Human Lyp Antibody

(1 citations)
  • Species Reactivity
    Human
  • Specificity
    Detects human Lyp in Western blots.
  • Source
    Monoclonal Mouse IgG2B Clone # 340113
  • Purification
    Protein A or G purified from hybridoma culture supernatant
  • Immunogen
    E. coli-derived recombinant human Lyp
    Ser306-Ser684
    Accession # Q9Y2R2
  • Formulation
    Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied as a 0.2 µm filtered solution in PBS.
  • Label
    Unconjugated
Applications
  •
    Recommended
    Concentration
    Sample
  • Western Blot
    1 µg/mL
    See below
  • Immunohistochemistry
    8-25 µg/mL
    See below
Please Note: Optimal dilutions should be determined by each laboratory for each application. General Protocols are available in the Technical Information section on our website.
Data Examples
Immunohistochemistry
Lyp in Human Lymph Node. Lyp was detected in immersion fixed paraffin-embedded sections of human lymph node using 25 µg/mL Mouse Anti-Human Lyp Monoclonal Antibody (Catalog # MAB3428) overnight at 4 °C. Tissue was stained with the Anti-Mouse HRP-DAB Cell & Tissue Staining Kit (brown; Catalog # CTS002) and counterstained with hematoxylin (blue). View our protocol for Chromogenic IHC Staining of Paraffin-embedded Tissue Sections.
Detection of Human Lyp by Western Blot. Western blot shows lysates of Jurkat human acute T cell leukemia cell line, Daudi human Burkitt's lymphoma cell line, and Ramos human Burkitt's lymphoma cell line. PVDF membrane was probed with 1 µg/mL of Mouse Anti-Human Lyp Monoclonal Antibody (Catalog # MAB3428) followed by HRP-conjugated Anti-Mouse IgG Secondary Antibody (Catalog # HAF007). A specific band was detected for Lyp at approximately 108 kDa (as indicated). This experiment was conducted under reducing conditions and using Immunoblot Buffer Group 1.
Preparation and Storage
  • Reconstitution
    Reconstitute at 0.5 mg/mL in sterile PBS.
  • Shipping
    The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below. *Small pack size (SP) is shipped with polar packs. Upon receipt, store it immediately at -20 to -70 °C
  • Stability & Storage
    Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
    • 12 months from date of receipt, -20 to -70 °C as supplied.
    • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
    • 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Background: Lyp

Lymphoid phosphatase (Lyp), also called LyPTP, Protein Tyrosine Phosphatase, Nonreceptor-type 22 (PTPN22), and PEST-domain Phosphatase (PEP), dephosphorylates tyrosine residues in proteins. Found primarily in bone marrow and lymphoid cell lines, an R620W gain-of-function mutation in Lyp has been associated with susceptibility to autoimmune diseases such as type I diabetes, rheumatoid arthritis, and lupus erythematosus. Mature PEP knockout mice have an excess of CD8 positive T cells and an exaggerated antigen-induced proliferative response.

  • Long Name:
    Lymphoid Phosphatase
  • Entrez Gene IDs:
    26191 (Human); 19260 (Mouse); 295338 (Rat)
  • Alternate Names:
    EC 3.1.3.48; Hematopoietic cell protein-tyrosine phosphatase 70Z-PEP; Lymphoid phosphatase; lymphoid-specific protein tyrosine phosphatase; Lyp; Lyp1; Lyp2; LyPTP; PEP; PEST-domain phosphatase; protein tyrosine phosphatase, non-receptor type 22 (lymphoid); protein tyrosine phosphatase, non-receptor type 8; PTPN22; PTPN8 (former); PTPN8LYP1; tyrosine-protein phosphatase non-receptor type 22
Related Research Areas
Citations:

R&D Systems personnel manually curate a database that contains references using R&D Systems products. The data collected includes not only links to publications in PubMed, but also provides information about sample types, species, and experimental conditions.

1 Citations: Showing 1 - 1

  1. Cutting edge: The PTPN22 allelic variant associated with autoimmunity impairs B cell signaling.
    Authors: Arechiga AF, Habib T, He Y, Zhang X, Zhang ZY, Funk A, Buckner JH
    J. Immunol., 2009;182(6):3343-7.
    Species: Human
    Sample Type: Cell Lysates
    Application: WB
