NCAM-1/CD56 Antibody (JF1021)

Name: NCAM-1/CD56 Antibody (JF1021)
Brand: Novus Biologicals
SKU: NBP2-66968
Price: 479 USD
Availability: InStock

Novus Biologicals | Catalog # NBP2-66968

Submit a review

Product Documents

Recombinant Monoclonal Antibody

100% Guarantee

Product Specifications
Scientific Data
Applications
Flow Cytometry
Preparation & Storage
Background
Product Documents
Specific Notices
Research Areas

Key Product Details

Validated by

Biological Validation

Species Reactivity

Validated:

Human, Mouse, Zebrafish

Cited:

Mouse

Applications

Validated:

Multiplex Immunofluorescence, Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot, Flow Cytometry, Immunocytochemistry/ Immunofluorescence, Immunoprecipitation

Cited:

Western Blot

Label

Unconjugated

Antibody Source

Recombinant Monoclonal Rabbit IgG Clone # JF1021 expressed in HEK293

View all NCAM-1/CD56 Primary Antibodies »

Product Specifications

Immunogen

Synthetic peptide within C-terminal human NCAM-1/CD56. (SwissProt: P13591 Human; SwissProt: P13595 Mouse)

Localization

Cell membrane, Secreted.

Clonality

Monoclonal

Host

Rabbit

Isotype

IgG

Scientific Data Images for NCAM-1/CD56 Antibody (JF1021)

Western Blot: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968]

Western Blot: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968] - Analysis of NCAM-1/CD56 on human brain tissue lysates with Rabbit anti-NCAM/CD56 antibody at 1/2,000 dilution. Lysates/proteins at 20 ug/Lane. Predicted band size: 95 kDa Observed band size: 140/180 kDa Exposure time: 30 seconds; 6% SDS-PAGE gel. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody at 1/2,000 dilution was used in 5% NFDM/TBST at room temperature for 2 hours. Goat Anti-Rabbit IgG - HRP Secondary Antibody at 1:300,000 dilution was used for 1 hour at room temperature.

Immunocytochemistry/ Immunofluorescence: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968]

Immunocytochemistry/Immunofluorescence: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968] - Staining NCAM in N2A cells (red). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.

Immunohistochemistry-Paraffin: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968]

Immunohistochemistry-Paraffin: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968] - Analysis of paraffin-embedded human kidney tissue with Rabbit anti-NCAM-1/CD56 antibody washed with ddH2O and PBS, and then probed with the primary antibody at 1/200 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

Flow Cytometry: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968]

Flow Cytometry: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968] - Analysis of SH-SY-5Y cells with NCAM antibody at 1/50 dilution (red) compared with an unlabelled control (cells without incubation with primary antibody; black). Alexa Fluor 488-conjugated goat anti rabbit IgG was used as the secondary antibody.

Western Blot: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968]

Western Blot: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968] - Analysis of NCAM on different lysates using anti-NCAM antibody at 1/1,000 dilution. Positive control: Lane 1: SH-SY-5Y Lane 2: Human brain

Western Blot: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968]

Western Blot: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968] - Analysis of NCAM-1/CD56 on SH-SY5Y cell lysates with Rabbit anti-NCAM-1/CD56 antibody at 1/500 dilution. Lysates/proteins at 10 ug/Lane. Predicted band size: 95 kDa Observed band size: 120/140 kDa Exposure time: 2 minutes; 6% SDS-PAGE gel. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody at 1/500 dilution was used in 5% NFDM/TBST at room temperature for 2 hours. Goat Anti-Rabbit IgG - HRP Secondary Antibody at 1:300,000 dilution was used for 1 hour at room temperature.

Immunocytochemistry/ Immunofluorescence: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968]

Immunocytochemistry/Immunofluorescence: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968] - Staining NCAM in A549 cells (red). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.

Immunocytochemistry/ Immunofluorescence: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968]

Immunocytochemistry/Immunofluorescence: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968] - Staining NCAM in SH-SY-5Y cells (red). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.

Immunohistochemistry-Paraffin: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968]

Immunohistochemistry-Paraffin: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968] - Analysis of paraffin-embedded human tonsil tissue using anti-NCAM antibody. Counter stained with hematoxylin.

Immunohistochemistry-Paraffin: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968]

Immunohistochemistry-Paraffin: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968] - Analysis of paraffin-embedded zebrafish kidney tissue using anti-NCAM antibody. Counter stained with hematoxylin.

Immunohistochemistry-Paraffin: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968]

Immunohistochemistry-Paraffin: NCAM-1/CD56 Antibody (JF1021) [NBP2-66968] - Analysis of paraffin-embedded human tonsil tissue using anti-NCAM-1/CD56 antibody. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 8.0-8.4) for 20 minutes.The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody 1/50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

View 8 more images

Applications for NCAM-1/CD56 Antibody (JF1021)

Application

Recommended Usage

Flow Cytometry

1:50-1:100

Immunocytochemistry/ Immunofluorescence

1:50-1:200

Immunohistochemistry-Paraffin

1:50-1:200

Multiplex Immunofluorescence

1:1000

Western Blot

1:1000-1:5000

Flow Cytometry Panel Builder

Bio-Techne Knows Flow Cytometry

Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.

Advanced Features

Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
Spillover Popups - Visualize the spectra of individual fluorochromes
Antigen Density Selector - Match fluorochrome brightness with antigen density

Build Your Panel Now

Formulation, Preparation, and Storage

Purification

Protein A purified

Formulation

TBS (pH7.4), 0.05% BSA, 40% Glycerol

Preservative

0.05% Sodium Azide

Concentration

1 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: NCAM-1/CD56

NCAM, as a member of the immunoglobulin superfamily of adhesion molecules is characterized by several immunoglobulin (Ig) like domains. The extracellular part of NCAM consists of five of these Ig domains and two fibronectin type III homology regions. NCAM is encoded by a single copy gene composed of 26 exons. However, at least 20-30 distinct isoforms can be generated by alternative splicing and by posttranslational modifications, such as sialylation. During sialylation, polysialic acid (PSA) carbohydrates are attached to the extracellular part of NCAM. Through its extracellular region, NCAM mediates homophilic interactions. In addition, NCAM can also undergo heterophilic interactions by binding extracellular matrix components, such as laminin, or other cell adhesion molecules, such as integrins. NCAM is expressed on most neuroectodermal derived cell lines, tissues and neoplasm such as retinoblastoma, medulloblastoma, astrocytomas and neuroblastoma.

Long Name

Neural Cell Adhesion Molecule

Alternate Names

CD56, NCAM1

Gene Symbol

NCAM1

Additional NCAM-1/CD56 Products

Product Documents for NCAM-1/CD56 Antibody (JF1021)

Download Product Datasheets

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Download SDS

Product Specific Notices for NCAM-1/CD56 Antibody (JF1021)

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
