Mouse Interleukin 20 (IL-20) was identified by searching sequence databases for translated sequences with a signal sequence and amphipathic helices found in helical cytokines. Based on the human molecule, mouse IL-20 was discovered in a skin library. Mouse IL-20 is synthesized as a 176 amino acid (aa) precursor that contains a 24 aa signal sequence and a 152 aa mature segment. There are no N-linked glycosylation sites and it is doubtful that the native molecule is glycosylated. Although IL-20 is a distant member of the IL-10 family, it functions as a monomer. IL-20 shares less than 40% aa sequence identity with other IL-10 family members. Mouse and human IL-20 are 77% aa identical in the mature segment. IL-20 production has been found in skin and trachea. In particular, activated keratinocytes and, possibly, monocytes are reported to express IL-20. There are two heterodimeric receptor complexes for IL-20. The first complex is composed of IL-20 R alpha and IL‑20 R beta. The second complex is composed of IL-22 R and IL‑20 R beta. Whereas the IL‑22 R/IL‑20 R beta complex is shared with IL-24/mda-7, the IL‑20 R alpha /IL‑20 R beta complex is shared with both IL-19 and IL-24. Little is known about the function of IL-20. It is reported to induce the proliferation of multipotential hematopoietic progenitor cells, direct the differentiation and expansion of keratinocytes, and promote the release of proinflammatory mediators in keratinocytes and other IL-20 receptor expressing cells (1‑6).
Key Product Details
Species Reactivity
Mouse
Applications
Western Blot, Neutralization
Label
Unconjugated
Antibody Source
Polyclonal Goat IgG
Loading...
Product Specifications
Immunogen
E. coli-derived recombinant mouse IL‑20
Leu25-Leu176
Accession # Q9JKV9
Leu25-Leu176
Accession # Q9JKV9
Specificity
Detects mouse IL-20 in direct ELISAs and the Western blots. In direct ELISAs and Western blots, approximately 10% cross-reactivity with recombinant human IL-20 is observed.
Clonality
Polyclonal
Host
Goat
Isotype
IgG
Endotoxin Level
<0.10 EU per 1 μg of the antibody by the LAL method.
Scientific Data Images for Mouse IL-20 Antibody
Cell Proliferation Induced by IL‑20 and Neutralization by Mouse IL‑20 Antibody.
Recombinant Mouse IL‑20 (Catalog # 1204-ML) stimulates proliferation in the BaF3 mouse pro‑B cell line co-transfected with human IL‑20 Ra and IL‑20 R beta in a dose-dependent manner (orange line). Proliferation elicited by Recombinant Mouse IL‑20 (10 ng/mL) is neutralized (green line) by increasing concentrations of Goat Anti-Mouse IL‑20 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF1204). The ND50 is typically 0.2-0.6 µg/mL.Mouse IL-20 ELISA Standard Curve
Recombinant Mouse IL‑20 (Catalog # 1204-ML) was serially diluted and captured by Rat Anti-Mouse IL‑20 Monoclonal Antibody (Catalog # MAB12042) coated on a Clear Polystyrene Microplate (Catalog # DY990). Goat Anti-Mouse IL‑20 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF1204) was biotinylated and incubated with the protein captured on the plate. Detection of the standard curve was achieved by incubating Streptavidin-HRP (Catalog # DY998)Applications for Mouse IL-20 Antibody
Application
Recommended Usage
Western Blot
0.1 µg/mL
Sample: Recombinant Mouse IL‑20 (Catalog # 1204-ML)
Sample: Recombinant Mouse IL‑20 (Catalog # 1204-ML)
Neutralization
Measured by its ability to neutralize IL‑20-induced proliferation in the BaF3 mouse pro‑B cell line co-transfected with human IL‑20 R alpha and IL‑20 R beta. The Neutralization Dose (ND50) is typically 0.2-0.6 µg/mL in the presence of 10 ng/mL Recombinant Mouse IL‑20.
Formulation, Preparation, and Storage
Purification
Antigen Affinity-purified
Reconstitution
Reconstitute at 0.2 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.
Loading...
Formulation
Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.
Shipping
Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.
Stability & Storage
Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
- 12 months from date of receipt, -20 to -70 °C as supplied.
- 1 month, 2 to 8 °C under sterile conditions after reconstitution.
- 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Calculators
Background: IL-20
References
- Blumberg, H. et al. (2001) Cell 104:9.
- Liu, L. et al. (2003) Blood 102:3206.
- Rich, B.E. and T.S. Kupper (2001) Curr. Biol. 11:R531.
- Pestka, S. et al. (2004) Annu. Rev. Immunol. 22:929.
- Dumoutier, L. (2001) J. Immunol. 167:3545.
- Romer, J. (2003) J. Invest. Dermatol. 121:1306.
Long Name
Interleukin 20
Alternate Names
IL20
Gene Symbol
IL20
UniProt
Additional IL-20 Products
Product Documents for Mouse IL-20 Antibody
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Note: Certificate of Analysis not available for kit components.
Product Specific Notices for Mouse IL-20 Antibody
For research use only
Citations for Mouse IL-20 Antibody
