Interleukin 23 (IL-23) is a heterodimeric cytokine composed of two disulfide-linked subunits, a p19 subunit that is unique to IL-23, and a p40 subunit that is shared with IL-12 (1‑5). The p19 subunit has homology to the p35 subunit of IL-12, as well as to other single chain cytokines such as IL-6 and IL-11. The p40 subunit is homologous to the extracellular domains of the hematopoietic cytokine receptors. Human p19 cDNA encodes a 189 amino acid residue (aa) precursor protein with a putative 19 aa signal peptide and 170 aa mature protein. Human and mouse p19 share 70% aa sequence identity. Although p19 is expressed by activated macrophages, dendritic cells, T cells, and endothelial cells, only activated macrophages and dendritic cells express p40 concurrently to produce IL-23. The functional IL-23 receptor complex consists of two receptor subunits, the IL-12 receptor beta 1 subunit (IL-12 R beta 1) and the IL-23-specific receptor subunit (IL-23 R). IL-23 has biological activities that are similar to, but distinct from IL-12. Both IL-12 and IL-23 induce proliferation and IFN-gamma production by human T cells. While IL-12 acts on both naïve and memory human T cells, the effects of IL-23 is restricted to memory T cells. In mouse, IL-23 but not IL-12, has also been shown to induce memory T cells to secret IL-17, a potent proinflammatory cytokine. IL-12 and IL-23 can induce IL-12 production from mouse splenic DC of both the CD8- and CD8+ subtypes, however only IL-23 can act directly on CD8+ DC to mediate immunogenic presentation of poorly immunogenic tumor/self peptide.
Human IL‑12/IL‑23 p40 Antibody
R&D Systems | Catalog # AF309
Key Product Details
Species Reactivity
Validated:
Human
Cited:
Human
Applications
Validated:
Western Blot, Neutralization
Cited:
ELISA Development (Detection)
Label
Unconjugated
Antibody Source
Polyclonal Goat IgG
Loading...
Product Specifications
Immunogen
S. frugiperda insect ovarian cell line Sf 21-derived recombinant human IL-12/IL-23 p40
p40: Ile23-Ser328, Accession # P29460; p19: Ala21-Pro189, Accession # AAG37232
p40: Ile23-Ser328, Accession # P29460; p19: Ala21-Pro189, Accession # AAG37232
Specificity
Detects human IL-12/IL-23 p40 in direct ELISAs and Western blots.
Clonality
Polyclonal
Host
Goat
Isotype
IgG
Endotoxin Level
<0.10 EU per 1 μg of the antibody by the LAL method.
Scientific Data Images for Human IL‑12/IL‑23 p40 Antibody
Detection of Human IL‑12/IL‑23 p40 by Western Blot.
Western blot shows lysates of Hs 294T human melanoma cell line. PVDF Membrane was probed with 1 µg/mL of Goat Anti-Human IL-12/IL-23 p40 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF309) followed by HRP-conjugated Anti-Goat IgG Secondary Antibody (Catalog # HAF019). A specific band was detected for IL-12/IL-23 p40 at approximately 40 kDa (as indicated). This experiment was conducted under reducing conditions and using Immunoblot Buffer Group 8.Il-17 Secretion Induced by IL‑23 and Neutralization by Human IL‑12/IL‑23 p40 Antibody.
Recombinant Human IL-23 (Catalog # 1290-IL) induces IL-17 secretion in the mouse splenocytes in a dose-dependent manner (orange line), as measured by Mouse IL-17 Quantikine kit. IL-17 Secretion elicited by Recombinant Human IL-23 (0.75 ng/mL) is neutralized (green line) by increasing concentrations of Goat Anti-Human IL-12/IL-23 p40 Anti-gen Affinity-purified Polyclonal Antibody (Catalog # AF309). The ND50 is typically 0.004-0.02 µg/mL.Applications for Human IL‑12/IL‑23 p40 Antibody
Application
Recommended Usage
Western Blot
1 µg/mL
Sample: Hs 294T human melanoma cell line
Sample: Hs 294T human melanoma cell line
Neutralization
Measured by its ability to neutralize IL‑23-induced IL-17 secretion in mouse splenocytes. Aggarwal, S. et al. (2003) J. Biol. Chem. 278:1910. The Neutralization Dose (ND50) is typically 0.004-0.02 μg/mL in the presence of 0.75 ng/mL Recombinant Human IL‑23.
Formulation, Preparation, and Storage
Purification
Antigen Affinity-purified
Reconstitution
Reconstitute at 0.2 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.
Loading...
Formulation
Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.
Shipping
Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.
Stability & Storage
Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
- 12 months from date of receipt, -20 to -70 °C as supplied.
- 1 month, 2 to 8 °C under sterile conditions after reconstitution.
- 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Calculators
Background: IL-12/IL-23 p40
References
- Oppmann, B. et al. (2000) Immunity 13:715.
- Lankford, C.S. and D.M. Frucht (2003) J. Leukoc. Biol. 73:49.
- Parham, C. et al. (2002) J. Immunol. 168:5699.
- Belladonna, M.L. et al. (2002) J. Immunol. 168:5448.
- Aggarwal, S. et al. (2003) J. Biol. Chem. 278:1910.
Long Name
Interleukin 12/Interleukin 23 p40
Alternate Names
CLMF2, IL-12B, IL12 p40, IL12B, NKSF2
Entrez Gene IDs
Gene Symbol
IL12B
