Mouse PD-L2/B7-DC Antibody

R&D Systems | Catalog # AF1022

R&D Systems

Key Product Details

Species Reactivity

Validated:

Mouse

Cited:

Mouse, Transgenic Mouse

Applications

Validated:

Immunohistochemistry, Western Blot, Blockade of Receptor-ligand Interaction, Flow Cytometry, CyTOF-ready

Cited:

Immunohistochemistry, Immunohistochemistry-Frozen, Western Blot, Immunocytochemistry

Label

Unconjugated

Antibody Source

Polyclonal Goat IgG
View all PD-L2/B7-DC Primary Antibodies »

Product Specifications

Immunogen

Mouse myeloma cell line NS0-derived recombinant mouse PD-L2
Leu20-Arg219
Accession # Q9WUL5

Specificity

Detects mouse PD-L2 in direct ELISAs and Western blots. In direct ELISAs and Western blots, approximately 20% cross-reactivity with recombinant human PD-L2 is observed.

Clonality

Polyclonal

Host

Goat

Isotype

IgG

Endotoxin Level

<0.10 EU per 1 μg of the antibody by the LAL method.

Scientific Data Images for Mouse PD-L2/B7-DC Antibody

PD‑L2 antibody in Mouse Thymus by Immunohistochemistry (IHC-Fr).

PD‑L2 in Mouse Thymus.

PD-L2 was detected in perfusion fixed frozen sections of mouse thymus using 15 µg/mL Goat Anti-Mouse PD-L2 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF1022) overnight at 4 °C. Tissue was stained with the Anti-Goat HRP-DAB Cell & Tissue Staining Kit (brown; Catalog # CTS008) and counterstained with hematoxylin (blue). View our protocol for Chromogenic IHC Staining of Frozen Tissue Sections.

Applications for Mouse PD-L2/B7-DC Antibody

Application
Recommended Usage

Blockade of Receptor-ligand Interaction

In a functional ELISA, 1-4 µg/mL of this antibody will block 50% of the binding of 1 µg/mL of Recombinant Mouse PD-1 (Catalog # 1021-PD) to immobilized Recombinant Mouse PD-L2 Fc Chimera (Catalog # 1022-PL) coated at 1 µg/mL (100 µL/well). At 30 μg/mL, this antibody will block >90% of the binding.

CyTOF-ready

Ready to be labeled using established conjugation methods. No BSA or other carrier proteins that could interfere with conjugation.

Flow Cytometry

2.5 µg/106 cells
Sample: RAW 264.7 mouse monocyte/macrophage cell line treated with LPS

Immunohistochemistry

5-15 µg/mL
Sample: Perfusion fixed frozen sections of mouse thymus

Western Blot

0.1 µg/mL
Sample: Recombinant Mouse PD-L2 Fc Chimera (Catalog # 1022-PL)

Reviewed Applications

Read 3 reviews rated 4.3 using AF1022 in the following applications:

Flow Cytometry Panel Builder

Bio-Techne Knows Flow Cytometry

Save time and reduce costly mistakes by quickly finding compatible reagents using the Panel Builder Tool.

Advanced Features

  • Spectra Viewer - Custom analysis of spectra from multiple fluorochromes
  • Spillover Popups - Visualize the spectra of individual fluorochromes
  • Antigen Density Selector - Match fluorochrome brightness with antigen density
Build Your Panel Now
Flow Cytometry

Formulation, Preparation, and Storage

Purification

Antigen Affinity-purified

Reconstitution

Reconstitute at 0.2 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.

Formulation

Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.

Shipping

Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.

Stability & Storage

Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.

Calculators

The reconstitution calculator allows you to quickly calculate the volume of a reagent to reconstitute your vial. Simply enter the mass of reagent and the target concentration and the calculator will determine the rest.

=
÷

Background: PD-L2/B7-DC

Mouse Programmed Death Ligand 2 (PD-L2), also named B7DC and butyrophilin-like protein, is a member of the B7 family of proteins that provide signals for regulating T-cell activation and tolerance (1-4). Other family members include B7-1, B7-2, B7-H2, PD-L1 (B7-H1), and B7-H3. B7 proteins are immunoglobulin (Ig) superfamily members with extracellular Ig-V-like and Ig-C-like domains and short cytoplasmic domains. Among the family members, they share from 20-40% amino acid (aa) sequence identity. The cloned mouse PD-L2 cDNA encodes a 247 aa type I membrane precursor protein with a putative 20 aa signal peptide, a 199 aa extracellular region containing one V-like and one C-like Ig domain, a 23 aa transmembrane region, and only a 5 aa cytoplasmic domain. The extracellular domains of mouse and human PD-L2 share approximately 72% aa sequence identity. PD-L2 is one of two ligands for programmed death-1 (PD-1), a member of the CD28 family of immunoreceptors. The other identified ligand is PD-L1. Mouse PD-L1 and PD-L2 share approximately 34% aa sequence identity and have similar functions. PD-L2 is constitutively expressed in lymphoid and non-lymphoid organs (1-4). The expression of PD-L2 is detected on dendritic cells, thymic epithelial cells and IFN-gamma treated monocytes. PD-L2 expression is also upregulated in a variety of tumor cell lines. On previously activated T cells, PD-L2 interaction with PD-1 inhibits TCR-mediated proliferation and cytokine production, suggesting an inhibitory role in regulating immune responses. In contrast, a co-stimulatory function for the PD-1 ligands on resting T cells has also been reported.

References

  1. Latchman, Y. et al. (2001) Nature Immun. 2:261.
  2. Tseng, B.S-Y. et al. (2001) J. Exp. Med. 193:839.
  3. Sharpe, A.H. and G.J. Freeman (2002) Nat. Rev. Immunol. 2:116.
  4. Coyle, A. and J. Gutierrez-Ramos (2001) Nat. Immunol. 2:203.

Long Name

Programmed Death-1 Ligand-2

Alternate Names

B7-DC, Butyrophilin-like Protein, CD273, PDCD1LG2, PDL2

Entrez Gene IDs

80380 (Human); 58205 (Mouse); 309304 (Rat); 102146227 (Cynomolgus Monkey)

Gene Symbol

PDCD1LG2

UniProt

Q9WUL5

Additional PD-L2/B7-DC Products

Product Documents for Mouse PD-L2/B7-DC Antibody

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot or batch number in the search box below.

Note: Certificate of Analysis not available for kit components.

Download SDS

Product Specific Notices for Mouse PD-L2/B7-DC Antibody

For research use only

Citations for Mouse PD-L2/B7-DC Antibody

Customer Reviews for Mouse PD-L2/B7-DC Antibody (3)

4.3 out of 5
3 Customer Ratings
5 Stars
33%
4 Stars
67%
3 Stars
0%
2 Stars
0%
1 Stars
0%

Have you used Mouse PD-L2/B7-DC Antibody?

Submit a review and receive an Amazon gift card!

$25/€18/£15/$25CAN/¥2500 for a review with an image

$10/€7/£6/$10CAN/¥1110 for a review without an image

Submit a review
Amazon Gift Card

Customer Images

Showing  1 - 3 of 3 reviews Showing All
Filter By:
Clear Filters X
  • Mouse PD-L2/B7-DC Antibody
    Name: Anonymous
    Application: Immunocytochemistry/Immunofluorescence
    Sample Tested: Cancer Cells
    Species: Mouse
    Verified Customer | Posted 05/12/2018
    Cancer associated fibroblasts (CAF)
    Mouse PD-L2/B7-DC Antibody AF1022
  • Mouse PD-L2/B7-DC Antibody
    Name: Mozhdeh Sojoodi
    Application: Immunocytochemistry/Immunofluorescence
    Sample Tested: Pancreatic cancer cells
    Species: Mouse
    Verified Customer | Posted 07/18/2017
    Overnight incubation with primary Ab. 4C
    Mouse PD-L2/B7-DC Antibody AF1022
  • Name: Anonymous
    Application: Immunofluorescence
    Sample Tested: See PMID 23090063
    Species: Mouse
    Verified Customer | Posted 01/05/2015
