IKK alpha Antibody (14A231) - BSA Free
Novus Biologicals | Catalog # NB100-56704
Key Product Details
Species Reactivity
Validated:
Cited:
Applications
Validated:
Cited:
Label
Antibody Source
Format
Product Specifications
Immunogen
Reactivity Notes
Clonality
Host
Isotype
Scientific Data Images for IKK alpha Antibody (14A231) - BSA Free
Immunohistochemistry-Paraffin: IKK alpha Antibody (14A231) - BSA Free [NB100-56704]
IKK-alpha-Antibody-14A231-BSA-Free-Immunohistochemistry-Paraffin-NB100-56704-img0018.jpgWestern Blot: IKK alpha Antibody (14A231)BSA Free [NB100-56704]
IKK-alpha-Antibody-14A231-BSA-Free-Western-Blot-NB100-56704-img0021.jpgFlow Cytometry: IKK alpha Antibody (14A231) - BSA Free [NB100-56704]
Flow Cytometry: IKK alpha Antibody (14A231) - BSA Free [NB100-56704] - An intracellular stain was performed on Hek293 cells with IKK alpha Antibody (14A231) NB100-56704 (blue) and a matched isotype control (orange). Cells were fixed with 4% PFA and then permeabilized with 0.1% saponin. Cells were incubated in an antibody dilution of 2.5 ug/mL for 30 minutes at room temperature, followed by Mouse IgG (H+L) Cross-Adsorbed Secondary Antibody, Dylight 550 (35503, Thermo Fisher).Western Blot: IKK alpha Antibody (14A231)BSA Free [NB100-56704]
Western Blot: IKK alpha Antibody (14A231) - BSA Free [NB100-56704] - IKK alpha Antibody (14A231) [NB100-56704] - Total protein from various Human, Mouse and Rat cell lines were separated on a 12% gel by SDS-PAGE, transferred to PVDF membrane and blocked in 5% non-fat milk in TBST. The membrane was probed with 1.0 ug/mL anti-IKK-alpha in 1% non-fat milk in TBST and detected with an anti-mouse HRP secondary antibody using chemiluminescence.Immunocytochemistry/ Immunofluorescence: IKK alpha Antibody (14A231) - BSA Free [NB100-56704]
Immunocytochemistry/Immunofluorescence: IKK alpha Antibody (14A231) - BSA Free [NB100-56704] - Antibody was tested in HeLa cells with Dylight 488 (green). Nuclei and alpha-tubulin were counterstained with DAPI (blue) and Dylight 550 (red). An antibody dilution of 1:10 was used. Image objective 40X.Immunohistochemistry: IKK alpha Antibody (14A231) - BSA Free [NB100-56704]
IKK-alpha-Antibody-14A231-BSA-Free-Immunohistochemistry-NB100-56704-img0022.jpgWestern Blot: IKK alpha Antibody (14A231)BSA Free [NB100-56704]
Western Blot: IKK alpha Antibody (14A231) - BSA Free [NB100-56704] - IKK alpha Antibody (14A231) [NB100-56704] - Analysis of IKK alpha in Daudi cell lysate using IKK alpha antibody at 1 ug/mL.Immunocytochemistry/ Immunofluorescence: IKK alpha Antibody (14A231) - BSA Free [NB100-56704]
Immunocytochemistry/Immunofluorescence: IKK alpha Antibody (14A231) - BSA Free [NB100-56704] - A431 cells were fixed for 10 minutes using 10% formalin and then permeabilized for 5 minutes using 1X PBS + 0.05% Triton X-100. The cells were incubated with anti-IKK alpha Antibody (14A231) at 2 ug/mL overnight at 4C and detected with an anti-mouse DyLight 488 (Green) at a 1:500 dilution. Actin was detected with Phalloidin 568 (Red) at a 1:200 dilution. Nuclei were counterstained with DAPI (Blue). Cells were imaged using a 40X objective.Immunocytochemistry/ Immunofluorescence: IKK alpha Antibody (14A231) - BSA Free [NB100-56704]
Immunocytochemistry/Immunofluorescence: IKK alpha Antibody (14A231) - BSA Free [NB100-56704] - HeLa cells were fixed for 10 minutes using 10% formalin and then permeabilized for 5 minutes using 1X PBS + 0.05% Triton X-100. The cells were incubated with anti-IKK alpha Antibody (14A231) at 2 ug/mL overnight at 4C and detected with an anti-mouse DyLight 488 (Green) at a 1:500 dilution. Actin was detected with Phalloidin 568 (Red) at a 1:200 dilution. Nuclei were counterstained with DAPI (Blue). Cells were imaged using a 40X objective.Immunohistochemistry-Paraffin: IKK alpha Antibody (14A231) - BSA Free [NB100-56704]
Immunohistochemistry-Paraffin: IKK alpha Antibody (14A231) - BSA Free [NB100-56704] - Analysis of a FFPE tissue section of human kidney using 1:200 dilution of IKK alpha clone 14A231 antibody. The staining was developed using HRP labeled anti-rabbit secondary antibody and DAB reagent, and nuclei of cells were counter-stained with hematoxylin.Immunohistochemistry-Paraffin: IKK alpha Antibody (14A231) - BSA Free [NB100-56704]
IKK-alpha-Antibody-14A231-BSA-Free-Immunohistochemistry-Paraffin-NB100-56704-img0020.jpgSimple Western: IKK alpha Antibody (14A231)BSA Free [NB100-56704]
Simple Western: IKK alpha Antibody (14A231) - BSA Free [NB100-56704] - IKK alpha Antibody (14A231) [NB100-56704] - Image shows a specific band for IKK alpha in 0.5 mg/mL of Daudi (left) and U937 (right) lysate. This exeriment was performed under reducing conditions using the 12-230 kDa separation system.Western Blot: IKK alpha Antibody (14A231) - BSA Free [NB100-56704] -
Western Blot: IKK alpha Antibody (14A231) - BSA Free [NB100-56704] - NEMO-Ub binding is essential for TNF alpha signaling, but not for IL-1 beta signaling.(a) Schematic illustration of NEMO deletions or point mutations. (b,c) Effects of NEMO C-terminal deletion mutants on TNF alpha & IL-1 beta signaling. NEMO−/Y MEFs were reconstituted with mock, NEMO WT or different C-terminal deletion constructs & stimulated with TNF alpha (b) or IL-1 beta (c). Effects on NF-kappa B signaling were investigated by determining I kappa B alpha phosphorylation & degradation in Western Blots as well as NF-kappa B-DNA binding by EMSA. (d,e) Effects of NEMO D311N on TNF alpha & IL-1 beta signaling. NEMO−/Y MEFs were reconstituted with mock, NEMO WT or NEMO D311N point mutant & stimulated with TNF alpha (d) or IL-1 beta (e). Analysis on NF-kappa B signaling were performed as in (b,c). Image collected & cropped by CiteAb from the following publication (https://pubmed.ncbi.nlm.nih.gov/26740240), licensed under a CC-BY license. Not internally tested by Novus Biologicals.Western Blot: IKK alpha Antibody (14A231) - BSA Free [NB100-56704] -
Western Blot: IKK alpha Antibody (14A231) - BSA Free [NB100-56704] - Expression of the transgenic IKK alpha protein in skin of C-IKK alpha & N-IKK alpha miceA. Recombinant DNA constructs employed to generate both transgenic mice lines. For C-IKK alpha mice generation, the nuclear localization signal (NLS) was removed from the sequence of the human IKK alpha cDNA employed. In the construct used for generation of the N-IKK alpha mice an extra NLS signal was added. WT IKK alpha ; wild type IKK alpha. B. Western blot of total protein extracts showing IKK alpha expression in back skin of Control & C-and N-IKK alpha mice. Actin was used as a loading control. C. Representative example of the K5 staining in back skin section of Control mice. D-E. Expression of exogenous IKK alpha protein in back skin of 1-month-old mice. Immunostaining with the NB100-56704 anti-IKK alpha antibody is showed; similar results were obtained with the H00001147-M04 IKK alpha antibody (not shown). Note the cytoplasmic expression of the transgene in the C-IKK alpha mice (D). By contrast, it is located in the nuclei of cells in the N-IKK alpha mice (E). In both types of transgenic mice the exogenous IKK alpha is expressed in basal keratinocytes (bk), in the outer root sheath of hair follicles (ORS) & in cells surrounding the sebaceous glands (sb). F. Back skin section of Control mice. The NB100-56704 antibody used does not recognize the endogenous IKK alpha in immunohistochemical assays. G. Endogenous IKK alpha expression in control mice using the IKK alpha (sc-7182) antibody. Scale bar: (C) 70 μm; (D-G) 60 μm. Image collected & cropped by CiteAb from the following publication (https://pubmed.ncbi.nlm.nih.gov/27121058), licensed under a CC-BY license. Not internally tested by Novus Biologicals.Immunohistochemistry-Paraffin: IKK alpha Antibody (14A231) - BSA Free [NB100-56704] -
Immunohistochemistry-Paraffin: IKK alpha Antibody (14A231) - BSA Free [NB100-56704] - Expression of the transgenic IKK alpha protein in skin of C-IKK alpha & N-IKK alpha miceA. Recombinant DNA constructs employed to generate both transgenic mice lines. For C-IKK alpha mice generation, the nuclear localization signal (NLS) was removed from the sequence of the human IKK alpha cDNA employed. In the construct used for generation of the N-IKK alpha mice an extra NLS signal was added. WT IKK alpha ; wild type IKK alpha. B. Western blot of total protein extracts showing IKK alpha expression in back skin of Control & C-and N-IKK alpha mice. Actin was used as a loading control. C. Representative example of the K5 staining in back skin section of Control mice. D-E. Expression of exogenous IKK alpha protein in back skin of 1-month-old mice. Immunostaining with the NB100-56704 anti-IKK alpha antibody is showed; similar results were obtained with the H00001147-M04 IKK alpha antibody (not shown). Note the cytoplasmic expression of the transgene in the C-IKK alpha mice (D). By contrast, it is located in the nuclei of cells in the N-IKK alpha mice (E). In both types of transgenic mice the exogenous IKK alpha is expressed in basal keratinocytes (bk), in the outer root sheath of hair follicles (ORS) & in cells surrounding the sebaceous glands (sb). F. Back skin section of Control mice. The NB100-56704 antibody used does not recognize the endogenous IKK alpha in immunohistochemical assays. G. Endogenous IKK alpha expression in control mice using the IKK alpha (sc-7182) antibody. Scale bar: (C) 70 μm; (D-G) 60 μm. Image collected & cropped by CiteAb from the following publication (https://pubmed.ncbi.nlm.nih.gov/27121058), licensed under a CC-BY license. Not internally tested by Novus Biologicals.Applications for IKK alpha Antibody (14A231) - BSA Free
Chromatin Immunoprecipitation
Chromatin Immunoprecipitation (ChIP)
Flow (Intracellular)
Flow Cytometry
Immunocytochemistry/ Immunofluorescence
Immunohistochemistry
Immunohistochemistry-Frozen
Immunohistochemistry-Paraffin
Immunoprecipitation
Simple Western
Western Blot
See Simple Western Antibody Database for Simple Western validation: Tested in Daudi and U937 lysate 0.5 mg/mL, separated by Size, antibody dilution of 10 ug/mL. Separated by Size-Wes, Sally Sue/Peggy Sue.
Flow Cytometry Panel Builder
Bio-Techne Knows Flow Cytometry
Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.
Advanced Features
- Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
- Spillover Popups - Visualize the spectra of individual fluorochromes
- Antigen Density Selector - Match fluorochrome brightness with antigen density
Formulation, Preparation, and Storage
Purification
Formulation
Format
Preservative
Concentration
Shipping
Stability & Storage
Background: IKK alpha
Long Name
Alternate Names
Gene Symbol
UniProt
Additional IKK alpha Products
Product Documents for IKK alpha Antibody (14A231) - BSA Free
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Product Specific Notices for IKK alpha Antibody (14A231) - BSA Free
This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
Citations for IKK alpha Antibody (14A231) - BSA Free
Customer Reviews for IKK alpha Antibody (14A231) - BSA Free
There are currently no reviews for this product. Be the first to review IKK alpha Antibody (14A231) - BSA Free and earn rewards!
Have you used IKK alpha Antibody (14A231) - BSA Free?
Submit a review and receive an Amazon gift card!
$25/€18/£15/$25CAN/¥2500 Yen for a review with an image
$10/€7/£6/$10CAN/¥1110 Yen for a review without an image
Submit a review
Protocols
View specific protocols for IKK alpha Antibody (14A231) - BSA Free (NB100-56704):
Sample Preparation.
1. Grow cells to 60-85% confluency. Flow cytometry requires between 2 x 105 and 1 x 106 cells for optimal performance.
2. If cells are adherent, harvest gently by washing once with staining buffer and then scraping. Avoid using trypsin as this can disrupt certain epitopes of interest. If enzymatic harvest is required, use Accutase, Collagenase, or TrypLE Express for a less damaging option.
3. Reserve 100 uL for counting, then transfer cell volume into a 50 mL conical tube and centrifuge for 8 minutes at 400 RCF.
a. Count cells using a hemocytometer and a 1:1 trypan blue exclusion stain to determine cell viability before starting the flow protocol. If cells appear blue, do not proceed.
4. Re-suspend cells to a concentration of 1 x 106 cells/mL in staining buffer (NBP2-26247).
5. Aliquot out 100 uL samples in accordance with your experimental samples.
Tip: When cell surface and intracellular staining are required in the same sample, it is advisable that the cell surface staining be performed first since the fixation and permeablization steps might reduce the availability of surface antigens.
Intracellular Staining.
Tip: When performing intracellular staining, it is important to use appropriate fixation and permeabilization reagents based upon the target and its subcellular location. Generally, our Intracellular Flow Assay Kit (NBP2-29450) is a good place to start as it contains an optimized combination of reagents for intracellular staining as well as an inhibitor of intracellular protein transport (necessary if staining secreted proteins). Certain targets may require more gentle or transient permeabilization protocols such as the commonly employed methanol or saponin-based methods.
Protocol for Cytoplasmic Targets:
1. Fix the cells by adding 100 uL fixation solution (such as 4% PFA) to each sample for 10-15 minutes.
2. Permeabilize cells by adding 100 uL of a permeabization buffer to every 1 x 106 cells present in the sample. Mix well and incubate at room temperature for 15 minutes.
a. For cytoplasmic targets, use a gentle permeabilization solution such as 1X PBS + 0.5% Saponin or 1X PBS + 0.5% Tween-20.
b. To maintain the permeabilized state throughout your experiment, use staining buffer + 0.1% of the permeabilization reagent (i.e. 0.1% Tween-20 or 0.1% Saponin).
3. Following the 15 minute incubation, add 2 mL of the staining buffer + 0.1% permeabilizer to each sample.
4. Centrifuge for 1 minute at 400 RCF.
5. Discard supernatant and re-suspend in 100 uL of staining buffer + 0.1% permeabilizer.
6. Add appropriate amount of each antibody (eg. 1 test or 1 ug per sample, as experimentally determined).
7. Mix well and incubate at room temperature for 30 minutes- 1 hour. Gently mix samples every 10-15 minutes.
8. Following the primary/conjugate incubation, add 1-2 mL/sample of staining buffer +0.1% permeabilizer and centrifuge for 1 minute at 400 RCF.
9. Wash twice by re-suspending cells in staining buffer (2 mL for tubes or 200 uL for wells) and centrifuging at 400 RCF for 5 minutes. Discard supernatant.
10. Add appropriate amount of secondary antibody (as experimentally determined) to each sample.
11. Incubate at room temperature in dark for 20 minutes.
12. Add 1-2 mL of staining buffer and centrifuge at 400 RCF for 1 minute and discard supernatant.
13. Wash twice by re-suspending cells in staining buffer (2 mL for tubes or 200 uL for wells) and centrifuging at 400 RCF for 5 minutes. Discard supernatant.
14. Resuspend in an appropriate volume of staining buffer (usually 500 uL per sample) and proceed with analysis on your flow cytometer.
Culture cells to appropriate density in 35 mm culture dishes or 6-well plates.
1. Remove culture medium and wash the cells briefly in PBS. Add 10% formalin to the dish and fix at room temperature for 10 minutes.
2. Remove the formalin and wash the cells in PBS.
3. Permeablize the cells with 0.1% Triton X100 or other suitable detergent for 10 min.
4. Remove the permeablization buffer and wash three times for 10 minutes each in PBS. Be sure to not let the specimen dry out.
5. To block nonspecific antibody binding, incubate in 10% normal goat serum from 1 hour to overnight at room temperature.
6. Add primary antibody at appropriate dilution and incubate overnight at 4C.
7. Remove primary antibody and replace with PBS. Wash three times for 10 minutes each.
8. Add secondary antibody at appropriate dilution. Incubate for 1 hour at room temperature.
9. Remove secondary antibody and replace with PBS. Wash three times for 10 minutes each.
10. Counter stain DNA with DAPi if required.
Antigen Unmasking:
Bring slides to a boil in 10 mM sodium citrate buffer (pH 6.0) then maintain at a sub-boiling temperature for 10 minutes. Cool slides on bench-top for 30 minutes (keep slides in the sodium citrate buffer all the time).
Staining:
1. Wash sections in deionized water three times for 5 minutes each.
2. Wash sections in PBS for 5 minutes.
3. Block each section with 100-400 ul blocking solution (1% BSA in PBS) for 1 hour at room temperature.
4. Remove blocking solution and add 100-400 ul diluted primary antibody. Incubate overnight at 4 C.
5. Remove antibody solution and wash sections in wash buffer three times for 5 minutes each.
6. Add 100-400 ul HRP polymer conjugated secondary antibody. Incubate 30 minutes at room temperature.
7. Wash sections three times in wash buffer for 5 minutes each.
8. Add 100-400 ul DAB substrate to each section and monitor staining closely.
9. As soon as the sections develop, immerse slides in deionized water.
10. Counterstain sections in hematoxylin.
11. Wash sections in deionized water two times for 5 minutes each.
12. Dehydrate sections.
13. Mount coverslips.
1. Perform SDS-PAGE on samples to be analyzed, loading 10-25 ug of total protein per lane.
2. Transfer proteins to PVDF membrane according to the instructions provided by the manufacturer of the membrane and transfer apparatus.
3. Stain the membrane with Ponceau S (or similar product) to assess transfer success, and mark molecular weight standards where appropriate.
4. Rinse the blot TBS -0.05% Tween 20 (TBST).
5. Block the membrane in 5% Non-fat milk in TBST (blocking buffer) for at least 1 hour.
6. Wash the membrane in TBST three times for 10 minutes each.
7. Dilute primary antibody in blocking buffer and incubate overnight at 4C with gentle rocking.
8. Wash the membrane in TBST three times for 10 minutes each.
9. Incubate the membrane in diluted HRP conjugated secondary antibody in blocking buffer (as per manufacturer's instructions) for 1 hour at room temperature.
10. Wash the blot in TBST three times for 10 minutes each (this step can be repeated as required to reduce background).
11. Apply the detection reagent of choice in accordance with the manufacturers instructions.
