Ephrin-B2, also known as Htk-L, ELF-2, LERK-5, and NLERK-1 (1), is a member of the ephrin ligand family which binds members of the Eph receptor family. All ligands share a conserved extracellular sequence, which most likely corresponds to the receptor binding domain. This conserved sequence consists of approximately 125 amino acids and includes four invariant cysteines. The B-class ligands are transmembrane proteins which can become tyrosine phosphorylated upon receptor ligation. The cytoplasmic domains are approximately 80 amino acids long and are highly conserved, especially the last 33 amino acids. Several signaling molecules have been shown to interact with the cytoplasmic region, although specific signaling roles have yet to be elucidated. Ephrin-B2 has been shown to bind EphA4, EphB1, EphB2, EphB3, and EphB4 (2, 3). The extracellular domains of murine and human Ephrin-B2 share 98% amino acid identity. Only membrane-bound or Fc-clustered ligands are capable of activating the receptor in vitro. While soluble monomeric ligands bind the receptor, they do not induce receptor autophosphorylation and activation (2). In vivo, the ligands and receptors display reciprocal expression (3). It has been found that nearly all the receptors and ligands are expressed in developing and adult neural tissue (3). The Ephrin/Eph families also appear to play a role in angiogenesis (3).
Mouse Ephrin‑B2 Biotinylated Antibody
R&D Systems | Catalog # BAF496
Key Product Details
Species Reactivity
Validated:
Mouse
Cited:
Mouse
Applications
Validated:
Immunohistochemistry, Western Blot, Immunocytochemistry
Cited:
Immunohistochemistry-Frozen, Western Blot, Flow Cytometry
Label
Biotin
Antibody Source
Polyclonal Goat IgG
Loading...
Product Specifications
Immunogen
Mouse myeloma cell line NS0-derived recombinant mouse Ephrin-B2
Arg27-Ala227
Accession # AAA82934
Arg27-Ala227
Accession # AAA82934
Specificity
Detects mouse Ephrin-B2 in Western blots. In Western blots, less than 5% cross-reactivity with recombinant human Ephrin-A5 is observed and less than 1% cross-reactivity with recombinant mouse Ephrin-B1 is observed.
Clonality
Polyclonal
Host
Goat
Isotype
IgG
Scientific Data Images for Mouse Ephrin‑B2 Biotinylated Antibody
Ephrin-B2 in Rat Brain.
Ephrin-B2 was detected in perfusion fixed frozen sections of rat brain (trigeminal ganglia) using Goat Anti-Mouse Ephrin-B2 Biotinylated Antigen Affinity-purified Polyclonal Antibody (Catalog # BAF496) at 15 µg/mL overnight at 4 °C. Tissue was stained using the Anti-Goat HRP-DAB Cell & Tissue Staining Kit (brown; Catalog # CTS008) and counterstained with hematoxylin (blue). Lower panel shows a lack of labeling if primary antibodies are omitted and tissue is stained only with secondary antibody followed by incubation with detection reagents. View our protocol for Chromogenic IHC Staining of Frozen Tissue Sections.Ephrin‑B2 in Rat Hippocampal Neurons.
Ephrin-B2 was detected in immersion fixed rat hippocampal neurons using Goat Anti-Mouse Ephrin-B2 Biotinylated Antigen Affinity-purified Polyclonal Antibody (Catalog # BAF496) at 10 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Streptavidin (red; Catalog # NL999) and counterstained with DAPI (blue). Specific staining was localized to cytoplasm and cell surface. View our protocol for Fluorescent ICC Staining of Non-adherent Cells.Applications for Mouse Ephrin‑B2 Biotinylated Antibody
Application
Recommended Usage
Immunocytochemistry
5-15 µg/mL
Sample: Immersion fixed cultured rat hippocampal neurons
Sample: Immersion fixed cultured rat hippocampal neurons
Immunohistochemistry
5-15 µg/mL
Sample: Perfusion fixed frozen sections of rat brain (trigeminal ganglia)
Sample: Perfusion fixed frozen sections of rat brain (trigeminal ganglia)
Western Blot
0.1 µg/mL
Sample: Recombinant Mouse Ephrin-B2 Fc Chimera (Catalog # 496-EB)
Sample: Recombinant Mouse Ephrin-B2 Fc Chimera (Catalog # 496-EB)
Formulation, Preparation, and Storage
Purification
Antigen Affinity-purified
Reconstitution
Reconstitute at 0.2 mg/mL in sterile PBS.
Loading...
Formulation
Lyophilized from a 0.2 μm filtered solution in PBS with BSA as a carrier protein.
Shipping
The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage
Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
- 12 months from date of receipt, -20 to -70 °C as supplied.
- 1 month, 2 to 8 °C under sterile conditions after reconstitution.
- 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Calculators
Background: Ephrin-B2
References
- Eph Nomenclature Committee [letter]. (1997) Cell 90:403.
- Flanagan, J.G. and P. Vanderhaeghen (1998) Annu. Rev. Neurosci. 21:309.
- Pasquale, E.B. (1997) Curr. Opin. Cell Biol. 9:608.
Alternate Names
EFNB2, ELF-2, EphrinB2, Htk-L, LERK-5, NLERK-1
Gene Symbol
EFNB2
UniProt
Additional Ephrin-B2 Products
Product Documents for Mouse Ephrin‑B2 Biotinylated Antibody
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Note: Certificate of Analysis not available for kit components.
Product Specific Notices for Mouse Ephrin‑B2 Biotinylated Antibody
For research use only
