Human DNAM-1/CD226
Antibody

Recombinant Monoclonal Antibody
Catalog # Availability Size / Price Qty
MAB10892-100
MAB10892-SP

15% Off Limited-time Savings on Your Reagents, Assays, and Kits
Now through September 27th, you can save 15% on Bio-Techne reagents, assays, and kits (including Novus, Tocris, and R&D Systems). Use promotion code SAVE15 at checkout on orders over $1,000. See terms and conditions for offer details.

DNAM-1/CD226 in Human NK cells.
2 Images
Product Details
FAQs
Supplemental Products
Reviews

Human DNAM-1/CD226
Antibody Summary

Species Reactivity
Human
Specificity
Detects human DNAM-1/CD226 in direct ELISAs.
Source
Recombinant Monoclonal Rabbit IgG Clone # 2770C
Purification
Protein A or G purified from hybridoma culture supernatant
Immunogen
Human embryonic kidney cell HEK293-derived human DNAM-1/CD226 protein
Glu19-Asn247
Accession # Q15762
Formulation
Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied as a 0.2 µm filtered solution in PBS.
Label
Unconjugated

Applications

Recommended Concentration
Sample
Immunocytochemistry
3-25 µg/mL
Immersion fixed human NK cells and human peripheral blood mononuclear cells (PBMCs)

Please Note: Optimal dilutions should be determined by each laboratory for each application. General Protocols are available in the Technical Information section on our website.

Data Examples

Immunocytochemistry View Larger

DNAM-1/CD226 in Human NK cells. DNAM-1/CD226 was detected in immersion fixed human NK cells (positive staining) and U937 human histiocytic lymphoma cell line (negative staining) using Rabbit Anti-Human DNAM-1/CD226 Monoclonal Antibody (Catalog # MAB10892) at 3 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Anti-Rabbit IgG Secondary Antibody (red; NL004) and counterstained with DAPI (blue). Specific staining was localized to cell surface and cytoplasm. Staining was performed using our protocol for Fluorescent ICC Staining of Non-adherent Cells.

Immunocytochemistry View Larger

DNAM-1/CD226 in Human PBMCs. DNAM-1/CD226 was detected in immersion fixed human peripheral blood mononuclear cells (PBMCs) (positive staining) and U937 human histiocytic lymphoma cell line (negative staining) using Rabbit Anti-Human DNAM-1/CD226 Monoclonal Antibody (Catalog # MAB10892) at 3 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Anti-Rabbit IgG Secondary Antibody (red; NL004) and counterstained with DAPI (blue). Specific staining was localized to cytoplasm. Staining was performed using our protocol for Fluorescent ICC Staining of Non-adherent Cells.

Reconstitution Calculator

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Preparation and Storage

Reconstitution
Reconstitute at 0.5 mg/mL in sterile PBS.
Reconstitution Buffer Available
Reconstitution Buffer 1 (PBS)
Catalog #
Availability
Size / Price
Qty
RB01
Shipping
The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below. *Small pack size (SP) is shipped with polar packs. Upon receipt, store it immediately at -20 to -70 °C
Stability & Storage
Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.

Background: DNAM-1/CD226

DNAX accessory molecule-1 (DNAM-1), also known as CD226, is a 65 kDa type I transmembrane glycoprotein in the immunoglobulin superfamily (1). Mature human DNAM-1 contains a 236 amino acid (aa) extracellular domain (ECD) with two Ig-like C2-set domains and a 61 aa cytoplasmic region that contains motifs for binding PDZ domains and band 4.1 family proteins (1, 2). Within the ECD, human DNAM-1 shares 50% and 52% aa sequence identity with mouse and rat DNAM-1, respectively. DNAM-1 is expressed on multiple lymphoid and myeloid cells and interacts with CD155/PVR and Nectin-2/CD112 (3, 4). Ligation of DNAM-1 promotes the activation of NK cells, CD8+ T cells, and mast cells (2-6), dendritic cell maturation, megakaryocyte and activated platelet adhesion to vascular endothelial cells, and monocyte extravasation; it inhibits the formation of osteoclasts (7-10). Platelet-endothelium interactions mediated by DNAM-1 can enable the metastasis of tumor cells to the lung (11). CD96 competes with DNAM-1 for binding to CD155 and blocks DNAM-1 mediated NK cell activation (12). In activated, but not in resting NK, T, and mast cells, the cis association of DNAM-1 with CD18 contributes to the tyrosine and serine phosphorylation of DNAM-1 during activation (6, 9, 13-15).

References
  1. Zingoni, A. et al. (2013) Front. Immunol. 3:408.
  2. Shibuya, A. et al. (1996) Immunity 4:573.
  3. Bottino, C. et al. (2003) J. Exp. Med. 198:557.
  4. Tahara-Hanaoka, S. et al. (2004) Int. Immunol. 16:533.
  5. Dardalhon, V. et al. (2005) J. Immunol. 175:1558.
  6. Bachelet, I. et al. (2006) J. Biol. Chem. 281:27190.
  7. Reymond, N. et al. (2004) J. Exp. Med. 199:1331.
  8. Kakehi, S. et al. (2007) Mol. Cell. Biochem. 301:209.
  9. Kojima, H. et al. (2003) J. Biol. Chem. 278:36748.
  10. Tahara-Hanaoka, S. et al. (2006) Blood 107:1491.
  11. Morimoto, K. et al. (2007) Oncogene 27:264.
  12. Chan, C.J. et al. (2014) Nat. Immunol. 15:431.
  13. Shibuya, K. et al. (1999) Immunity 11:615.
  14. Shibuya, K. et al. (2003) J. Exp. Med. 198:1829.
  15. Shibuya, A. et al. (1998) J. Immunol. 166:1671.
Long Name
DNAX Accessory Molecule 1
Entrez Gene IDs
10666 (Human); 225825 (Mouse); 307199 (Rat); 102117316 (Cynomolgus Monkey)
Alternate Names
CD226 antigenplatelet and T cell activation antigen 1; CD226 molecule; CD226; DNAM1; DNAM-1; DNAM1adhesion glycoprotein; DNAM-1DNAX accessory molecule-1; DNAX accessory molecule 1; PTA1; T lineage-specific activation antigen 1 antigen; TLiSA1
