Angiogenesis is the tightly regulated process by which new blood vessels are formed from the existing vasculature. This process is physiologically important for development and wound healing, and is also a common driver in multiple diseases including rheumatoid arthritis, atherosclerosis, macular degeneration, and cancer. Angiogenesis occurs in response to a variety of molecular cues. Generally, the angiogenic process includes endothelial cell proliferation, chemotactic endothelial cell migration through the extracellular matrix barrier, and the formation of capillary tubes. Physiological and pathological angiogenesis utilize many of the same cellular processes and molecular signaling networks, however the structures that form during pathological angiogenesis are often functionally abnormal.
Proteome Profiler Mouse Angiogenesis Array Kit
R&D Systems | Catalog # ARY015
Key Product Details
Species
Product Summary for Proteome Profiler Mouse Angiogenesis Array Kit
Kit Summary
A membrane-based antibody array for the parallel determination of the relative levels of selected angiogenesis-related proteins. Validated for analyte detection in cell culture supernates, cell lysates, tissue lysates or serum.
Key Benefits
- Detects 53 mouse angiogenesis-related proteins simultaneously
- Requires no specialized equipment
Principle of the Array
The Proteome Profiler Mouse Angiogenesis Array Kit is a membrane-based sandwich immunoassay. Samples are mixed with a cocktail of biotinylated detection antibodies (Step 1) and then incubated with the array membrane which is spotted in duplicate with capture antibodies to specific target proteins (Step 2). Captured proteins are visualized using chemiluminescent detection reagents (Step 3). The signal produced is proportional to the amount of analyte bound. Analytes include soluble growth and differentiation factors, extracellular matrix components, proteases, membrane-bound receptors, and intracellular signaling molecules.
Why Use an Antibody Array to Detect Angiogenesis-Related Proteins?
Determining the expression of multiple cytokines in a single sample can be expensive, time consuming and can require specialized equipment. Performing multiple immunoprecipitations and Western blots requires time, labor, and reagents. The use of a multiplex antibody array to detect multiple cytokines in a single sample can be cost-effective and also save time and sample.
- 4 Array Membranes
- 4-Well Multi-dish
- Array Buffers
- Wash Buffer
- Detection Antibody Cocktail
- Streptavidin-HRP
- Chemiluminescent Detection Reagents
- Transparency Overlay Template
- Detailed Protocol
For a complete list of the kit contents and necessary materials, please see the Materials Provided/Other Supplies Required sections of the product datasheet.
Stability and Storage
Store the unopened kit at 2°C to 8°C. Do not use past kit expiration date.
| Simultaneously detect the relative levels of these angiogenesis-related proteins in a single sample. | ||
|---|---|---|
| ADAMTS1 | Endothelin-1 | NOV/CCN3/IGFBP-9 |
| Amphiregulin | FGF acidic | Osteopontin |
| Angiogenin | FGF basic | PD-ECGF |
| Angiopoietin-1 | FGF-7/KGF | PDGF-AA |
| Angiopoietin-3 | Fractalkine | PDGF-AB/BB |
| CCL2/JE/MCP-1 | GM-CSF | Pentraxin-3 |
| CCL3/MIP-1 alpha | HB-EGF | PlGF-2 |
| CXCL1/KC | HGF | Prolactin |
| CXCL10/IP-10/CRG-2 | IGFBP-1 | Proliferin |
| CXCL12/SDF-1 | IGFBP-2 | Serpin E1/PAI-1 |
| CXCL16 | IGFBP-3 | Serpin F1/PEDF |
| CXCL4/PF4 | IL-1 alpha | Thrombospondin-2 |
| Cyr61/CNN1/IGFBP-10 | IL-1 beta | TIMP-1 |
| DLL4 | IL-10 | TIMP-4 |
| DPPIV/CD26 | Leptin | Coagulation Factor III |
| EGF | MMP-3 (pro and mature) | VEGF |
| Endoglin/CD105 | MMP-8 (pro) | VEGF-B |
| Endostatin/Collagen XVIII | MMP-9 (pro and active) | |
Assays for analytes represented in the Mouse Angiogenesis Antibody Array Kit
| Quantkine® ELISA kit | DuoSet® ELISA Development Reagents | |
| ADAMTS1 | ||
| Amphiregulin | DY989 | |
| Angiogenin | ||
| Angiopoietin-1 | ||
| Angiopoietin-3 | MANL30 | DY738 |
| CCL2/JE/MCP-1 | MJE00 | DY479 |
| CCL3/MIP-1 alpha | MMA00 | DY450 |
| CXCL1/KC | MKC00B | DY453 |
| CXCL10/IP-10/CRG-2 | MCX100 | DY466 |
| CXCL12/SDF-1 | MCX120 | DY460 |
| CXCL16 | DY503 | |
| CXCL4/PF4 | MCX400 | DY595 |
| Cyr61/CNN1/IGFBP-10 | ||
| DLL4 | DY1389 | |
| DPPIV/CD26 | DY954 | |
| EGF | MEG00 | DY2028 |
| Endoglin/CD105 | MNDG00 | DY1320 |
| Endostatin/Collagen XVIII | ||
| Endothelin-1 | DET100 | |
| FGF acidic | ||
| FGF basic | ||
| FGF-7/KGF | ||
| Fractalkine | MCX310 | DY472 |
| GM-CSF | MGM00 | DY415 |
| HB-EGF | ||
| HGF | MHG00 | DY2207 |
| IGFBP-1 | ||
| IGFBP-2 | DY797 | |
| IGFBP-3 | MGB300 | DY775 |
| IL-1 alpha | MLA00 | DY400 |
| IL-1 beta | MLB00C | DY401 |
| IL-10 | M1000B | DY417 |
| Leptin | MOB00 | DY498 |
| MMP-3 (pro and mature) | MMP300 | |
| MMP-8 (pro) | ||
| MMP-9 (pro and active) | MMPT90 | |
| NOV/CCN3/IGFBP-9 | DY1976 | |
| Osteopontin | MOST00 | DY441 |
| PD-ECGF | ||
| PDGF-AA | DAA00B | |
| PDGF-AB/BB | MHD00/MBB00 | |
| Pentraxin-3 | MPTX30 | DY2166 |
| PlGF-2 | MP200 | DY465 |
| Prolactin | DY1445 | |
| Proliferin | ||
| Serpin E1/PAI-1 | ||
| Serpin F1/PEDF | ||
| Thrombospondin-2 | ||
| TIMP-1 | MTM100 | DY980 |
| TIMP-4 | ||
| Coagulation Factor III | ||
| VEGF | MMV00 | DY493 |
| VEGF-B | DY469 |
Scientific Data Images for Proteome Profiler Mouse Angiogenesis Array Kit
Multiple Proteins in TNF-alpha-treated Balb/3T3 Cells were Assessed using the Mouse Angiogenesis Array.
A. The Proteome Profiler Mouse Angiogenesis Array Kit (Catalog # ARY015) was used to simultaneously assess the relative levels of 53 mouse angiogenesis-related proteins in cell lysates from Balb/3T3 mouse embryonic fibroblast cells that had been left untreated or treated with recombinant mouse TNF-alpha (Catalog # 410-MT) for 24 hours. B. Histogram profiles for select proteins were generated by quantifying the mean spot pixel density from the arrays using image software analysis. Green bars represent protein levels in lysates from untreated cells, purple bars represent protein levels in lysates from TNF-alpha-treated cells.
