HIV-1 Gag p24 Antibody

Catalog # Availability Size / Price Qty
Detection of HIV-1 Gag p24 by Western Blot.
1 Image
Product Details
Citations (3)
Supplemental Products
Reviews (2)

HIV-1 Gag p24 Antibody Summary

Species Reactivity
Detects viral HIV-1 Gag p24 in direct ELISAs.
Monoclonal Mouse IgG2A Clone # 749140
Protein A or G purified from hybridoma culture supernatant
E. coli-derived recombinant viral HIV-1 Gag p24
Accession # NP_057850
Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.


Recommended Concentration
Western Blot
2 µg/mL
See below

Please Note: Optimal dilutions should be determined by each laboratory for each application. General Protocols are available in the Technical Information section on our website.

Scientific Data

Western Blot Detection of HIV-1 Gag p24 antibody by Western Blot. View Larger

Detection of HIV-1 Gag p24 by Western Blot. Western blot shows recombinant HIV Gag p24 (5 ng/lane). PVDF membrane was probed with 2 µg/mL of Mouse Anti-Viral HIV-1 Gag p24 Monoclonal Antibody (Catalog # MAB7360) followed by HRP-conjugated Anti-Mouse IgG Secondary Antibody (Catalog # HAF007). A specific band was detected for HIV-1 Gag p24 at approximately 23 kDa (as indicated). This experiment was conducted under reducing conditions and using Immunoblot Buffer Group 1.

Reconstitution Calculator

Reconstitution Calculator

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.


Preparation and Storage

Sterile PBS to a final concentration of 0.5 mg/mL.
Reconstitution Buffer Available
Reconstitution Buffer 1 (PBS)
Catalog #
Size / Price
The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below. *Small pack size (SP) is shipped with polar packs. Upon receipt, store it immediately at -20 to -70 °C
Stability & Storage
Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.

Background: HIV-1 Gag p24

The gag gene of human immunodeficiency virus 1 (HIV-1) encodes a precursor protein known as Pr55Gag. The viral protease PR cleaves this precursor to generate p17, p24, p7, and p6 proteins which are required for virus particle assembly. p24 is a major viral core structural protein. Its measurement is commonly used as an indicator of HIV-1 infection and viral load.

Long Name
Human Immunodeficiency Virus Type 1 GAG/Group-specific Antigen core protein of 24 kDa
Entrez Gene IDs
155030 (Viral)
Alternate Names
CA; Capsid Protein; HIV1 Gag p24; HIV-1 Gag p24; Pr55(Gag)

Product Datasheets

You must select a language.


Citations for HIV-1 Gag p24 Antibody

R&D Systems personnel manually curate a database that contains references using R&D Systems products. The data collected includes not only links to publications in PubMed, but also provides information about sample types, species, and experimental conditions.

3 Citations: Showing 1 - 3
Filter your results:

Filter by:

  1. Characterising proteolysis during SARS-CoV-2 infection identifies viral cleavage sites and cellular targets with therapeutic potential
    Authors: B Meyer, J Chiaravall, S Gellenonco, P Brownridge, DP Bryne, LA Daly, A Grauslys, M Walter, F Agou, LA Chakrabart, CS Craik, CE Eyers, PA Eyers, Y Gambin, AR Jones, E Sierecki, E Verdin, M Vignuzzi, E Emmott
    Nature Communications, 2021-09-21;12(1):5553.
    Species: Human
    Sample Types: Cell Lysates
    Applications: Western Blot
  2. Mechanisms of HIV-1 evasion to the antiviral activity of chemokine CXCL12 indicate potential links with pathogenesis
    Authors: M Armani-Tou, Z Zhou, R Gasser, I Staropoli, V Cantaloube, Y Benureau, J Garcia-Per, M Pérez-Olme, V Lorin, B Puissant-L, L Assoumou, C Delaugerre, JD Lelièvre, Y Lévy, H Mouquet, G Martin-Blo, J Alcami, F Arenzana-S, J Izopet, P Colin, B Lagane
    PloS Pathogens, 2021-04-19;17(4):e1009526.
    Species: Human
    Sample Types: Cell Lysates
    Applications: Western Blot
  3. Hydroxyproline-containing collagen peptide derived from the skin of the Alaska pollack inhibits HIV-1 infection
    Mol Med Rep, 2016-11-16;14(6):5489-5494.
    Species: Human
    Sample Types: Cell Lysates
    Applications: Western Blot


No product specific FAQs exist for this product, however you may

View all Antibody FAQs

Isotype Controls

Mouse IgG2A Isotype Control

Reconstitution Buffers

Secondary Antibodies

Reviews for HIV-1 Gag p24 Antibody

Average Rating: 4.5 (Based on 2 Reviews)

5 Star
4 Star
3 Star
2 Star
1 Star

Have you used HIV-1 Gag p24 Antibody?

Submit a review and receive an Amazon gift card.

$25/€18/£15/$25CAN/¥75 Yuan/¥1250 Yen for a review with an image

$10/€7/£6/$10 CAD/¥70 Yuan/¥1110 Yen for a review without an image

Submit a Review

Filter by:

HIV-1 Gag p24 Antibody
By Anonymous on 10/09/2018
Application: WB Sample Tested: Cell Lysates Species: HIV

gag protein w/o HIV protease, expressed in HEK293 cells, 1/500 dilution

HIV-1 Gag p24 Antibody
By Anonymous on 02/24/2016
Application: ELISA Sample Tested: Cell Lysates Species: Viral
