PI 3-Kinase p85 alpha Antibody (SU04-07)

Name: PI 3-Kinase p85 alpha Antibody (SU04-07)
Brand: Novus Biologicals
SKU: NBP2-67488
Price: 449 USD
Availability: InStock

Novus Biologicals | Catalog # NBP2-67488

Submit a review

Citations (1)

Product Documents

Recombinant Monoclonal Antibody

100% Guarantee

Product Specifications
Scientific Data
Applications
Flow Cytometry
Preparation & Storage
Background
Product Documents
Specific Notices
Research Areas

Key Product Details

Species Reactivity

Human, Mouse, Rat

Applications

Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Flow Cytometry, Immunocytochemistry/ Immunofluorescence

Label

Unconjugated

Antibody Source

Recombinant Monoclonal Rabbit IgG Clone # SU04-07 expressed in HEK293

View all PI 3-Kinase p85 alpha Primary Antibodies »

Product Specifications

Immunogen

Synthetic peptide within C-terminal human PI 3-Kinase p85 alpha. (SwissProt: P27986 Human; SwissProt: P26450 Mouse; SwissProt: Q63787 Rat)

Localization

Cytoplasm, membrane, nucleus.

Clonality

Monoclonal

Host

Rabbit

Isotype

IgG

Theoretical MW

84 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.

Scientific Data Images for PI 3-Kinase p85 alpha Antibody (SU04-07)

Western Blot: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488]

Western Blot: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488] - Analysis of PI 3 Kinase p85 alpha on different lysates using anti-PI 3 Kinase p85 alpha antibody at 1/1,000 dilution. Positive control: Lane 1: MCF-7 Lane 2: Raji

Immunocytochemistry/ Immunofluorescence: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488]

Immunocytochemistry/Immunofluorescence: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488] - Staining PI 3 Kinase p85 alpha in NIH/3T3 cells (red). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.

Immunohistochemistry-Paraffin: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488]

Immunohistochemistry-Paraffin: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488] - Analysis of paraffin-embedded mouse kidney tissue using anti-PI 3 Kinase p85 alpha antibody. Counter stained with hematoxylin.

Flow Cytometry: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488]

Flow Cytometry: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488] - Analysis of HepG2 cells with PI 3 Kinase p85 alpha antibody at 1/50 dilution (red) compared with an unlabelled control (cells without incubation with primary antibody; black). Alexa Fluor 488-conjugated goat anti rabbit IgG was used as the secondary antib

Immunocytochemistry/ Immunofluorescence: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488]

Immunocytochemistry/Immunofluorescence: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488] - Staining PI 3 Kinase p85 alpha in Hela cells (red). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.

Immunocytochemistry/ Immunofluorescence: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488]

Immunocytochemistry/Immunofluorescence: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488] - Staining PI 3 Kinase p85 alpha in HepG2 cells (red). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.

Immunocytochemistry/ Immunofluorescence: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488]

Immunocytochemistry/Immunofluorescence: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488] - Staining PI 3 Kinase p85 alpha in MCF-7 cells (red). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.

Immunohistochemistry-Paraffin: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488]

Immunohistochemistry-Paraffin: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488] - Analysis of paraffin-embedded human kidney tissue using anti-PI 3 Kinase p85 alpha antibody. Counter stained with hematoxylin.

Immunohistochemistry-Paraffin: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488]

Immunohistochemistry-Paraffin: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488] - Analysis of paraffin-embedded human liver cancer tissue using anti-PI 3 Kinase p85 alpha antibody. Counter stained with hematoxylin.

Immunohistochemistry-Paraffin: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488]

Immunohistochemistry-Paraffin: PI 3-Kinase p85 alpha Antibody (SU04-07) [NBP2-67488] - Analysis of paraffin-embedded mouse heart tissue using anti-PI 3 Kinase p85 alpha antibody. Counter stained with hematoxylin.

View 7 more images

Applications for PI 3-Kinase p85 alpha Antibody (SU04-07)

Application

Recommended Usage

Flow Cytometry

1:50-1:100

Immunocytochemistry/ Immunofluorescence

1:50-1:200

Immunohistochemistry-Paraffin

1:50-1:200

Western Blot

1:1000-1:2000

Flow Cytometry Panel Builder

Bio-Techne Knows Flow Cytometry

Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.

Advanced Features

Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
Spillover Popups - Visualize the spectra of individual fluorochromes
Antigen Density Selector - Match fluorochrome brightness with antigen density

Build Your Panel Now

Formulation, Preparation, and Storage

Purification

Protein A purified

Formulation

TBS (pH7.4), 0.05% BSA, 40% Glycerol

Preservative

0.05% Sodium Azide

Concentration

1 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: PI 3-Kinase p85 alpha

Phosphatidylinositol 3-kinase (PI3K) p85 alpha is a regulatory subunit that heterodimerizes with a catalytic subunit to form a Class IA PI3K enzyme complex, which plays an important role in the immune system (1,2). The P13K pathway is involved in many diverse processes including growth, metabolism, proliferation, and survival (2). PI3Ks are typically activated by cytokine receptors and are responsible for phosphorylation of the 3'-hydroxyl group of PI and its derivatives (3). p85 alpha is one of five regulatory subunit proteins which also includes p55 alpha, p50 alpha, p85 beta, and p55 gamma, and can bind to two of the three catalytic subunits (p110 alpha or p110 delta) (1,2). p85 alpha, p55 alpha, and p50 alpha proteins are all synthesized by the same PIK3R1 gene by alternative splicing (1). Structurally, PI 3-Kinase p85 alpha contains SRC homology 3 (SH3 domain), followed by a Bcr homology (BH) domain flanked by two proline-rich regions, then a N-terminal SH2 domain, an inter-SH2 domain, and C-terminal SH2 domain (1,2). PI 3-Kinase p85 alpha protein consists of 724 amino acids (aa) in length with a theoretical molecular weight of 83.5 kDa (2,4). The primary role for the p85 subunit is interaction with cell surface receptors and acts as an adapter for the stabilization and recruitment of the p110 catalytic subunit to the plasma membrane (1,3). Additionally, p85 has been shown to function in both interleukin-2 receptor (IL2R) and erythropoietin receptor (EpoR) endocytosis (3).

The PI3K pathway functions in a broad range of cellular processes, so it is understandable that pathway dysfunction can lead to an array of diseases and disorders (2,5). Elevated PI3K signaling is a key feature of many cancers (5). PI3K pathway dysregulation has also been implicated in neurological, metabolic, and cardiovascular disorders (5). Furthermore, both overactivation or under-activation of the PI3K delta (p85 alpha subunit + p110 delta subunit) pathway has been shown to cause immunodeficiency and pathologies related to immune system dysfunction (2). Therapeutics to target the PI3K pathway and treat related cancers include PI3K inhibitors and, specifically, isoform-selective inhibitors which have a lot of promise when used as part of a combination therapy (5).

References

1. Okkenhaug, K., & Vanhaesebroeck, B. (2001). New responsibilities for the PI3K regulatory subunit p85 alpha. Science's STKE : signal transduction knowledge environment. https://doi.org/10.1126/stke.2001.65.pe1

2. Nunes-Santos, C. J., Uzel, G., & Rosenzweig, S. D. (2019). PI3K pathway defects leading to immunodeficiency and immune dysregulation. The Journal of allergy and clinical immunology. https://doi.org/10.1016/j.jaci.2019.03.017

3. Chen, P. H., Yao, H., & Huang, L. J. (2017). Cytokine Receptor Endocytosis: New Kinase Activity-Dependent and -Independent Roles of PI3K. Frontiers in endocrinology. https://doi.org/10.3389/fendo.2017.00078

4. Uniprot (P27986)

5. Fruman, D. A., Chiu, H., Hopkins, B. D., Bagrodia, S., Cantley, L. C., & Abraham, R. T. (2017). The PI3K Pathway in Human Disease. Cell. https://doi.org/10.1016/j.cell.2017.07.029

Long Name

PI 3-Kinase p85 alpha

Alternate Names

GRB1, PI 3Kinase p85 alpha, PIK3R1

Gene Symbol

PIK3R1

Additional PI 3-Kinase p85 alpha Products

Product Documents for PI 3-Kinase p85 alpha Antibody (SU04-07)

Download Product Datasheets

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Download SDS

Product Specific Notices for PI 3-Kinase p85 alpha Antibody (SU04-07)

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
