TLR9 Antibody (26C593.2) [PE]

Novus Biologicals | Catalog # NBP2-24907

Novus Biologicals
100% Guarantee

Key Product Details

Species Reactivity

Validated:

Human, Mouse, Rat, Canine, Equine, Monkey, Primate

Cited:

Human, Mouse, Canine, Primate (Rhesus monkey)

Applications

Validated:

Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Flow Cytometry, Flow (Cell Surface), Flow (Intracellular), Immunocytochemistry/ Immunofluorescence, Knockdown Validated

Cited:

Immunohistochemistry-Paraffin, Western Blot, Flow Cytometry, Flow (Cell Surface), Flow Cytometry Control

Label

PE (Excitation = 488 nm, Emission = 575 nm)

Antibody Source

Monoclonal Mouse IgG1 kappa Clone # 26C593.2
View all TLR9 Primary Antibodies »

Product Specifications

Immunogen

This antibody was developed against KLH-conjugated synthetic peptide corresponding to amino acids 268-300 of human TLR9 isoform A (Genbank accession no. AAF78037).

Reactivity Notes

Rhesus Monkey.

Clonality

Monoclonal

Host

Mouse

Isotype

IgG1 kappa

Scientific Data Images for TLR9 Antibody (26C593.2) [PE]

Flow Cytometry: TLR9 Antibody (26C593.2) [PE] [NBP2-24907] - Intracellular analysis of TLR9 in human PBMCs using 0.2 ug of this antibody. Shaded histogram represents cells without antibody; green represents a mouse IgG1-PE isotype control ; red represents anti-TLR9 antibody.
Flow Cytometry: TLR9 Antibody (26C593.2) [PE] [NBP2-24907] - Intracellular flow analysis of TLR9 in Ramos cells using 0.1 ug of antibody. Shaded histogram represents Ramos cells without antibody; green represents a mouse IgG1-PE isotype control red represents anti-TLR9 antibody.
TLR9 Antibody (26C593.2) [PE]

Immunohistochemistry: TLR9 Antibody (26C593.2) [PE] [NBP2-24907] -

Immunohistochemistry: TLR9 Antibody (26C593.2) [PE] [NBP2-24907] - The nasal epithelium expresses TLR3, TLR7, TLR9, RIG-I & MDA-5.Sections of nasal biopsies were incubated with antibodies against TLR3 (A), TLR7 (B), TLR9 (C), RIG-I (D), & MDA-5 (E) & visualized by 3, 3′-diaminobenzidine (brown). In control slides (F), N-series universal negative control reagent was used. All sections were accompanied with a square magnification. All slides were counterstained with haematoxylin (blue). The figure shows one representative biopsy out of four (3 male, 1 female). The arrows indicate positive stained cells. Image collected & cropped by CiteAb from the following publication (https://pubmed.ncbi.nlm.nih.gov/24886842), licensed under a CC-BY license. Not internally tested by Novus Biologicals.

Applications for TLR9 Antibody (26C593.2) [PE]

Application
Recommended Usage

Flow Cytometry

1ul/1 million cells

Immunocytochemistry/ Immunofluorescence

1:10-1:2000
Application Notes
Optimal dilution of this antibody should be experimentally determined.

Spectra Viewer

Plan Your Experiments

Use our spectra viewer to interactively plan your experiments, assessing multiplexing options. View the excitation and emission spectra for our fluorescent dye range and other commonly used dyes.

Spectra Viewer
Spectra Viewer

Flow Cytometry Panel Builder

Bio-Techne Knows Flow Cytometry

Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.

Advanced Features

  • Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
  • Spillover Popups - Visualize the spectra of individual fluorochromes
  • Antigen Density Selector - Match fluorochrome brightness with antigen density
Build Your Panel Now
Flow Cytometry

Formulation, Preparation, and Storage

Purification

Protein G purified

Formulation

PBS

Preservative

0.05% Sodium Azide

Concentration

Please see the vial label for concentration. If unlisted please contact technical services.

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C in the dark.

Background: TLR9

Toll-like receptors (TLRs) are evolutionarily conserved pattern-recognition molecules resembling the toll proteins that mediate antimicrobial responses in Drosophila. These proteins recognize different microbial products during infection and serve as an important link between the innate and adaptive immune responses. TLR9 forms a subfamily along with TLR7 and TLR8 that recognize viral RNA and CpG DNA sequences and are localized in intracellular acidic compartments such as the phagolysosome. Unlike other TLRs which act through adaptor molecules such as TOLLIP, TIRAP, TRIF, and MyD88 to activate various kinases and transcription factors to respond to potential infection, TLR9 is strictly dependent on MyD88.

Long Name

Toll-like Receptor 9

Alternate Names

CD289

Gene Symbol

TLR9

Additional TLR9 Products

Product Documents for TLR9 Antibody (26C593.2) [PE]

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Download SDS

Product Specific Notices for TLR9 Antibody (26C593.2) [PE]

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.

Citations for TLR9 Antibody (26C593.2) [PE]

Customer Reviews for TLR9 Antibody (26C593.2) [PE]

There are currently no reviews for this product. Be the first to review TLR9 Antibody (26C593.2) [PE] and earn rewards!

Have you used TLR9 Antibody (26C593.2) [PE]?

Submit a review and receive an Amazon gift card!

$25/€18/£15/$25CAN/¥2500 Yen for a review with an image

$10/€7/£6/$10CAN/¥1110 Yen for a review without an image

Submit a review
Amazon Gift Card

Protocols

Find general support by application which include: protocols, troubleshooting, illustrated assays, videos and webinars.

FAQs for TLR9 Antibody (26C593.2) [PE]

Showing  1 - 1 of 1 FAQ Showing All

  • Q: Is NBP2-24907 conjugated and what is it conjugated with?

    A:

    NBP2-24907 is conjugated to PE (R-Phycoerythrin). The NBP2-24729 antibody clone (26C593.2) is available in a number of formats and conjugates.

Showing  1 - 1 of 1 FAQ Showing All
View all FAQs for Antibodies
