Neuropilin-1 (Npn-1, previously known as neuropilin) and Npn-2 (previously known as Npn-1-related molecule) are type I transmembrane proteins that bind members of the class III secreted semaphorin subfamily which are implicated in repulsive axon guidance. The extracellular domain of these proteins is composed of two N-terminal CUB (complement-binding) domains (domains a1 and a2), two domains with homology to coagulation factors V and VIII (domains b1 and b2) and a MAM (meprin) domain (domain c). In the absence of ligands, neuropilins can form homo- and hetero-oligomers via homophilic interactions of their MAM domains. At the amino acid sequence level, Npn-1and Npn-2 share 44% identity. Npn-1 and Npn-2 show different binding specificities for different members of the semaphorin family. The expression patterns of Npn-1 and Npn-2 in developing neurons of the central and peripheral nervous systems are largely, though not completely non-overlapping. Npn‑1 and Npn-2 are also expressed by endothelial and tumor cells and have been shown to be isoform-specific receptors for VEGF165. Npn-1 was also reported to bind PlGF-2 and the VEGF-like protein from of virus NZ2.
Rat Neuropilin‑2 Antibody
R&D Systems | Catalog # MAB567R
Key Product Details
Species Reactivity
Applications
Label
Antibody Source
Product Specifications
Immunogen
Gln23-Asp857 (Val809-Asp825 del)
Accession # O35276
Specificity
Clonality
Host
Isotype
Scientific Data Images for Rat Neuropilin‑2 Antibody
Detection of Rat Neuropilin‑2 by Western Blot.
Western blot shows lysates of C6 rat glioma cell line and Rat-2 rat embryonic fibroblast cell line. PVDF membrane was probed with 1 µg/mL of Mouse Anti-Rat Neuropilin-2 Monoclonal Antibody (Catalog # MAB567R) followed by HRP-conjugated Anti-Mouse IgG Secondary Antibody (Catalog # HAF018). A specific band was detected for Neuropilin-2 at approximately 110 kDa (as indicated). This experiment was conducted under reducing conditions and using Immunoblot Buffer Group 1.Detection of Neuropilin-2 in C6 Rat Cell Line by Flow Cytometry.
C6 Rat glial tumor cell line was stained with Mouse Anti-Rat Neuropilin-2 Monoclonal Antibody (Catalog # MAB567R, filled histogram) or isotype control antibody (Catalog # MAB0041, open histogram), followed by Allophycocyanin-conjugated Anti-Mouse IgG Secondary Antibody (Catalog # F0101B). View our protocol for Staining Membrane-associated Proteins.Detection of Rat Neuropilin‑2 by Simple WesternTM.
Simple Western lane view shows lysates of C6 rat glioma cell line, loaded at 0.2 mg/mL. A specific band was detected for Neuropilin‑2 at approximately 138 kDa (as indicated) using 50 µg/mL of Mouse Anti-Rat Neuropilin‑2 Monoclonal Antibody (Catalog # MAB567R). This experiment was conducted under reducing conditions and using the 12-230 kDa separation system.Applications for Rat Neuropilin‑2 Antibody
CyTOF-ready
Flow Cytometry
Sample: C6 Rat Cell Line
Simple Western
Sample: C6 rat glioma cell line
Western Blot
Sample: C6 rat glioma cell line and Rat‑2 rat embryonic fibroblast cell line
Flow Cytometry Panel Builder
Bio-Techne Knows Flow Cytometry
Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.
Advanced Features
- Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
- Spillover Popups - Visualize the spectra of individual fluorochromes
- Antigen Density Selector - Match fluorochrome brightness with antigen density
Formulation, Preparation, and Storage
Purification
Reconstitution
Reconstitute at 0.5 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.
Formulation
Shipping
Stability & Storage
- 12 months from date of receipt, -20 to -70 °C as supplied.
- 1 month, 2 to 8 °C under sterile conditions after reconstitution.
- 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Calculators
Background: Neuropilin-2
References
- Fujisawa, H. and T. Kitsukawa (1998) Curr. Opin. Neurobiol. 8:587.
- Neufeld, G. et al. (1999) FASEB J. 13:9.
- Poltorak, Z. et al. (2000) J. Biol. Chem. 275:18040.
