M-CSF, also known as CSF-1, is a four-alpha -helical-bundle cytokine that is the primary regulator of macrophage survival, proliferation and differentiation (1-3). M-CSF is also essential for the survival and proliferation of osteoclast progenitors (1, 4). M-CSF also primes and enhances macrophage killing of tumor cells and microorganisms, regulates the release of cytokines and other inflammatory modulators from macrophages, and stimulates pinocytosis (2, 3). M-CSF increases during pregnancy to support implantation and growth of the decidua and placenta (5). Sources of M-CSF include fibroblasts, activated macrophages, endometrial secretory epithelium, bone marrow stromal cells, and activated endothelial cells (1-5). The M-CSF receptor (c-fms) transduces its pleotropic effects and mediates its endocytosis. M-CSF mRNAs of various sizes occur (3-9). Full length mouse M-CSF transcripts encode a 520 amino acid (aa) type I transmembrane (TM) protein with a 462 aa extracellular region, a 21 aa TM domain, and a 37 aa cytoplasmic tail that forms a 140 kDa covalent dimer. Differential processing produces two proteolytically cleaved, secreted dimers. One is an N- and O-glycosylated 86 kDa dimer, while the other is modified by both glycosylation and chondroitin-sulfate proteoglycan (PG) to generate a 200 kDa subunit. Although PG-modified M-CSF can circulate, it may be immobilized by attachment to type V collagen (8). Shorter transcripts encode M-CSF that lacks cleavage and PG sites and produces an N-glycosylated 68 kDa TM dimer and a slowly produced 44 kDa secreted dimer (7). Although forms may vary in activity and half-life, all contain the N-terminal 150 aa portion that is necessary and sufficient for interaction with the M-CSF receptor (10, 11). The first 229 aa of mature mouse M-CSF shares 87%, 83%, 82%, and 81% aa identity with corresponding regions of rat, dog, cow, and human M-CSF, respectively (12, 13). Human M-CSF is active in the mouse, but mouse M-CSF is reported to be species-specific.
Scientific images may be resized, cropped, or adjusted for brightness or contrast for presentation purposes. These updates are limited to presentation and do not affect the underlying scientific interpretation of the data. Where available, additional source data may be provided upon request.
Key Product Details
Species Reactivity
Validated:
Cited:
Applications
Validated:
Cited:
Label
Antibody Source
Product Specifications
Immunogen
Lys33-Glu262
Accession # Q3U4F9
Specificity
Clonality
Host
Isotype
Endotoxin Level
Scientific Data Images for Mouse M-CSF Antibody
Cell Proliferation Induced by M‑CSF and Neutralization by Mouse M‑CSF Antibody.
Recombinant Mouse M-CSF (Catalog # 416-ML) stimulates proliferation in the M-NFS-60 mouse myelogenous leukemia lymphoblast cell line in a dose-dependent manner (orange line). Proliferation elicited by Recombinant Mouse M-CSF (10 ng/mL) is neutralized (green line) by increasing concentrations of Goat Anti-Mouse M-CSF Antigen Affinity-purified Polyclonal Antibody (Catalog # AF416). The ND50 is typically 0.015-0.035 µg/mL.Mouse M-CSF ELISA Standard Curve
Recombinant Mouse M‑CSF (Catalog # 416-ML) was serially diluted and captured by Rat Anti-Mouse M‑CSF Monoclonal Antibody (Catalog # MAB416) coated on a Clear Polystyrene Microplate (Catalog # DY990). Goat Anti-Mouse M‑CSF Antigen Affinity-purified Polyclonal Antibody (Catalog # AF416) was biotinylated and incubated with the protein captured on the plate. Detection of the standard curve was achieved by incubating Streptavidin-HRP (Catalog # DY998)Detection of M-CSF by Immunohistochemistry
CSF1/CSF1R expression in the E18 mandibular incisor. (A) CSF1R stained in red and (B) CSF1 stained in green, with nuclei stained blue. Magnified views of the apical ends (A′,B′) and incisal ends (A″,B″) from A and B. Insets in (B′,B″) show CSF1/CSF1R double immunostaining. Autofluorescent blood cells are marked by asterisks (*) while CSF1- and CSF1R-expressing cells are marked with arrowheads. Pre-immune negative controls at E18 on bottom panel. n = 3 animals [see Supplemental Table S1 for details]. Dental papilla (dp), labial cervical loop (LaCL), labial dental epithelium (La DE), lingual cervical loop (LiCL), lingual dental epithelium (Li DE). Image collected and cropped by CiteAb from the following open publication (https://pubmed.ncbi.nlm.nih.gov/42201245), licensed under a CC-BY license. Not internally tested by R&D Systems.Applications for Mouse M-CSF Antibody
Western Blot
Sample: Recombinant Mouse M-CSF (Catalog # 416-ML)
Neutralization
Formulation, Preparation, and Storage
Purification
Reconstitution
Reconstitute at 0.2 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.
Formulation
Shipping
Stability & Storage
- 12 months from date of receipt, -20 to -70 °C as supplied.
- 1 month, 2 to 8 °C under sterile conditions after reconstitution.
- 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Calculators
Background: M-CSF
References
- Pixley, F.J. and E.R. Stanley (2004) Trends Cell Biol. 14:628.
- Chitu, V. and E.R. Stanley (2006) Curr. Opin. Immunol. 18:39.
- Fixe, P. and V. Praloran (1997) Eur. Cytokine Netw. 8:125.
- Ryan, G.R. et al. (2001) Blood 98:74.
- Makrigiannakis, A. et al. (2006) Trends Endocrinol. Metab. 17:178.
- Nandi, S. et al. (2006) Blood 107:786.
- Rettenmier, C.W. and M.F. Roussel (1988) Mol. Cell Biol. 8:5026.
- Suzu, S. et al. (1992) J. Biol. Chem. 267:16812.
- Manos, M.M. (1988) Mol. Cell. Biol. 8:5035.
- Koths, K. (1997) Mol. Reprod. Dev. 46:31.
- Jang, M-H. et al. (2006) J. Immunol. 177:4055.
- DeLamarter, J.F. et al. (1987) Nucleic Acids Res. 15:2389.
- Ladner, M.B. et al. (1988) Proc. Natl. Acad. Sci. USA 85:6706.
Long Name
Alternate Names
Gene Symbol
UniProt
