GITR (glucocorticoid-induced tumor necrosis factor receptor, also named AITR, activation-inducible TNF R family member), is a 228 amino acid (aa) type I transmembrane protein belonging to the TNF R family and has been designated TNFRSF18. The GITR cytoplasmic domain has striking homology with the cytoplasmic domain of 4-1BB and CD27. Human GITR shares 55% homology with murine GITR. GITR is expressed at low levels in peripheral blood T cells, bone marrow, thymus, spleen, and lymph nodes. In contrast to mouse GITR, expression of human GITR is not induced by treatment with dexamethasone, but is up‑regulated by antigen stimulation or by treatment with anti-CD3 plus anti-CD28, or PMA plus ionomycin. Human GITR ligand was identified from human umbilical vein endothelial cells and is a 177 aa polypeptide belonging to the TNF superfamily (TNFSF18). Ligation of GITR can activate NF-kappa B through TRAF2, and protect T cells from TCR activation-induced cell death. It has been proposed that GITR ligand and GITR may modulate T lymphocyte functions.
Human GITR/TNFRSF18 Antibody
R&D Systems | Catalog # AF689
Key Product Details
Species Reactivity
Validated:
Cited:
Applications
Validated:
Cited:
Label
Antibody Source
Product Specifications
Immunogen
Gln26-Glu161 (Thr45Ala)
Accession # Q9Y5U5
Specificity
Clonality
Host
Isotype
Endotoxin Level
Scientific Data Images for Human GITR/TNFRSF18 Antibody
GITR/TNFRSF18 in Human Tonsil.
GITR/TNFRSF18 was detected in immersion fixed paraffin-embedded sections of human tonsil using Goat Anti-Human GITR/TNFRSF18 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF689) at 10 µg/mL overnight at 4 °C. Tissue was stained using the Anti-Goat HRP-DAB Cell & Tissue Staining Kit (brown; Catalog # CTS008) and counterstained with hematoxylin (blue). Specific staining was localized to trabeculae sinuses. View our protocol for Chromogenic IHC Staining of Paraffin-embedded Tissue Sections.
Applications for Human GITR/TNFRSF18 Antibody
Blockade of Receptor-ligand Interaction
In a functional ELISA, 1-2 µg/mL of this antibody will block 50% of the binding of 10 ng/mL of Recombinant Biotinylated Human GITR Ligand/TNFSF18 to immobilized Recombinant Human GITR/TNFRSF18 Fc Chimera (Catalog # 689-GR) coated at 2 µg/mL (100 µL/well). At 10 μg/mL, this antibody will block >90% of the binding.
CyTOF-ready
Flow Cytometry
Sample: Human T cells treated with PHA
Immunohistochemistry
Sample: Immersion fixed paraffin-embedded sections of human tonsil
Western Blot
Sample: Recombinant Human GITR/TNFRSF18 Fc Chimera (Catalog # 689-GR)
Flow Cytometry Panel Builder
Bio-Techne Knows Flow Cytometry
Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.
Advanced Features
- Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
- Spillover Popups - Visualize the spectra of individual fluorochromes
- Antigen Density Selector - Match fluorochrome brightness with antigen density
Formulation, Preparation, and Storage
Purification
Reconstitution
Reconstitute at 0.2 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.
Formulation
Shipping
Stability & Storage
- 12 months from date of receipt, -20 to -70 °C as supplied.
- 1 month, 2 to 8 °C under sterile conditions after reconstitution.
- 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Calculators
Background: GITR/TNFRSF18
References
- Nocentini, G. et al. (1997) Proc. Natl. Acad. Sci. USA 94:6216.
- Kwon, B. et al. (1999) J. Biol. Chem. 274:6056.
- Gurney, A.L. et al. (1999) Current Biology 9:215.
- Kwon, B. et al. (1999) Current Opinion in Immunology 11:340.
Long Name
Alternate Names
Gene Symbol
UniProt
