CHC22 (clathrin heavy chain on chromosome 22; also Clathrin Heavy Chain 2, CHL-22, CLTCL1, and CLTD) is a 170-190 kDa member of the clathrin heavy chain family of molecules. It is expressed in striated (skeletal and cardiac) muscle and adipocytes. CHC22 appears to participate in glucose transport by interacting with GLUT4 and GGA2, thus contributing to the formation of the GLUT4 storage compartment. CHC22 forms homotrimers, but does not interact with clathrin light chains. Human clathrin heavy chain 2/CHC22 is 1640 amino acids (aa) in length. It contains an N-terminal domain that mediates protein-protein interactions (aa 2-479), a flexible linker region (aa 480-523), a distal segment (aa 524-634), a "proximal" region (aa 639-1640), and a trimerization domain that mediates the formation of a non‑covalent structure (aa 1551-1640). Multiple utilized phosphorylation and acetylation sites exist. There are three potential splice forms. One possesses a seven aa substitution for aa 1620-1640, a second shows a deletion of aa 1479-1535, and a third contains a combination of the afore-mentioned variations. Over aa 1521‑1640, human CHC22 shares 60% aa identity with canine CHC22 and 73% aa identity with human CHC17. In rodent, CHC22 is not expressed as it is represented by a pseudogene.
Human Clathrin Heavy Chain 2/CHC22 Antibody
R&D Systems | Catalog # AF6948
Key Product Details
Species Reactivity
Validated:
Human
Cited:
Human
Applications
Validated:
Western Blot, Immunocytochemistry
Cited:
Western Blot
Label
Unconjugated
Antibody Source
Polyclonal Sheep IgG
Loading...
Product Specifications
Immunogen
E. coli-derived recombinant human Clathrin Heavy Chain 2/CHC22
Trp1521-Glu1640
Accession # P53675
Trp1521-Glu1640
Accession # P53675
Specificity
Detects human Clathrin Heavy Chain 2/CHC22 in direct ELISAs and Western blots. In direct ELISAs, less than 1% cross-reactivity with recombinant human CHC17 is observed.
Clonality
Polyclonal
Host
Sheep
Isotype
IgG
Scientific Data Images for Human Clathrin Heavy Chain 2/CHC22 Antibody
Detection of Human Clathrin Heavy Chain 2/CHC22 by Western Blot.
Western blot shows lysates of human testis tissue and U2OS human osteosarcoma cell line. PVDF membrane was probed with 1 µg/mL of Sheep Anti-Human Clathrin Heavy Chain 2/CHC22 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF6948) followed by HRP-conjugated Anti-Sheep IgG Secondary Antibody (Catalog # HAF016). A specific band was detected for Clathrin Heavy Chain 2/CHC22 at approximately 170 kDa (as indicated). This experiment was conducted under reducing conditions and using Immunoblot Buffer Group 1.Clathrin Heavy Chain 2/CHC22 in Human Mesenchymal Stem Cells.
Clathrin Heavy Chain 2/CHC22 was detected in immersion fixed human mesenchymal stem cells differentiated to adipocytes with Human/Mouse/Rat StemXVivo Adipogenic Supplement (Catalog # CCM011) using Sheep Anti-Human Clathrin Heavy Chain 2/CHC22 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF6948) at 10 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Anti-Sheep IgG Secondary Antibody (red; Catalog # NL010) and counterstained with DAPI (blue). Specific staining was localized to cytoplasm. View our protocol for Fluorescent ICC Staining of Cells on Coverslips.Applications for Human Clathrin Heavy Chain 2/CHC22 Antibody
Application
Recommended Usage
Immunocytochemistry
5-15 µg/mL
Sample: Immersion fixed human mesenchymal stem cells differentiated to adipocytes with Human/Mouse/Rat StemXVivo Adipogenic Supplement (Catalog # CCM011)
Sample: Immersion fixed human mesenchymal stem cells differentiated to adipocytes with Human/Mouse/Rat StemXVivo Adipogenic Supplement (Catalog # CCM011)
Western Blot
1 µg/mL
Sample: Human testis tissue and U2OS human osteosarcoma cell line
Sample: Human testis tissue and U2OS human osteosarcoma cell line
Formulation, Preparation, and Storage
Purification
Antigen Affinity-purified
Reconstitution
Sterile PBS to a final concentration of 0.2 mg/mL. For liquid material, refer to CoA for concentration.
Loading...
Formulation
Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.
Shipping
Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.
Stability & Storage
Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
- 12 months from date of receipt, -20 to -70 °C as supplied.
- 1 month, 2 to 8 °C under sterile conditions after reconstitution.
- 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Calculators
Background: Clathrin Heavy Chain 2/CHC22
Long Name
Clathrin Heavy Chain on Chromosome 22
Alternate Names
CHC22, CLH-22, CLTCL1, CLTD
Gene Symbol
CLTCL1
UniProt
