PHD2 (Prolyl Hydroxylase Domain-containing protein 2; also HPH2, EGLN1 and HIF-PH2) is a 45-47 kDa dioxygenase member of the PH family of enzymes. It is ubiquitously expressed, and serves to regulate the availability of the oxygen-sensitive HIF transcription factor. Active HIF1 alpha is a heterodimer of alpha - and beta -subunits and when intact, promotes VEGF and EPO production. The beta -subunit is constitutively expressed, while alpha -subunit levels are regulated by intracellular oxygen concentration. At normoxic levels, the alpha -subunit is hydroxylated on Pro by one of three PHDs, inducing its ubiquitination/degradation. The hydroxylation event requires oxygen, and thus PH activity (particularly PHD2) is a measure of a cell's oxygen concentration. Human PHD2 is 426 amino acids (aa) in length. It contains an NES (aa 6-20), a Zn-finger region (aa 21-58), and a catalytic domain (aa 291-392). There are five nitrosylated cysteines plus one acetylated alanine. Two isoform variants are known, one that shows a deletion of aa 338-359, and another that contains a 17 aa substitution for aa 58-175. Over aa 157-426, human PHD2 shares 93% aa sequence identity with mouse PHD2.
Human/Rat EGLN1/PHD2 Antibody
R&D Systems | Catalog # MAB7680
Key Product Details
Species Reactivity
Applications
Label
Antibody Source
Product Specifications
Immunogen
Ala2-Phe426
Accession # Q9GZT9
Specificity
Clonality
Host
Isotype
Scientific Data Images for Human/Rat EGLN1/PHD2 Antibody
Detection of Human and Rat EGLN1/PHD2 by Western Blot.
Western blot shows lysates of HEK293T human embryonic kidney cell line, PC-3 human prostate cancer cell line, and L6 rat myoblast cell line. PVDF membrane was probed with 1 µg/mL of Rabbit Anti-Human/Rat EGLN1/PHD2 Monoclonal Antibody (Catalog # MAB7680) followed by HRP-conjugated Anti-Rabbit IgG Secondary Antibody (HAF008). A specific band was detected for EGLN1/PHD2 at approximately 49 kDa (as indicated). This experiment was conducted under reducing conditions and using Immunoblot Buffer Group 1.Detection of EGLN1/PHD2 in Human Jurkat cell line by Flow Cytometry.
Human Jurkat T Cell Leukemia Cell Line was stained with Rabbit Anti-Human/Rat EGLN1/PHD2 Monoclonal Antibody (Catalog # MAB7680, filled histogram) or Rabbit IgG Isotype Control Antibody (MAB1050, open histogram) followed by Phycoerythrin-conjugated Anti-Rabbit IgG Secondary Antibody (Catalog # F0110). To facilitate intracellular staining, cells were fixed and permeabilized with FlowX FoxP3 Fixation & Permeabilization Buffer Kit (FC012). View our protocol for Staining Membrane-associated Proteins.EGLN1/PHD2 in WM-115 Human Cell Lines.
EGLN1/PHD2 was detected in immersion fixed WM-115 human malignant melanoma cell line using Rabbit Anti-Human/Rat EGLN1/PHD2 Monoclonal Antibody (Catalog # MAB7680) at 3 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Anti-Rabbit IgG Secondary Antibody (red; NL004) and counterstained with DAPI (blue). Specific staining was localized to cell cytoplasm and nuclei. View our protocol for Fluorescent ICC Staining of Cells on Coverslips.EGLN1/PHD2 in Human Kidney.
EGLN1/PHD2 was detected in immersion fixed paraffin-embedded sections of human kidney using Rabbit Anti-Human/Rat EGLN1/PHD2 Monoclonal Antibody (Catalog # MAB7680) at 3 µg/mL for 1 hour at room temperature followed by incubation with the Anti-Rabbit IgG VisUCyte™ HRP Polymer Antibody (VC003). Before incubation with the primary antibody, tissue was subjected to heat-induced epitope retrieval using Antigen Retrieval Reagent-Basic (CTS013). Tissue was stained using DAB (brown) and counterstained with hematoxylin (blue). Specific staining was localized to cell cytoplasm and nuclei. View our protocol for IHC Staining with VisUCyte HRP Polymer Detection Reagents.Detection of Human EGLN1/PHD2 by Simple WesternTM.
Simple Western lane view shows lysates of HEK293T human embryonic kidney cell line, loaded at 0.2 mg/mL. A specific band was detected for EGLN1/PHD2 at approximately 55 kDa (as indicated) using 10 µg/mL of Rabbit Anti-Human/Rat EGLN1/PHD2 Monoclonal Antibody (Catalog # MAB7680). This experiment was conducted under reducing conditions and using the 12-230 kDa separation system.Bax in RAW264.7 cells.
EGLN1/PHD2 was detected in immersion fixed L6 cells using Rabbit Anti-Human/Rat EGLN1/PHD2 Monoclonal Antibody (Catalog # MAB7680) at 15 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Anti-Rabbit IgG Secondary Antibody (red; Catalog # NL004) and counterstained with DAPI (blue). Specific staining was localized to plasma membrane. View our protocol for Fluorescent ICC Staining of Non-adherent Cells.Applications for Human/Rat EGLN1/PHD2 Antibody
CyTOF-ready
Flow Cytometry
Sample: Jurkat Human T Cell Leukemia Line
Immunocytochemistry
Sample: Immersion fixed WM-115 human malignant melanoma cell line
Immunohistochemistry
Sample: Immersion fixed paraffin-embedded sections of human kidney
Simple Western
Sample: HEK293T human embryonic kidney cell line
Western Blot
Sample: HEK293T human embryonic kidney cell line, PC‑3 human prostate cancer cell line, and L6 rat myoblast cell line
Flow Cytometry Panel Builder
Bio-Techne Knows Flow Cytometry
Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.
Advanced Features
- Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
- Spillover Popups - Visualize the spectra of individual fluorochromes
- Antigen Density Selector - Match fluorochrome brightness with antigen density
Formulation, Preparation, and Storage
Purification
Reconstitution
Reconstitute at 0.5 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.
Formulation
Shipping
Stability & Storage
- 12 months from date of receipt, -20 to -70 °C as supplied.
- 1 month, 2 to 8 °C under sterile conditions after reconstitution.
- 6 months, -20 to -70 °C under sterile conditions after reconstitution.
