Mouse F4/80 Antibody

Catalog # Availability Size / Price Qty
Detection of F4/80/EMR1 in RAW 264.7 Mouse Cell Line by Flow Cytometry.
2 Images
Product Details
Citations (22)
Supplemental Products
Reviews (1)

Mouse F4/80 Antibody Summary

Species Reactivity
Detects mouse F4/80/EMR1.
Monoclonal Rat IgG2A Clone # 521204
Protein A or G purified from hybridoma culture supernatant
NS0 mouse myeloma cell line transfected with mouse F4/80/EMR1
Accession # Q61549
Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.


Recommended Concentration
Flow Cytometry
0.25 µg/106 cells
See below
Ready to be labeled using established conjugation methods. No BSA or other carrier proteins that could interfere with conjugation.
8-25 µg/mL
Immersion fixed and unfixed live RAW 264.7 mouse monocyte/macrophage cell line

Please Note: Optimal dilutions should be determined by each laboratory for each application. General Protocols are available in the Technical Information section on our website.

Scientific Data

Flow Cytometry Detection of F4/80/EMR1 antibody in RAW 264.7 Mouse Cell Line antibody by Flow Cytometry. View Larger

Detection of F4/80/EMR1 in RAW 264.7 Mouse Cell Line by Flow Cytometry. RAW 264.7 mouse monocyte/macrophage cell line was stained with Rat Anti-Mouse F4/80/EMR1 Monoclonal Antibody (Catalog # MAB5580, filled histogram) or isotype control antibody (MAB006, open histogram), followed by Allophycocyanin-conjugated Anti-Rat IgG F(ab')2Secondary Antibody (Catalog # F0113).

Immunocytochemistry View Larger

F4/80 in RAW 264.7 mouse monocyte/macrophage cell line. F4/80 was detected in unfixed live cells fixed RAW 264.7 mouse monocyte/macrophage cell line using Rat Anti-Mouse F4/80 Monoclonal Antibody (Catalog # MAB5580) at 8 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Anti-Rat IgG Secondary Antibody (red; NL013) and counterstained with DAPI (blue). Specific staining was localized to cytoplasm.

Reconstitution Calculator

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.


Preparation and Storage

Reconstitute at 0.5 mg/mL in sterile PBS.
The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below. *Small pack size (SP) is shipped with polar packs. Upon receipt, store it immediately at -20 to -70 °C
Stability & Storage
Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.

Background: F4/80

F4/80, also known as EMR1, is a 160 kDa extensively glycosylated protein in the EGF-TM7 family of adhesion molecules. It is primarily expressed on macrophages and dendritic cells in mouse but is restricted to eosinophils in human. F4/80 plays a role in the development of peripheral tolerance.

Entrez Gene IDs
13733 (Mouse); 316137 (Rat)
Alternate Names
ADGRE1; cell surface glycoprotein F4/80; DD7A5-; DD7A5-7; EGF-like module containing, mucin-like, hormone receptor-like sequence 1; EGF-like module receptor 1; EGF-like module-containing mucin-like hormone receptor-like 1; EGF-TM7; Emr; EMR1 hormone receptor; Emr1; F4/80; Gpf480; Ly7; Ly71; lymphocyte antigen 71; Mouse EMR1; Rat EMR1; TM7L; TM7LN3

Product Datasheets

You must select a language.


Citations for Mouse F4/80 Antibody

R&D Systems personnel manually curate a database that contains references using R&D Systems products. The data collected includes not only links to publications in PubMed, but also provides information about sample types, species, and experimental conditions.

22 Citations: Showing 1 - 10
Filter your results:

Filter by:

  1. Interleukin‑33 promotes obstructive renal injury via macrophages
    Authors: Yanlei Li, Jing Liu, Ting Yu, Bingdi Yan, Hongjun Li
    Molecular Medicine Reports
  2. Apelin-13 Attenuates Lipopolysaccharide-Induced Inflammatory Responses and Acute Lung Injury by Regulating PFKFB3-Driven Glycolysis Induced by NOX4-Dependent ROS
    Authors: Yafei Yuan, Wei Wang, Yue Zhang, Qiaohui Hong, Wenhui Huang, Lijuan Li et al.
    Journal of Inflammation Research
  3. Schwann cell-derived CXCL2 contributes to cancer pain by modulating macrophage infiltration in a mouse breast cancer model
    Authors: Y Zhang, R Sang, J Bao, Z Jiang, D Qian, Y Zhou, W Su, J Wei, L Zhao, Z Wei, Y Zhao, M Shi, G Chen
    Brain, Behavior, and Immunity, 2023-02-06;0(0):.
    Species: Mouse
    Sample Types: Whole Tissue
    Applications: IHC
  4. Melatonin Suppresses Macrophage M1 Polarization and ROS-Mediated Pyroptosis via Activating ApoE/LDLR Pathway in Influenza A-Induced Acute Lung Injury
    Authors: MM Xu, JY Kang, S Ji, YY Wei, SL Wei, JJ Ye, YG Wang, JL Shen, HM Wu, GH Fei
    Oxidative Medicine and Cellular Longevity, 2022-11-15;2022(0):2520348.
    Species: Mouse
    Sample Types: Whole Cells
    Applications: ICC
  5. Rationally designed bioactive milk-derived protein scaffolds enhanced new bone formation
    Authors: MS Lee, J Jeon, S Park, J Lim, HS Yang
    Oncogene, 2022-06-16;20(0):368-380.
    Species: Mouse
    Sample Types: Whole Tissue
    Applications: IHC
  6. Resveratrol Ameliorates Cardiac Remodeling in a Murine Model of Heart Failure With Preserved Ejection Fraction
    Authors: L Zhang, J Chen, L Yan, Q He, H Xie, M Chen
    Frontiers in Pharmacology, 2021-06-10;12(0):646240.
    Species: Mouse
    Sample Types: Whole Tissue
    Applications: IHC
  7. Interleukin-22 deficiency alleviates doxorubicin-induced oxidative stress and cardiac injury via the p38 MAPK/macrophage/Fizz3 axis in mice
    Authors: J Ye, Y Wang, Y Xu, Z Wang, L Liu, M Wang, D Ye, J Zhang, Z Yang, Y Lin, Q Ji, J Wan
    Redox Biol, 2020-07-07;36(0):101636.
    Species: Mouse
    Sample Types: Whole Tissue
    Applications: IHC
  8. Heparin inhibits pro-inflammatory and promotes anti-inflammatory macrophage polarization under hyperglycemic stress
    Authors: A Abbadi, J Loftis, A Wang, M Yu, Y Wang, S Shakya, X Li, EV Maytin, VC Hascall
    J. Biol. Chem., 2020-02-27;0(0):.
    Species: Mouse
    Sample Types: Whole Cells
    Applications: ICC
  9. Overproduction of thrombopoietin by BRAFV600E-mutated mouse hepatocytes and contribution of thrombopoietin to hepatocarcinogenesis
    Authors: H Tanaka, K Horioka, M Yamamoto, M Asari, K Okuda, K Yamazaki, K Shimizu, K Ogawa
    Cancer Sci., 2019-07-30;110(9):2748-2759.
    Species: Mouse
    Sample Types: Whole Tissue
    Applications: IHC-P
  10. Osteopontin in the host response to Leishmania amazonensis
    Authors: E Giraud, E Rouault, L Fiette, JH Colle, D Smirlis, E Melanitou
    BMC Microbiol., 2019-02-08;19(1):32.
    Species: Mouse
    Sample Types: Whole Tissue
    Applications: IHC-P
  11. Self-implantable double-layered micro-drug-reservoirs for efficient and controlled ocular drug delivery
    Authors: A Than, C Liu, H Chang, PK Duong, CMG Cheung, C Xu, X Wang, P Chen
    Nat Commun, 2018-11-06;9(1):4433.
    Species: Mouse
    Sample Types: Whole Tissue
    Applications: IHC
  12. Mannan-binding lectin deficiency exacerbates sterile liver injury in mice through enhancing hepatic neutrophil recruitment
    Authors: J Zhou, J Li, Y Yu, Y Liu, H Li, Y Liu, J Wang, L Zhang, X Lu, Z Chen, D Zuo
    J. Leukoc. Biol., 2018-10-23;0(0):.
    Species: Mouse
    Sample Types: Whole Cells
    Applications: Flow Cytometry
  13. Depletion of Nsd2-mediated histone H3K36 methylation impairs adipose tissue development and function
    Authors: L Zhuang, Y Jang, YK Park, JE Lee, S Jain, E Froimchuk, A Broun, C Liu, O Gavrilova, K Ge
    Nat Commun, 2018-05-04;9(1):1796.
    Species: Mouse
    Sample Types: Whole Tissue
    Applications: IHC
  14. Central role of myeloid MCPIP1 in protecting against LPS-induced inflammation and lung injury
    Authors: Y Li, X Huang, S Huang, H He, T Lei, F Saaoud, XQ Yu, A Melnick, A Kumar, CJ Papasian, D Fan, M Fu
    Signal Transduct Target Ther, 2017-12-08;2(0):17066.
    Species: Mouse
    Sample Types: Whole Tissue
    Applications: IHC-P
  15. Combination of Fluorescent in situ Hybridization (FISH) and Immunofluorescence Imaging for Detection of Cytokine Expression in Microglia/Macrophage Cells.
    Authors: Maria Fe Lanfran, David J Loane, Italo Mocchetti, Mark P Burns, Sonia Villapol
    Bio-Protocol, 2017-11-20;0(0):2331-8325.
    Species: Mouse
    Sample Types: Whole Tissue
    Applications: IHC
  16. MerTK cleavage limits proresolving mediator biosynthesis and exacerbates tissue inflammation
    Proc Natl Acad Sci USA, 2016-05-19;0(0):.
    Species: Mouse
    Sample Types: Whole Cells
    Applications: Flow Cytometry
  17. Macrophages as IL-25/IL-33-responsive cells play an important role in the induction of type 2 immunity.
    Authors: Yang Z, Grinchuk V, Urban J, Bohl J, Sun R, Notari L, Yan S, Ramalingam T, Keegan A, Wynn T, Shea-Donohue T, Zhao A
    Species: Mouse
    Sample Types: Whole Tissue
    Applications: IHC-Fr
  18. Extracellular adenosine signaling induces CX3CL1 expression in the brain to promote experimental autoimmune encephalomyelitis.
    J Neuroinflammation, 2012-08-10;9(0):193.
    Species: Mouse
    Sample Types: Whole Tissue
    Applications: IHC-Fr
  19. CX3CL1 expression in the conjunctiva is involved in immune cell trafficking during toxic ocular surface inflammation.
    Authors: Denoyer A, Godefroy D, Celerier I, Frugier J, Riancho L, Baudouin F, Rostene W, Baudouin C
    Mucosal Immunol, 2012-06-13;5(0):702.
    Species: Mouse
    Sample Types: Whole Tissue
    Applications: IHC-Fr
  20. Implantation and tracing of green fluorescent protein-expressing adipose-derived stem cells in peri-implant capsular fibrosis
    Authors: Bo-Yoon Park, Dirong Wu, Kyoo-Ri Kwon, Mi-Jin Kim, Tae-Gon Kim, Jun-Ho Lee et al.
    Stem Cell Research & Therapy
  21. Interleukin-6 knockout reverses macrophage differentiation imbalance and alleviates cardiac dysfunction in aging mice
    Authors: Yuan Wang, Shan Zhu, Wen Wei, Yi Tu, Chuang Chen, Junlong Song et al.
    Aging (Albany NY)
  22. p300/CBP inhibitor A-485 alleviates acute liver injury by regulating macrophage activation and polarization
    Authors: Jinjin Peng, Jiacheng Li, Jing Huang, Pan Xu, Heming Huang, Yanjun Liu et al.


No product specific FAQs exist for this product, however you may

View all Antibody FAQs

Reviews for Mouse F4/80 Antibody

Average Rating: 1 (Based on 1 Review)

5 Star
4 Star
3 Star
2 Star
1 Star

Have you used Mouse F4/80 Antibody?

Submit a review and receive an Amazon gift card.

$25/€18/£15/$25CAN/¥75 Yuan/¥1250 Yen for a review with an image

$10/€7/£6/$10 CAD/¥70 Yuan/¥1110 Yen for a review without an image

Submit a Review

Filter by:

Mouse F4/80 Antibody
By Anonymous on 12/01/2017
Application: IHC Sample Tested: Colon tissue Species: Mouse

We tried 4 difference sources and none of them, including this one, works. Our experience is that no F4/80 antibody works for FFPE samples. Although it is not uncommon to see published positive staining, those data using FFPE samples cannot be trusted.

Technical service is following up
