Human/Mouse/Rat B-Raf Antibody


  • Species Reactivity
    Human, Mouse, Rat
  • Specificity
    Detects human, mouse, and rat B-Raf. No cross-reactivity with recombinant human Raf-1 is observed. Cross-reactivity with A-Raf has not been tested.
  • Source
    Monoclonal Mouse IgG2A Clone # 336016
  • Purification
    Protein A or G purified from hybridoma culture supernatant
  • Immunogen
    E. coli-derived recombinant human B-Raf
    Met1-His766
    Accession # P15056
  • Formulation
    Lyophilized from a 0.2 μm filtered solution in PBS and NaCl with Trehalose. *Small pack size (SP) is supplied as a 0.2 µm filtered solution in PBS.
  • Label
    Unconjugated
Applications
  •
    Recommended
    Concentration
    Sample
  • Western Blot
    1 µg/mL
    See below
Please Note: Optimal dilutions should be determined by each laboratory for each application. General Protocols are available in the Technical Information section on our website.
Data Examples
Detection of Human/Mouse/Rat B‑Raf by Western Blot. Western blot shows lysates of MDA-MB-468 human breast cancer cell line, Raji human Burkitt's lymphoma cell line, and Ramos human Burkitt's lymphoma cell line. PVDF membrane was probed with 1 µg/mL Mouse Anti-Human/Mouse/Rat B‑Raf Monoclonal Antibody (Catalog # MAB3424) followed by HRP-conjugated Anti-Mouse IgG Secondary Antibody (Catalog # HAF007). For additional reference, Recombinant Human Active Raf‑1 (Y340E Y341E), aa 306-648 (Catalog # 4540-KS) and recombinant human B-Raf (5 ng/lane) were included. A specific band for B-Raf was detected at approximately 95 kDa (as indicated). An unidentified band at 55 kDa was also detected. This experiment was conducted under reducing conditions and using Immunoblot Buffer Group 2.
Preparation and Storage
  • Reconstitution
    Reconstitute at 0.5 mg/mL in sterile PBS.
  • Shipping
    The product is shipped at ambient temperature. Upon receipt, store it immediately at the temperature recommended below. *Small pack size (SP) is shipped with polar packs. Upon receipt, store it immediately at -20 to -70 °C
  • Stability & Storage
    Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
    • 12 months from date of receipt, -20 to -70 °C as supplied.
    • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
    • 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Background: B-Raf

The Raf serine/threonine kinases are effectors of Ras that function as MAP3Ks in the ERK phosphorylation cascade. Mammals express three Raf proteins: Raf-1 (C‑Raf); A-Raf; and B-Raf, strongly expressed in fetal brain and adult cerebrum. Mice with a targeted disruption of the B-raf gene die of vascular defects during mid‑gestation. B-raf mutations have been found in two-thirds of malignant melanomas, with the single substitution V599E in the kinase domain the most frequent occurrence.

  • Long Name:
    v-Raf Murine Sarcoma Viral Oncogene Homolog B1
  • Entrez Gene IDs:
    673 (Human); 114486 (Rat)
  • Alternate Names:
    94 kDa B-raf protein; B-Raf proto-oncogene serine/threonine-protein kinase (p94); BRaf; B-Raf; BRAF1; B-RAF1; BRAF1MGC126806; EC 2.7.11.1; MGC138284; murine sarcoma viral (v-raf) oncogene homolog B1; NS7; p94; Proto-oncogene B-Raf; RAFB1; serine/threonine-protein kinase B-raf; v-raf murine sarcoma viral oncogene homolog B1FLJ95109
