TIM-4 (T cell; immunoglobulin; mucin-4), also known as SMUCKLER, is a 60 kDa member of the TIM family of immune regulating proteins. TIMs are type I transmembrane proteins with one Ig-like V domain and one Ser/Thr-rich mucin domain (1 - 3). The human TIM-4 cDNA encodes a 378 amino acid (aa) precursor that includes a 24 aa signal sequence, a 290 aa extracellular domain (ECD), a 21 aa transmembrane segment, and a 43 aa cytoplasmic tail (4). Structurally, TIM-4 is distinguished from other TIMs by the presence of an RGD motif in its Ig domain and the lack of a site for tyrosine phosphorylation in its cytoplasmic tail. The mucin domain in TIM-4 is larger than in TIM-1 or TIM-3. Within the ECD, human TIM-4 shares 35% and 23% aa sequence identity with TIM-1 and TIM-3, respectively. A TIM-2 ortholog has not been identified in human. The ECD of human TIM-4 shares 45% aa sequence identity with that of mouse and rat TIM-4. TIM-4 is expressed by macrophages and mature dendritic cells but not by lymphocytes (4, 5). TIM-4 binds specifically to TIM-1 which is also the cellular receptor for the hepatitis A virus, and has been implicated in the development of asthma (5 - 7). Among hematopoietic cells, TIM-1 is expressed on activated B and T cells, preferentially in the Th2 subset of CD4+ T cells (5, 8). The interaction of TIM-4 with TIM-1 induces costimulatory and hyperproliferative signals in T cells (5).
Key Product Details
Species Reactivity
Validated:
Cited:
Applications
Validated:
Cited:
Label
Antibody Source
Product Specifications
Immunogen
Glu25-Leu315
Accession # Q96H15
Specificity
Clonality
Host
Isotype
Scientific Data Images for Human TIM‑4 Antibody
Detection of Recombinant Human TIM‑4 by Western Blot.
Western blot shows 25 ng of Recombinant Human TIM-4 His-tag (Catalog # 2929-TM), Recombinant Human TIM-1/KIM-1/HAVCR (Catalog # 1750-TM), Recombinant Human TIM-3 Fc Chimera (Catalog # 2365-TM), Recombinant Mouse TIM-1/KIM-1/HAVCR (Catalog # 1817-TM), Recombinant Mouse TIM-2 (Catalog # 1885-TM), Recombinant Mouse TIM-3 Fc Chimera (Catalog # 1529-TM), Recombinant Mouse TIM-4 (Catalog # 2826-TI), Recombinant Mouse TIM-5, and Recombinant Mouse TIM-6. PVDF Membrane was probed with 0.1 µg/mL of Goat Anti-Human TIM-4 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF2929) followed by HRP-conjugated Anti-Goat IgG Secondary Antibody (Catalog # HAF109). A specific band was detected for TIM-4 at approximately 75 kDa (as indicated). This experiment was conducted under reducing conditions and using Immunoblot Buffer Group 3.
TIM‑4 in Human Tonsil.
TIM-4 was detected in immersion fixed paraffin-embedded sections of human tonsil using Goat Anti-Human TIM-4 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF2929) at 1 µg/mL for 1 hour at room temperature followed by incubation with the Anti-Goat IgG VisUCyte™ HRP Polymer Antibody (Catalog # VC004). Before incubation with the primary antibody, tissue was subjected to heat-induced epitope retrieval using Antigen Retrieval Reagent-Basic (Catalog # CTS013). Tissue was stained using DAB (brown) and counterstained with hematoxylin (blue). Specific staining was localized to cell membranes of macrophages. View our protocol for IHC Staining with VisUCyte HRP Polymer Detection Reagents.
Applications for Human TIM‑4 Antibody
Immunohistochemistry
Sample: Immersion fixed paraffin-embedded sections of human tonsil
Western Blot
Sample: Recombinant Human TIM‑4 (Catalog # 2929-TM)
Reviewed Applications
Read 1 review rated 4 using AF2929 in the following applications:
Formulation, Preparation, and Storage
Purification
Reconstitution
Reconstitute at 0.2 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.
Formulation
Shipping
Stability & Storage
- 12 months from date of receipt, -20 to -70 °C as supplied.
- 1 month, 2 to 8 °C under sterile conditions after reconstitution.
- 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Calculators
Background: TIM-4
References
- Kuchroo, V.K. et al. (2003) Nat. Rev. Immunol. 3:454.
- Mariat, C. et al. (2005) Phil. Trans. R. Soc. B 360:1681.
- Meyers, J.H. et al. (2005) Trends Mol. Med. 11:362.
- Shakhov, A.N. et al. (2004) Eur. J. Immunol. 34:494.
- Meyers, J.H. et al. (2005) Nat. Immunol. 6:455.
- Feigelstock, D. et al. (1998) J. Virol. 72:6621.
- McIntire, J.J. et al. (2001) Nat. Immunol. 2:1109.
- Khademi, M. et al. (2004) J. Immunol. 172:7169.
Long Name
Alternate Names
Gene Symbol
UniProt
Additional TIM-4 Products
Product Documents for Human TIM‑4 Antibody
Certificate of Analysis
To download a Certificate of Analysis, please enter a lot or batch number in the search box below.
Note: Certificate of Analysis not available for kit components.
Product Specific Notices for Human TIM‑4 Antibody
For research use only
Citations for Human TIM‑4 Antibody
Customer Reviews for Human TIM‑4 Antibody (1)
Have you used Human TIM‑4 Antibody?
Submit a review and receive an Amazon gift card!
$25/€18/£15/$25CAN/¥2500 Yen for a review with an image
$10/€7/£6/$10CAN/¥1110 Yen for a review without an image
Submit a review
-
Application: Flow CytometrySample Tested: See PMID 23084921Species: OtherVerified Customer | Posted 01/07/2015
