Mouse CD45 Biotinylated Antibody


  • Species Reactivity
    Mouse
  • Specificity
    Detects mouse CD45. Detects both alloantigens and all isoforms of CD45.
  • Source
    Monoclonal Rat IgG2B Clone # 30-F11
  • Purification
    Protein A or G purified from hybridoma culture supernatant
  • Immunogen
    Mouse thymus or spleen
  • Formulation
    Lyophilized from a 0.2 μm filtered solution in PBS with BSA as a carrier protein.
  • Endotoxin Level
    <0.10 EU per 1 μg of the antibody by the LAL method.
  • Label
    Biotin
Applications
  •
    Recommended
    Concentration
    Sample
  • Flow Cytometry
    0.25 µg/106 cells
    See below
  • Immunohistochemistry
    8-25 µg/mL
    See below
  • Immunoprecipitation
    Ledbetter, J.A. and L.A. Herzenberg (1979) Immunol. Rev. 47:63.
  • Complement-dependent Cytotoxicity
    Ledbetter, J.A. and L.A. Herzenberg (1979) Immunol. Rev. 47:63.
Please Note: Optimal dilutions should be determined by each laboratory for each application. General Protocols are available in the Technical Information section on our website.
Data Examples
Detection of CD45 in Mouse Splenocytes by Flow Cytometry. Mouse splenocytes were stained with Rat Anti-Mouse CD45 Biotinylated Monoclonal Antibody (Catalog # BAM114, filled histogram) or isotype control antibody (Catalog # IC013B, open histogram), followed by Streptavidin-Allophycocyanin (Catalog # F0050). View our protocol for Staining Membrane-associated Proteins.
Immunohistochemistry
CD45 in Mouse Thymus. CD45 was detected in perfusion fixed frozen sections of mouse thymus using Rat Anti-Mouse CD45 Biotinylated Monoclonal Antibody (Catalog # BAM114) at 25 µg/mL overnight at 4 °C. Tissue was stained using the Anti-Rat HRP-DAB Cell & Tissue Staining Kit (brown; Catalog # CTS017) and counterstained with hematoxylin (blue). Lower panel shows a lack of labeling if primary antibodies are omitted and tissue is stained only with secondary antibody followed by incubation with detection reagents. View our protocol for Chromogenic IHC Staining of Frozen Tissue Sections.
Preparation and Storage
  • Reconstitution
    Reconstitute at 0.5 mg/mL in sterile PBS.
  • Shipping
    The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below.
  • Stability & Storage
    Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
    • 12 months from date of receipt, -20 to -70 °C as supplied.
    • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
    • 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Background: CD45

CD45, previously called LCA (leukocyte common antigen), T200, or Ly5 in mouse, is member C of the class 1 (receptor-like) protein tyrosine phosphatase family (PTPRC) (1, 2). It is a variably glycosylated 180‑220 kDa transmembrane protein that is abundantly expressed on all nucleated cells of hematopoietic origin (1‑3). CD45 has several isoforms, expressed according to cell type, developmental stage and antigenic exposure (1‑5). The longest form, CD45RABC (called B220 in mouse), is expressed on B lymphocytes (5). The mouse CD45RABC cDNA encodes 1291 amino acids (aa), including a 23 aa signal sequence, a 541 aa extracellular domain containing the splicing region, a cysteine-rich region and two fibronectin type III domains, a 22 aa transmembrane sequence, and a 705 aa cytoplasmic domain that contains two phosphatase domains, D1 and D2. Only D1 has phosphatase activity. CD45R0 is the shortest form, lacking exons 4, 5 and 6 which encode aa 30‑169. It is expressed on memory cells, while intermediate sizes are expressed on other T cells (3, 4, 6). CD45 has been best studied in T cells, where it determines T cell receptor signaling thresholds (3, 6‑8). CD45 is moved into or out of the immunological synapse (IS) membrane microdomain depending on the relative influence of interaction with the extracellular galectin lattice or the intracellular actin cytoskeleton (9, 10). Galectin interaction can be fine-tuned by varying usage of the heavily O-glycosylated spliced regions and sialylation of N-linked carbohydrates (4, 9). Within the IS, CD45 dephosphorylates and negatively regulates the src family kinase, LCK (8‑10). In other leukocytes, CD45 influences differentiation and links immunoreceptor signaling with cytokine secretion and cell survival, partially overlapping in function with DEP-1/CD148 (11‑14). CD45 deletion causes in severe immunodeficiency, while point mutations may be associated with autoimmune disorders (6, 7).

  • References:
    1. Anderson, J.N. et al. (2004) FASEB J. 18:8.
    2. Streuli, M. et al. (1987) J. Exp. Med. 166:1548.
    3. Hermiston, M.L. et al. (2003) Annu. Rev. Immunol. 21:107.
    4. Earl, L.A. and L.G. Baum (2008) Immunol. Cell Biol. 86:608.
    5. Ralph, S.J. et al. (1987) EMBO J. 6:1251.
    6. Falahti, R. and D. Leitenberg (2008) J. Immunol. 181:6082.
    7. Tchilian, E.Z. and P.C.L. Beverley (2006) Trends Immunol. 27:146.
    8. McNiell, L. et al. (2007) Immunity 27:425.
    9. Chen, I-J. et al. (2007) J. Biol. Chem. 282:35361.
    10. Freiberg, B.A. et al. (2002) Nat. Immunol. 3:911.
    11. Zhu, J.W. et al. (2008) Immunity 28:183.
    12. Huntington, N.D. et al. (2006) Nat. Immunol. 7:190.
    13. Hesslein, D.G. et al. (2006) Proc. Natl. Acad. Sci. USA 103:7012.
    14. Cross, J.L. et al. (2008) J. Immunol. 180:8020.
  • Long Name:
    Cluster of Differentiation 45
  • Entrez Gene IDs:
    5788 (Human); 19264 (Mouse); 490255 (Canine); 100061950 (Equine)
  • Alternate Names:
    B220; CD45 antigen; CD45; CD45R; EC 3.1.3.48; LCA; L-CA; LY5; protein tyrosine phosphatase, receptor type, C; PTPRC; receptor-type tyrosine-protein phosphatase C; T200 Glycoprotein; T200 leukocyte common antigen; T200receptor type, c polypeptide
