review and receive an Amazon gift card!
$25/€18/£15/$25CAN/¥2500 Yen for a review with an image
$10/€7/£6/$10CAN/¥1110 Yen for a review without an image
Submit a review
Protocols
View specific protocols for VEGFR2/KDR/Flk-1 Antibody - BSA Free (NB100-529):
VEGFR2/KDR/Flk-1 Antibody:
Immunocytochemistry Protocol
Culture cells to appropriate density in 35 mm culture dishes or 6-well plates.
1. Remove culture medium and add 10% formalin to the dish. Fix at room temperature for 30 minutes.
2. Remove the formalin and add ice cold methanol. Incubate for 5-10 minutes.
3. Remove methanol and add washing solution (i.e. PBS). Be sure to not let the specimen dry out. Wash three times for 10 minutes.
4. To block nonspecific antibody binding incubate in 10% normal goat serum from 1 hour to overnight at room temperature.
5. Add primary antibody at appropriate dilution and incubate at room temperature from 2 hours to overnight at room temperature.
6. Remove primary antibody and replace with washing solution. Wash three times for 10 minutes.
7. Add secondary antibody at appropriate dilution. Incubate for 1 hour at room temperature.
8. Remove antibody and replace with wash solution, then wash for 10 minutes. Add Hoechst 33258 to wash solution at 1:25,0000 and incubate for 10 minutes. Wash a third time for 10 minutes.
9. Cells can be viewed directly after washing. The plates can also be stored in PBS containing Azide covered in Parafilm (TM). Cells can also be cover-slipped using Fluoromount, with appropriate sealing.
*The above information is only intended as a guide. The researcher should determine what protocol best meets their needs. Please follow safe laboratory procedures.
Immunocytochemistry Protocol
Culture cells to appropriate density in 35 mm culture dishes or 6-well plates.
1. Remove culture medium and add 10% formalin to the dish. Fix at room temperature for 30 minutes.
2. Remove the formalin and add ice cold methanol. Incubate for 5-10 minutes.
3. Remove methanol and add washing solution (i.e. PBS). Be sure to not let the specimen dry out. Wash three times for 10 minutes.
4. To block nonspecific antibody binding incubate in 10% normal goat serum from 1 hour to overnight at room temperature.
5. Add primary antibody at appropriate dilution and incubate at room temperature from 2 hours to overnight at room temperature.
6. Remove primary antibody and replace with washing solution. Wash three times for 10 minutes.
7. Add secondary antibody at appropriate dilution. Incubate for 1 hour at room temperature.
8. Remove antibody and replace with wash solution, then wash for 10 minutes. Add Hoechst 33258 to wash solution at 1:25,0000 and incubate for 10 minutes. Wash a third time for 10 minutes.
9. Cells can be viewed directly after washing. The plates can also be stored in PBS containing Azide covered in Parafilm (TM). Cells can also be cover-slipped using Fluoromount, with appropriate sealing.
*The above information is only intended as a guide. The researcher should determine what protocol best meets their needs. Please follow safe laboratory procedures.
VEGFR2/KDR/Flk-1 Antibody:
Western Blot Protocol
1. Perform SDS-PAGE (3-8%) on samples to be analyzed, loading 50 ug of total protein per lane.
2. Transfer proteins to Nitrocellulose according to the instructions provided by the manufacturer of the transfer apparatus.
3. Stain the blot using ponceau S for 1-2 minutes to access the transfer of proteins onto the nitrocellulose membrane. Rinse the blot in water to remove excess stain and mark the lane locations and locations of molecular weight markers using a pencil.
4. Rinse the blot in TBS for approximately 5 minutes.
5. Block the membrane using 5% non-fat dry milk + 0.5% BSA in TBS for 1 hour.
6. Dilute the rabbit anti-VEGFR2 primary antibody (NB 100-529) in blocking buffer and incubate 2 hours at room temperature.
7. Wash the membrane in water for 5 minutes and apply the diluted rabbit-IgG HRP-conjugated secondary antibody in blocking buffer (as per manufacturer's instructions) and incubate 1 hour at room temperature.
8. Wash the blot in TBS containing 0.05-0.1% Tween-20 for 10-20 minutes.
9. Wash the blot in type I water for an additional 10-20 minutes (this step can be repeated as required to reduce background).
10. Apply the detection reagent of choice in accordance with the manufacturer's instructions (Amersham's ECL is the standard reagent used at Novus Biologicals).
Note: Tween-20 can be added to the blocking buffer at a final concentration of 0.05-0.2%, provided it does not interfere with antibody-antigen binding.
Western Blot Protocol
1. Perform SDS-PAGE (3-8%) on samples to be analyzed, loading 50 ug of total protein per lane.
2. Transfer proteins to Nitrocellulose according to the instructions provided by the manufacturer of the transfer apparatus.
3. Stain the blot using ponceau S for 1-2 minutes to access the transfer of proteins onto the nitrocellulose membrane. Rinse the blot in water to remove excess stain and mark the lane locations and locations of molecular weight markers using a pencil.
4. Rinse the blot in TBS for approximately 5 minutes.
5. Block the membrane using 5% non-fat dry milk + 0.5% BSA in TBS for 1 hour.
6. Dilute the rabbit anti-VEGFR2 primary antibody (NB 100-529) in blocking buffer and incubate 2 hours at room temperature.
7. Wash the membrane in water for 5 minutes and apply the diluted rabbit-IgG HRP-conjugated secondary antibody in blocking buffer (as per manufacturer's instructions) and incubate 1 hour at room temperature.
8. Wash the blot in TBS containing 0.05-0.1% Tween-20 for 10-20 minutes.
9. Wash the blot in type I water for an additional 10-20 minutes (this step can be repeated as required to reduce background).
10. Apply the detection reagent of choice in accordance with the manufacturer's instructions (Amersham's ECL is the standard reagent used at Novus Biologicals).
Note: Tween-20 can be added to the blocking buffer at a final concentration of 0.05-0.2%, provided it does not interfere with antibody-antigen binding.
