CXCL9, a member of the alpha subfamily of chemokines that lack the ELR domain, was initially identified as a lymphokine-activated gene in mouse macrophages. Human CXCL9 was subsequently cloned using mouse MIG cDNA as a probe. The CXCL9 gene is induced in macrophages and in primary glial cells of the central nervous system specifically in response to IFN-gamma. CXCL9 has been shown to be a chemoattractant for activated T-lymphocytes and TIL but not for neutrophils or monocytes. The human CXCL9 cDNA encodes a 125 amino acid residue precursor protein with a 22 amino acid residue signal peptide that is cleaved to yield a 103 amino acid residue mature protein. CXCL9 has an extended carboxy-terminus containing greater than 50% basic amino acid residues and is larger than most other chemokines. The carboxy-terminal residues of CXCL9 are prone to proteolytic cleavage resulting in size heterogeneity of natural and recombinant CXCL9. CXCL9 with large carboxy-terminal deletions have been shown to have diminished activity in the calcium flux assay. A chemokine receptor (CXCR3) specific for CXCL9 and IP-10 has been cloned and shown to be highly expressed in IL-2-activated T-lymphocytes. The E. coli-expressed CXCL9 preparations produced at R&D Systems have been shown to contain greater than 80% full length CXCL9.
Human CXCL9/MIG Antibody
R&D Systems | Catalog # AF392
Scientific images may be resized, cropped, or adjusted for brightness or contrast for presentation purposes. These updates are limited to presentation and do not affect the underlying scientific interpretation of the data. Where available, additional source data may be provided upon request.
Key Product Details
Species Reactivity
Validated:
Cited:
Applications
Validated:
Cited:
Label
Antibody Source
Product Specifications
Immunogen
Thr23-Thr125
Accession # Q07325
Specificity
Clonality
Host
Isotype
Endotoxin Level
Scientific Data Images for Human CXCL9/MIG Antibody
Chemotaxis Induced by CXCL9/MIG and Neutral-ization by Human CXCL9/ MIG Antibody.
Recombinant Human CXCL9/ MIG (392-MG) chemo-attracts the BaF3 mouse pro-B cell line transfected with mouse CXCR3 in a dose-dependent manner (orange line). The amount of cells that migrated through to the lower chemotaxis chamber was measured by Resazurin (AR002). Chemotaxis elicited by Recombinant Human CXCL9/ MIG (1 µg/mL) is neutralized (green line) by increasing concentrations of Goat Anti-Human CXCL9/MIG Antigen Affinity-purified Polyclonal Antibody (Catalog # AF392). The ND50 is typically 5-40 µg/mL.CXCL9/MIG in THP‑1 Human Cell Line.
CXCL9/MIG was detected in immersion fixed THP-1 human acute monocytic leukemia cell line stimulated with IFN-gamma using Goat Anti-Human CXCL9/MIG Antigen Affinity-purified Polyclonal Antibody (Catalog # AF392) at 10 µg/mL for 3 hours at room temperature. Cells were stained using the Northern-Lights™ 557-conjugated Anti-Goat IgG Secondary Antibody (red; Catalog # NL001) and counter-stained with DAPI (blue). View our protocol for Fluorescent ICC Staining of Cells on Coverslips.Detection of Human CXCL9/MIG by Immunohistochemistry
CD8+ T- and CD20+ B-lymphocytes are not localized within inflammatory foci.Immunohistochemistry using anti-CD20 identified a few B-lymphocytes in the inflammatory foci (arrows) (A). In contrast, no CD8+ T-lymphocytes are localized using anti-CD8 antibody (B) (400X). Immunohistrochemistry using anti-pro-IL-18 (C) or anti-CXCL9 (D) reveals the expression of these molecules on mononuclear cells within inflammatory foci (200X). Image collected and cropped by CiteAb from the following open publication (https://dx.plos.org/10.1371/journal.pone.0014429), licensed under a CC-BY license. Not internally tested by R&D Systems.Detection of Human CXCL9/MIG by Immunohistochemistry
CD8+ T- and CD20+ B-lymphocytes are not localized within inflammatory foci.Immunohistochemistry using anti-CD20 identified a few B-lymphocytes in the inflammatory foci (arrows) (A). In contrast, no CD8+ T-lymphocytes are localized using anti-CD8 antibody (B) (400X). Immunohistrochemistry using anti-pro-IL-18 (C) or anti-CXCL9 (D) reveals the expression of these molecules on mononuclear cells within inflammatory foci (200X). Image collected and cropped by CiteAb from the following open publication (https://dx.plos.org/10.1371/journal.pone.0014429), licensed under a CC-BY license. Not internally tested by R&D Systems.Human CXCL9 / MIG ELISA Standard Curve
Recombinant Human CXCL9/MIG (Catalog # 392-MG) was serially diluted and captured by Mouse Anti-Human CXCL9/MIG Monoclonal Antibody (Catalog # MAB392) coated on a Clear Polystyrene Microplate (Catalog # DY990). Goat Anti-Human CXCL9/MIG Antigen Affinity-purified Polyclonal Antibody (Catalog # AF392) was biotinylated and incubated with the protein captured on the plate. Detection of the standard curve was achieved by incubating Streptavidin-HRP (Catalog # DY998)Applications for Human CXCL9/MIG Antibody
Immunocytochemistry
Sample: Immersion fixed human peripheral blood mononuclear cells treated with PMA and calcium ionomycin, and THP-1 human acute monocytic leukemia cell line stimulated with IFN-gamma
Western Blot
Sample: Recombinant Human CXCL9/MIG (Catalog # 392-MG)
Neutralization
Formulation, Preparation, and Storage
Purification
Reconstitution
Reconstitute at 0.2 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.
Formulation
Shipping
Stability & Storage
- 12 months from date of receipt, -20 to -70 °C as supplied.
- 1 month, 2 to 8 °C under sterile conditions after reconstitution.
- 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Calculators
Background: CXCL9/MIG
References
- Loetscher, M. et al. (1996) J. Exp. Med. 184:963.
- Liao, F. et al. (1995) J. Exp. Med. 182:1301.
- Vanguri, P. (1995) J. Neuroimmunol. 56:35.
Alternate Names
Gene Symbol
UniProt
Additional CXCL9/MIG Products
Product Documents for Human CXCL9/MIG Antibody
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Note: Certificate of Analysis not available for kit components.
Product Specific Notices for Human CXCL9/MIG Antibody
For research use only
Citations for Human CXCL9/MIG Antibody
Customer Reviews for Human CXCL9/MIG Antibody
There are currently no reviews for this product. Be the first to review Human CXCL9/MIG Antibody and earn rewards!
Have you used Human CXCL9/MIG Antibody?
Submit a review and receive an Amazon gift card!
$25/€18/£15/$25CAN/¥2500 for a review with an image
$10/€7/£6/$10CAN/¥1110 for a review without an image
Submit a review
